GSF
Guide Kits for SF280
With Perforation:
Ref.: GSF08V-B wire Ø 0.8 mm / Ø 0.032 in
Ref.: GSF10V-B wire Ø 1.0 mm / Ø 0.040 in
Ref.: GSF12V-B wire Ø 1.2 mm / Ø 0.047 in
Ref.: GSF15V-B wire Ø 1.5 mm / Ø 0.059 in
Ref.: GSF16V-B wire Ø 1.6 mm / Ø 0.063 in
Without Perforation:
GSF04D-B for wire Ø 0.38 - 0.40 mm / Ø 0.015 - 0.016 in
GSF05D-B for wire Ø 0.46 - 0.56 mm / Ø 0.018 - 0.022 in
GSF06D-B for wire Ø 0.60 - 0.64 mm / Ø 0.023 - 0.025 in
GSF07D-B for wire Ø 0.70 - 0.78 mm / Ø 0.028 - 0.031 in
GSF08D-B for wire Ø 0.80 - 0.82 mm / Ø 0.032 - 0.033 in
GSF10D-B for wire Ø 0.90 - 1.10 mm / Ø 0.036 - 0.044 in
GSF12D-B for wire Ø 1.14 - 1.27 mm / Ø 0.045 - 0.051 in
GSF15D-B for wire Ø 1.50 - 1.57 mm / Ø 0.060 - 0.062 in
GSF16D-B for wire Ø 1.60 - 1.63 mm / Ø 0.063 - 0.065 in
GSF18D-B for wire Ø 1.80 mm / Ø 0.073 in
- Guide Tube Length: 126 cm / 49.6 in
- Package Dimensions: 245 x 185 x 45 mm
(L x W x H) 9.65 x 7.28 x 1.77 in
Complies with CE standards.
ESD safe
Specifications
Total Net Weight: Package Weight:
108 g / 0.24 lb 200 g / 0.44 lb
108 g / 0.24 lb 200 g / 0.44 lb
94 g / 0.21 lb 186 g / 0.41 lb
94 g / 0.21 lb 186 g / 0.41 lb
94 g / 0.21 lb 186 g / 0.41 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
90 g / 0.20 lb 182 g /0.40 lb
90 g / 0.20 lb 182 g /0.40 lb
90 g / 0.20 lb 182 g /0.40 lb
90 g / 0.20 lb 182 g /0.40 lb
11
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
