Harness parts list
KGA - 0108
No Part No. Part Name Q'ty Remarks No Part No. Part Name Q'ty Remarks
1 KM5-M661E-003 HNS,1-2 (QF11-TM11) 1 J3 39 KV6-M664G-002 HNS,CMN HEAD 1 J114
2 KM6-M661G-001 HNS,1-4 (TM11-TC11) 1 J4 40 KV7-M665A-001 HNS,5-1(PI N) 1 J121
3 KGA-M662E-010 HNS,TC11-QF,XT21 1 J11 41 KV7-M665E-001 HNS,5-2(PI R1,R2) 1 J122
4 KM6-M661J-000 HNS 1-6 (TM11-QF31) 1 J14 42 KGA-M665F-010 HNS,PI1B 1 J123
5 KM6-M661K-000 HNS 1-7 (QF31-NF11) 1 J15 43 KV7-M665G-000 HNS 5-4PI Z1,Z2,W) 1 J124
6 KV8-M661J-000 HNS 1-6(TM11-QF32) 1 J16 44 KV7-M665J-000 HNS 5-6(PI X,Z1,Z2) 1 J125
7 KGA-M662L-000 HNS,U11-U14 1 J17 45 KV7-M665H-000 HNS 5-5(Y-FLEX PI R, 2 J126,J127
8 KM6-M661L-000 HNS 1-8 (NF11-KM11) 1 J18 46 KV7-M665L-010 HNS,5-8(XFLEX PI) 1 J128
9 KV8-M661N-001 HNS,1-10(QF40-KM10A) 1 J19 47 KV8-M665K-000 HNS 5-7(X-BEAM,PI X) 1 J129
10 KGA-M662A-010 HNS,C/R POWER 1 J21 48 KV7-M665K-000 HNS 5-7(X-FLEX PI N) 1 J130
11 KGA-M667L-000 HNS,CONNE.-FAN 1 J22 49 KV8-M665M-000 HNS 5-9(PI W) 1 J131
12 KV8-M662G-000 HNS 2-4(CONNECT,CNF1 1 J24 50 KGA-M665G-000 HNS,BASE PUP 1 J132
13 KGA-M662H-020 HNS,EXT.POWER 1 J28 51 KGA-M665A-000 HNS,BASE Y1P 1 J133
14 KGA-M662R-010 HNS,SENSOR PWR 1 J30 52 KGA-M665E-000 HNS,BASE Y2P 1 J134
15 KGA-M662W-000 HNS,CNF41 LED POWER 1 J40 53 KGA-M665U-010 HNS,BASE(XP,ZP) 1 J135
16 KV8-M661U-003 HNS,CNF16 1 J41 54 KV7-M666A-000 HNS 6-1(MO N1,N2) 1 J141
17 KV8-M661V-000 HNS 1-14(PWR,HEAD I/ 1 J43 55 KV7-M666E-000 HNS 6-2(MO R1,R2) 1 J142
18 KV7-M661W-000 HNS 1-15(PWR,HEAD I/ 1 J44 56 KV8-M666F-002 HNS.M0 X,Y1,Y2,PU 1 J143
19 KGA-M662X-000 HNS,QF22-GS21 1 J47 57 KV7-M666G-000 HNS 6-4(MO Z1,Z2,W) 1 J144
20 KV7-M662Y-001 HNS 2-17(CONN,CNF21) 1 J48 58 KV8-M666H-002 HNS,6-5(Y-FLEX XM) 1 J145
21 KV8-M663A-002 HNS,3-1 (PWR,MTR) 1 J51 59 KV7-M666J-001 HNS,Y-FLEX ZRNM 3 J146,J147,J148
22 KU0-M663N-004 HNS,3-10 (CAPACITOR) 1 J52 60 KV8-M666L-001 HNS,X-FLEX ZM RM 2 J149,J150
23 KV7-M663M-000 HNS 3-9(CONNECT,CNF4 1 J58 61 KV7-M666K-001 HNS,6-7(X-FLEX NM) 1 J151
24 KG2-M663R-002 HNS 3-11 :J61/J62 2 J61,J62 62 KGA-M667G-000 HNS,CN8A INTERLOCK 1 J161
25 KV8-M663T-001 HNS SPEED CONTROL 1 J63 63 KGA-M667H-000 HNS,CN8B INTERLOCK 1 J162
26 KV8-M536E-100 HNS 302 2 J71,J73 64 KGA-M667A-001 HNS,COVER LIMIT 2 J163,J164
27 KV8-M66L1-000 HNS 17-1(700) 1 J72 65 KGA-M667J-000 HNS,EMG SW 2 J165,J166
28 KH5-M536E-110 HNS 302 (FG 500 FLEX 1 J74 66 KGA-M667F-000 HNS,CNF48 EMG 1 J167
29 KK1-M664J-010 HNS,PE 1000 5 J77,J78,J79,J80,J89 67 KGA-M667E-000 HNS,CNF35-CN6A 1 J168
30 KM6-M66L2-030 HNS,PE 1600 1 J81 68 KV8-M662N-002 HNS,CONNECT CNF10 1 J170
31 KG2-M536A-220 HNS,PE 150 6 J83,J84,J85,J86,J87,J88 69 KV8-M662R-001 HNS,2-11(OT,HEAD) 1 J171
32 KM0-M536A-010 HNS,PE 70 2 J90,J91 70 KV6-M662T-000 HNS 2-12(OT,HEAD) 1 J172
33 KGA-M664A-001 HNS,I/O1 CMN 1 J101 71 KGA-M662J-020 HNS,CNF15 MSP 1 J176
34 KV8-M664F-000 HNS 4-3(CMN,I/O AB) 1 J102 72 KGA-M668F-102 HNS,FRONT OPE.SW 1 J181
35 KGA-M664E-001 HNS,I/O2 CMN 1 J103 73 KGA-M669V-010 HNS,SWITCH ACTIVE 1 J183
36 KG2-M669R-110 HNS 9-11 (BUZZER) 1 J109 74 KGA-M669V-110 HNS,SWITCH READY 1 J184
37 KV8-M664J-000 HNS 4-6(I/O CMN Y-FL 1 J108 75 KGA-M669V-220 HNS,SWITCH START 1 J185
38 KW3-M668H-001 HNS,FDD 1 J110 76 KGA-M669V-301 HNS,SWITCH STOP 1 J186
PAGE 25
Harness parts list
KGA - 0108
No Part No. Part Name Q'ty Remarks No Part No. Part Name Q'ty Remarks
77 KGA-M669V-401 HNS,SWITCH ERROR CLR 1 J187
78 KGA-M669V-510 HNS,SWITCH RESET 1 J188
79 KW3-M66GW-001 HNS,NEXT INTERFACE 1 J201
80 KG2-M669G-010 HNS,9-4 1 J202
81 KV8-M669N-002 HNS,DO CONNECTION 1 J203
82 KGA-M669T-010 HNS,CN16A DO 1 J204
83 KGA-M669J-050 HNS,CN15B DO 1 J205
84 KV8-M669E-000 HNS 9-2(PATLITE) 1 J219
85 KGA-M668J-060 HNS,CNF30 GATE 1 J220
86 KW7-M668N-001 HNS,INTERFACE IN 1 J221
87 KW3-M66GX-001 HNS,PRE.INTERFACE 1 J222
88 KGA-M668A-010 HNS,CN3A DI 1 J258
89 KV8-M668F-002 HNS,8-3(DI,DUMP 1/2) 2 J251,J255
90 KGA-M668E-020 HNS,CN1A DI 1 J252
91 KV8-M668G-XXX HNS,DI DUMP SEL. 2 J253,J257
92 KV8-M668G-200 HNS,8-4(DI,DUMP 3/4) 2 J253
93 KV8-M668G-200 HNS,8-4(DI,DUMP 3/4) 1 J253,J257
94 KGA-M668K-000 HNS,CN4A DI 1 J254
95 KV8-M668M-011 HNS,NOZZLE STATION 1 J256
96 KGA-M669F-010 HNS,USB1 1 J270
97 KGA-M669E-010 HNS,MSP IN 1 J271
98 KGA-M669H-110 MSP SHORT ASSY 1
99 KGA-M669H-010 HNS,MSP SHORT 1
100 KGA-M13E1-001 MSP CHAIN 1
101 KH1-M13E2-000 BALL CHAIN 1
102 KH1-M13E3-000 TERMINAL 2
103 KH1-M13E4-000 STAINLESS W RING 1
104 KV7-M66A2-003 HNS,10-2(DI,HEAD) 1 J301
105 KV7-M66A3-011 HNS,10-3(VALVE,HEAD) 1 J302
106 KV7-M66A4-002 HNS,10-4(DI HEAD) 1 J303
107 KV7-M66A5-003 HNS,10-5(DI,VAC) 1 J304
108 KV7-M66A7-002 HNS,10-7(FID) 1 J306
110 KM6-M66M1-201 HNS,TAP CHANGE 1 J609
111 KM6-M66M4-001 HNS 18-4 (JUMPER) 3 J612,J613
109
J601, J602, J603, J604,
J605, J606, J607, J608
10HNS,TAP CHANGEKM6-M66M1-101
