P-335-001_SIGMA-F8高速贴装头V11_GS-HH850.pdf - 第12页
– 6 – G1 2 Electrical Box 1402-001 X10202 X0709 X0305 X3105 N5 C N1 C 5 N C A 2 P N C B 2 P N C C 2 P N C D 2 P N C A 2 N C B 2 N C C 2 N C D 2 N C 3 P N C D 4 N C C 4 N C B 4 N C 3 N C N1 C N1 C N7 C N8 C N9 C N2 C N3 C…
– 5 –
HIGH SPEED HEAD(DDH V11)
1402-001
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
4
KYA-M700D-00
1006D40J BOX_ELE 1
5 KYB-M658U-00 4U240493 UNIT-DRIVER 1
6 KYA-M701E-00 1006D40L BRACKET_CONNECTOR 1
7 KYA-M701F-00 1006D40M COVER_ELE_BOX 1
8 KYB-M700E-00 1011D215 BRACKET_MV-CAB 1
10 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 4
11 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 4
12 90990-11J009 221DA051 MACHINE SCREW 17
13 KYA-M7026-00 1006D40B SPACER 8
21 KYA-M701G-00 1006D701 HNS,CBL-SLIP-RING 1
22 KYA-M701H-00 1006D702 HNS,CBL-HEAD-SENSOR 1
23 KYA-M702D-00 23N30172 ACCESS-WIRING 1
24 KYB-M656C-00 0916D209 ACCESS-WIRING 120
25 KYB-M65AW-00 23N30632 WIRING 1
33 KYB-M7008-00 0914014W ASSY_WARNING-HH_1 1
34
該当なし
1006360H ASSY_NAMEPLATE 1
– 6 –
G1
2 Electrical Box
1402-001
X10202
X0709
X0305
X3105
N5
C
N1
C
5NC
A2
PNC
B2
PNC
C
2PNC
D
2PNC
A2N
C
B2N
C
C2
NC
D2
NC
3PNC
D4NCC
4
NCB4NC
3N
C
N1
C
N1
C
N7
C
N8C
N9
C
N2C
N3
C
NX1C
N5
C
N10
C
N6
C
Y0208
106
122
123
110
110
111
U02
101
101
125
125
122
124
102
104
103
131
132
105
U02
U03
A31
123
104
121
121
113
109
112
108
126
107
See Fig. G1-6
Key No.581-583
See Fig. G1-1
Key No.9
See Fig. G1-1
Key No.5
X0305
X0208
X0202
X0201
X02X1
X3105
Y0208
X0709
X10202
X31P1
X314B
X314D
1PNC
– 7 –
HIGH SPEED HEAD(DDH V11)
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYA-M701J-00 1005DA00 PCB-MOUNT 1
102 KYB-M850W-00 1005AB04 PIPE_FITTINGS 1
103 KYB-M702S-00 1005AB0A PIPE_FITTINGS 1
104 KYA-M700X-00 10063000 ASSY,VALVE Y0208 1
105 KYB-M220P-00 1005AB0E PIPE_FITTINGS 1
106 KYA-M700M-00 1006D40K BRACKET_PCB 1
107 KYC-M177Y-00 23N30589 ACCESS WIRING 1
108 90112-02J010 221AB014 BOLT,HEX.SOCKET HEAD 2
109 91312-04020 221AA021 BOLT,HEX.SOCKET HEAD 1
110 90990-11J009 221DA051 MACHINE SCREW 7
111 90990-11J010 221DA056 SCREW,PAN HEAD WW 2
112 90171-02J026 221HA101 WASHER,PLAIN 2
113 92902-04200 221HA104 WASHER 1
121 KYA-M700T-00 1005BC1M HNS,HEAD-IN-P 1
122 KYA-M700U-00 1005BC1P HNS,HEAD-IN-S 1
123 KYA-M700V-00 1005BC1Q HNS,DD-PULSE 1
124 KYB-M65AW-00 23N30632 WIRING 5
125 KYA-M7026-00 1006D40B SPACER 8
126 KYB-M656C-00 0916D209 ACCESS-WIRING 13
131 KYA-M7022-00 1006370B TUBE_D4 1
132 KYA-M7023-00 1006370C TUBE_D8 1
1402-001
