82 Mechanical Drawings 17 70 03 Issu e 1 Bo ar d Clamp - 340 GA A B C D REMOVE ALL BURRS & SHARP EDGES 45 6 1 2 3 45 6 1 2 3 A B C E E PROJECTION D DRAWN APPROVED DATE C COPYRIGHT DO NO T SCALE SCALE TITLE DRAWING NU…
Mechanical Drawings 81
177002 Issue 1 USC Drive Carriage Slim Tank GA
54321
A
B
CC
B
A
12345
67
8
910
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
ITEM PART NO. DESCRIPTION QTY.
1
107265 ELBOW F/F 2
2
107443 RARE EARTH POT TYPE MAGNET 2
3
112664 EARTHING STUD 1
4
119664 FILLER CAP 1
5
119667 WASHER SEALING 1
6
129217 MAGNET HOLDER, LH 1
7
129504 MAGNET HOLDER, RH 1
8
133149 VAC. U.S.C. LOW SOLVENT LOOM BOM 1
9
140535 SEALING WASHER 1
10
156599 MANIFOLD 1
11
156924 DRIVE UNIT ASSEMBLY 1
12
157281 INTERFACE BRACKET 1
13
163490 SOLVENT TANK 1
14
700102 SCREW M3X10 CAP HD ST.ST 2
15
700110 SCREW M4X10 CAP HD ST.ST 1
16
700111 SCREW M4X12 CAP HD ST.ST 2
17
700114 SCREW M4X30 CAP HD ST.ST 2
18
700132 SCREW M5X10 CAP HD ST.ST 3
19
700415 SCREW M3X16 CSK.SLTD.M/C ST.ST 2
20
700526 NUT M5 FULL BRASS 1
21
700602 WASHER M4 PLAIN FORM A ST.ST 1
22
700603 WASHER M5 PLAIN FORM A ST.ST 3
23
700609 WASHER M3 CRINKLE BE/CU 2
24
700656 6BA T2 WASHER S/S 2
25
E0509 P-CLIP LARGE, SIZE 3,DIA 9.5-14.3 1
26
G0332 FLEXO 123008 SPRING 2
27
G5120 WASHER M5 BRASS FORM B 1
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
JLANGHAM
GA^DRIVE CARRIAGE^USC^SLIM TANK
06-Dec-01
177002
177000
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
01 06-Dec-01 26905 JL
SCALE 4:5
SCALE 3:5
SCALE 3:5
2
1
3
1
4
1
5
1
6
1
7
1
11
1
12
1
13
1
25
1
26
1
2
1
26
1
15
1
16
2
17
1
18
2
19
2
20
1
22
2
23
2
24
2
22
1
18
1
17
1
1
2
8
1
9
1
14
2
21
1
27
1
82 Mechanical Drawings
177003 Issue 1 Board Clamp - 340 GA
A
B
C
D
REMOVE ALL BURRS & SHARP EDGES
456
1
2
3
456
1
2
3
A
B
C
E
E
PROJECTION
D
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
Z
Z
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
A HAMLIN
DWG^GA^BOARD CLAMP ASSY^340 LG
20-Sep-01
177003
177060
SH 1
OF 1
A
2
ITEM PART NO. DESCRIPTION QTY.
1
177004 CARRIER^^BOARD CLAMP^340mm 1
2
177005 DWG^GA^FOIL ASSY^340 mm 1
3
177083 PLATE^ANGLED LH^BOARD CLAMP^340 1
4
177084 PLATE^ANGLED RH^BOARD CLAMP^340 1
5
700037 SCREW M5X6 PAN.HD SLTD MC ST.ST 2
6
700069 SCREW M2.5X6 PN.HD SLTD MC ST.ST 6
LATEST
ISSUE
No. DATE DCR INITIAL
02 09-Oct-01 27027 AH
NOTE:
1. DO NOT USE LOCTITE ON FASTENERS.
2. ENSURE NOTCHES IN ITEMS 3 & 4 FACE
AWAY FROM FOIL.
5
SECTION Z-Z
SCALE 4:1
1
6
2
3
4
Mechanical Drawings 83
177005 Issue 1 Foil Assy - 340mm GA
A
B
C
D
REMOVE ALL BURRS & SHARP EDGES
456
1
2
3
456
1
2
3
A
B
C
E
E
PROJECTION
D
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
A
A
0.05
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
A HAMLIN
DWG^GA^FOIL ASSY^340 mm
19-Sep-01
177005
177061
SH 1
OF 1
A
2
ITEM PART NO. DESCRIPTION QTY.
1
177006 FIXING BLOCK^FOIL^^340 1
2
177007 FOIL^^^340 1
LATEST
ISSUE
No. DATE DCR INITIAL
02 09-Oct-01 27027 AH
NOTES:
1. TAPPED HOLES TO BE COVERED WITH SELF ADHESIVE LABEL
PART NO. 145136 BEFORE APPLYING ADHESIVE.
2. PARTS TO BE BONDED USING 3M SCOTCH-WELD DP460 ADHESIVE,
DEK PART NO. 112104, IN ACCORDANCE WITH PLP188.
3. REMOVE ANY EXCESS ADHESIVE.
SECTION A-A
SCALE 10:1
SEE NOTE 3
SEE NOTE 3
2
1
