6.1.3 Multi-Tray Unit (MTU-8E and MTU-9E) (Optional)
Two models of MTU are available to supply parts from trays. The MTU-8E, in
which trays are positioned in the 50 available shelves in the magazine, and the
MTU-9E in which up to 8 trays can be stacked in each of ten extractable drawers.
A reject parts conveyor will be fitted to one side of the MTU-8E/9E, which can
handle parts up to 74 x 74 mm with heights of up to 25.4 mm.
• Up to 100 different part types can be supplied by loading two trays side by
side on each shelf.
• Trays with a total width (including part height) of 7.8 mm or more can be
handled by removing the shelf directly above.
• Up to 20 different part types can be supplied by loading two stacks of
smaller trays onto each shelf.
Tray size (mm)
Parts variation
Pitch (mm)
Tray height (mm)
Max. loading weight per shelf (kg)
335 x 330
10 types
160 x 330
20 types
32
4 – 32
Max. 240
Max. 4.0
MTU-9E
Weight of empty trays (g)
QP3S019
Tray size (mm)
Parts variation (50 levels)
Pitch (mm)
Tray height (mm)
Max. loading weight per shelf (g)
335 x 330
50 types
160 x 330
100 types
10
4 – 25
Max. 400
MTU-8E
QP3S018
Max. 7.8 at a pitch of 10 mm
– 13 – QP-341E-MM/QP-351-MM Specifications
Preliminary (January 10, 2000)
6.1.4 Nozzles (Optional)
Three single nozzles are selected as required from the nozzles held in the nozzle
station.
Nozzle types (Scheduled)
Notes: Contact Fuji for details of support for nozzle types other than those listed in the
table above.
Fuji carries out in-house testing for the handling of connectors. Parts for
testing are required for appraisal by Fuji.
The nozzle information in the table above is derived at in the following manner.
6.1.5 Special Nozzles and Mechanical Chucks (Optional)
• Used to handle parts such as connectors that cannot be handled with
regular nozzles. For details, contact your Fuji representative with the
following information.
• Sample and detailed illustrations of the parts to be handled.
• Packaging information (reel, stick, tray etc.)
• Mounting history
– 14 – QP-341E-MM/QP-351-MM Specifications
Preliminary (January 10, 2000)
6.1.6 Single Tray Unit (STU-1/2) (Optional) (Under Development)
A Single Tray Unit is mounted on an MFU-6E or PFU-3E to supply tray parts.
The STU requires a separate air and power supply.
#1: Attached at the front side on the QP-341E.
6.1.7 Reject Parts Conveyor (Optional)
A reject parts conveyor is installed on MFU-6E or PFU-3E. (It can also be
installed at QP-341E fixed side.) Two models of conveyor are available: MFU-6E
type and PFU-3E type. Select an M or L size unit depending on the parts being
handled.
QP3S024
Size
M
L
Belt width
33.4 mm
78.0 mm
Part size
27 x 27 – 31 x 31 mm
74 x 74 mm
Feeder slots
3
7 (6)*
* The value in parentheses indicates the number of slots taken up if a reject parts
conveyor is used with an STU.
QP3S022
Supply unit
Tray size (mm)
Tray stack
height (mm)
Stack number
Empty tray
weight (g)
Slots occupied
Max. no. of units
Machine side
STU-1
MFU-6E
100 x 150 to
150 x 330
4 to 50
Up to 240
9
2
Rear
STU-2
MFU-6E
50 x 50 to
102 x 102
4 to 50
Up to 240
7
3
Rear
STU-4
MFU-6E
STU-7
MFU-3E
2-inch tray
50.8 x 50.8
50
4
6
Front/rear
STU-5
MFU-6E
STU-8
PFU-3E
4-inch tray
101.6 x 101.6
25
7
3
Rear
STU-6
MFU-6E
STU-9
PFU-3E
JEDEC tray
135.9 x 322.6
40 (thin)
25 (thick)
9
2
Rear
#1
#1
