E-by SIPLACE CP14 Removing the Aperture Ring Part Exchange 1/1 CAUTION! Refer to safety inst ructions in user manual before working on the machine. ESD guidelines are to be followed Tool: Wear Part: Consum ables: 1. Loos…

E-by SIPLACE CP14 Removing the CP14 Head

Part Exchange

2/2

CAUTION! Refer to safety instructions in user manual before working on the machine.

ESD guidelines are to be followed

Tool: Wear Part: Consumables:

7. Carefully lift the head out of the locating

pins on the head plate.

E-by SIPLACE CP14 Removing the Aperture Ring

Part Exchange

1/1

CAUTION! Refer to safety instructions in user manual before working on the machine.

ESD guidelines are to be followed

Tool: Wear Part: Consumables:

1. Loosen the screw fastening the cover and

remove it.

2. Loosen the three screws (1) fastening the

aperture ring.

3. Carefully lever the aperture ring off the lo-

cating pins. Make sure that the O-ring is not

damaged.
