GSF Guide Kit for SF280 with Solder Wire Perforation 4

100%1 / 12
The following items are included:
Packing List
Guide Tube* ............................................. 1 unit
Inlet Nozzle* ............................................. 1 unit
Traction Wheel* ....................................... 1 unit
Support Wheel* ....................................... 1 unit
Counter Wheel* ....................................... 1 unit
Intermediate Nozzle* ............................. 1 unit
Outlet Nozzle* .......................................... 1 unit
*references see table on page 5
GSF Guide Kit for SF280 without Solder Wire Perforation
Intermediate Nozzle
Traction Wheel
Outlet Nozzle
Counter Wheel
Support Wheel
Headless Screws
Guide Tube
Inlet Nozzle
Allen Screws
Allen Screws* ......................................... 2 units
Headless Screws* ................................ 3 units
Manual ....................................................... 1 unit
Ref. 0028099
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
GSF Guide Kit for SF280
with Solder Wire Perforation
4
GSFXXD-B
WITHOUT SOLDER WIRE PERFORATION
Wire
SPARE PARTS
Outlet nozzle
Nozzle
Traction wheel
Support wheel
Inlet nozzle
Interm. nozzle
Counter wheel
Screws
Threaded stud
GSF04D-B
0025268
0021158
0019479
0020345
0019520
0024954
0026693
(Supplied with
SF)
0026695
(x2)
0026696
(x3)
GSF05D-B
0019519
GSF06D-B
0022994
0025293
GSF07D-B
0025289
0019480
0018632
0025291
GSF08D-B
0025270
0024955
GSF10D-B
0021560
0019170 0024956
GSF12D-B
0025272
0019481 0019171
0024957
0026694
GSF15D-B
0025274
0024958
GSF16D-B
0025276
0028367
0024233 0024959
GSF18D-B
0021559
0024234 0024960
Guide tube
GSF04X-B
0019521
GSF05X-B
GSF06X-B
GSF07X-B
0018630
GSF08X-B
GSF10X-B
0019168
GSF12X-B
0026113
GSF15X-B
0019169
GSF16X-B
0026115
GSF18X-B
Wire diameter
XX
Range of use
04
0.38 - 0.40 mm
0.015 - 0.016 in
05
0.46 - 0.56 mm
0.018 - 0.022 in
06
0.60 - 0.64 mm
0.023 - 0.025 in
07
0.70 - 0.78 mm
0.028 - 0.031 in
08
0.80 - 0.82 mm
0.032 - 0.033 in
10
0.90 - 1.10 mm
0.036 - 0.044 in
12
1.14 - 1.27 mm
0.045 - 0.051 in
15
1.50 - 1.57 mm
0.060 - 0.063 in
16
1.60 - 1.63 mm
0.063 - 0.065 in
18
1.80 mm
0.073 in
THIS DOCUMENT CONTAINS CONFIDENTIAL AND PROPRIETARY INFORMATION THAT CANNOT BE USED, COPIED, DISTRIBUTED, REPRODUCED
OR PASSED TO ANY THIRD PARTY, IN WHOLE OR IN PART, WITHOUT WRITTEN AUTHORIZATION FROM JBC Soldering, S.L.
CONFIDENTIAL:
1:1
SCALE
ISO 2768-f
GSFXXD-B
DIMENSIONS IN
MILLIMETERS
DIN
RoHS
Compliant
GENERAL
TOLERANCES
A3
DRAWN BY
O. Vila
7309
3035
INSPECT. GUIDELINE
TECHNICAL DOC.
95677
No
23/03/2022
COMPATIBLE
DATE
PLANO COMERCIAL
SUBSTITUTES
GSFXX
DESCRIPTION
KIT GUIA SF Ø"X.X" -B
ADDITIONAL DESCRIPTION
PART NUMBER
DRAWING No.
GSF Guide Kit for SF280
without Solder Wire Perforation
5
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
