Product Engineering Division
SMT Section
Robotics Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50281
1/15
Feeder ID Log
Function Specifications
History of Revision
Changes are marked with [▲(rev)].
Rev Version Chapter Revised Contents
00 V3.42STD R1.000
V4.42STD R1.000
All Created
01 V3.45STD R1.000
V4.48STD R1.000
3 Items on [Feeder ID Log] screen added.
・Feeder MACS Correct X
・Feeder MACS Correct Y
02 V3.49STD R3.000
V4.63STD R4.000
1-3 Items on [Feeder ID Log] screen added.
・Drive Cnt After Tape Guide Maintenance
本文書に含まれる技術内容は当社の秘密情報です。当社の許諾無く第三者への開示はできません。
The information contained in this message may be confidential and legally protected under
applicable law. The message is intended solely for the addressee(s).
If you are not the intended recipient, you are hereby notified that any use, forwarding,
dissemination, or reproduction of this message is strictly prohibited and maybe unlawful.
Product Engineering Division
SMT Section
Robotics Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50281
2/15
Contents
Feeder ID Log................................................................................................................................ 1
Function Specifications .................................................................................................................. 1
Contents ........................................................................................................................................ 2
1. Applicable models and software versions ................................................................................. 3
2. Outline ....................................................................................................................................... 3
3. Detail ......................................................................................................................................... 3
3.1 Feeder ID log screen ........................................................................................................... 3
3.1.1 Display items ................................................................................................................. 4
3.1.2 “Save Log” button .......................................................................................................... 6
3.1.3 “Reset” button ............................................................................................................... 6
3.1.4 “Option” button .............................................................................................................. 7
3.2 Feeder ID log file ................................................................................................................. 8
3.2.1 Feeder ID individual log file ........................................................................................... 8
3.2.2 Feeder ID daily log file .................................................................................................. 8
3.2.3 Feeder ID log backup file .............................................................................................. 8
3.3 Feeder ID log file format ...................................................................................................... 8
4. Setting ..................................................................................................................................... 11
4.1 Setting in “ID log setting” screen........................................................................................ 11
4.2 Setting in “Unit log” screen ................................................................................................ 13
4.3 Setting in “Setting Detail History” screen ........................................................................... 13
5. Error Message ......................................................................................................................... 14
Product Engineering Division
SMT Section
Robotics Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50281
3/15
1. Applicable models and software versions
Applicable feeders and software version are as below.
Table1.1 Applicable feeders and software version
Feeders Software Version Remarks
CLi feeder,
FSi feeder
V3.42STD R1.000 or later YG300,
YG12 series mounters
SS feeder,
ZS feeder
V3.42STD R1.000 or later
V4.42STD R1.000 or later
YS series mounters,
YSM series mounters
Auto Loading Feeder only V3.49STD R3.000 or later
V4.63STD R4.000 or later
YS series mounters,
YSM series mounters
2. Outline
Feeder ID Log function is able to manage the information about feeder usage condition,
error frequency, etc. for each one feeder (each feeder ID) by identifying feeder ID of each
feeder. However, target feeders are only SS feeder, ZS feeder, Auto Loading Feeder
▲2
, CLi
feeder, and FSI feeder.
To use this function, it is necessary to validate Feeder Maintenance Notice function. When
the first installation, Feeder Maintenance Notice function becomes effective by default.
3. Detail
This chapter explains about the feeder ID log screen and the feeder ID log file.
3.1 Feeder ID log screen
The feeder ID log is displayed at [Unit Log]-[Feeder ID] tab.
“Feeder ID” tab is further divided into three tabs. The "Operator" or "Service" tab can be
cleared as needed. The "Total" log cannot be cleared.
