2 Scope of delivery
Bedienungsanleitung OSC Package User Guide OSC-Paket 05/2019 59
2 Scope of delivery
The OSC package needs a license and is delivered together with this User Guide in the
OSCPackage – Machine Connection license package, item no. [00117263-xx].
2 Scope of delivery
60 Bedienungsanleitung OSC Package User Guide OSC-Paket 05/2019
3 Prerequisites
3.1 Software Requirements
Bedienungsanleitung OSC Package User Guide OSC-Paket 05/2019 61
3 Prerequisites
The necessary system requirements for the OSC package correspond to the system requirements
for SIPLACE Pro and are described in the SIPLACE Pro Version Description,
item no. [00198612-xx] .
3.1 Software Requirements
The following software requirements must be met for the released features of R16-2:
●
SIPLACE Pro from Version 14.0 (R16-2)
●
Station software from Version 710.0 (R16-2)
●
SIPLACE Vision from Version 5.4.1 (R16-2)
The following software requirements must be met for the released features of R18-2:
●
SIPLACE Pro from Version 16.0 (R18-2)
●
Station software from Version 712.0 (R18-2)
●
SIPLACE Vision from Version 5.6.1 (R18-2)
The following software requirements must be met for the released features of R19-1:
●
SIPLACE Pro from Version 16.1 (R19-1)
●
Station software from Version 712.1 (R19-1)
●
SIPLACE Vision from Version 5.6.2 (R19-1)
3.2 Hardware Requirements
The following hardware requirements must be met for the released features of R16-2:
Function Hardware
Improved placement of snap-in components Placement heads: : Twin VHF
Smart Pin Support is recommended
Stereo Measurement for THT Pins Placement heads: CPP, TH, TH HF,
Twin VHF
Camera types: SST33, SST25
Customer-specific Pattern Features Placement heads: All
Special position evaluation Placement heads: All
Support to find best acceleration Placement heads: All
Increased placement force for Twin VHF placement
head
to 100 N
Placement head: Twin VHF
Can only be used with function status
-03!
Smart Pin Support is recommended
The following hardware requirements must be met for the released features of R18-2 :
Function Hardware
Improved placement of components with centering pins
(Pin in Paste height check)
Placement heads: CPP, TH, Twin VHF
Smart Pin Support is recommended
Improved teaching of snap-in components Placement head: Twin VHF
Stereo measurement for Gullwing and Pattern Fea-
tures lead group types
Placement heads: CPP, TH, TH HF,
Twin VHF
Camera types: SST33, SST25
Measurement parameter 4x image capture as option in
the stereo measurement
Placement heads: CPP, TH, TH HF,
Twin VHF
Camera types: SST33, SST25
Automatic illumination optimization for Non-standard
and Connector component types
Placement heads: All
