Finger Conveyor = (M)
Roller Conveyor = (R)
Pin Chain Conveyor = (K)
11
Selective Soldering Nozzles
Nozzle height with variable Z-Axis Nozzle height with variable Z-Axis
ECOSELECT 1
≤ 90 mm (M) ≤ 57 mm (M)
SMARTFLOW
≤ 75 mm (M) -----
ECOSELECT 2
≤ 75 mm (K) ≤ 57 mm (K)
VERSAFLOW 3
≤ 85 mm (R) ≤ 57 mm (R)
ECOSELECT 4
≤ 85 mm (R) ≤ 85 mm (R)
VERSAFLOW 4
≤ 85 mm (R) ≤ 85 mm (R)
ECOCELL
≤ 85 mm (R, K) ≤ 57 mm (R, K)
Height 90 mm, B16,1
Height 85 mm, B16,1
S NOZZLE 4,0/8,0; H=85; B16,1
138145 1 Pcs.
S NOZZLE 4,0/8,0; H=85; B16,1
184677 1 Pcs.
S NOZZLE 4,0/8,0; H=90; B16,1
162216 1 Pcs.
S NOZZLE 4,3/8,0; H=90; B16,1
168373 1 Pcs.
S NOZZLE 6,0/10,0; H=90; B16,1
162195 1 Pcs.
S NOZZLE 6,2/10,0; H=90; B16,1
168446 1 Pcs.
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
12
Figure Description Order No.
High temperature cain oil
LUBCON - special oil, Turmofluid 40B,
0,4 l Spraycan
6XOEL24-0.4S
LUBCON - special oil, Turmofluid 40B,
0,5 l bottle
6XOEL24-0.5
LUBCON - special oil, Turmofluid 40B,
1,0 l bottle
6XOEL24-1.0
High temperature grease UH1-96-402
delivery in tubes with 80 g
171146
OKS 250 Metal-free multi paste 250 g
Lubrication of toothed bars of width
adjustment, splined shafts and
separating agents for screws in the
hot area
210939
Lubrication set OKS 250 paste
tube 80 g and 5 lube brushes
- unsuitable by direct contact with
solder
211218
OKS 250 Metal-free multi paste 80 ml
unsuitable by direct contact with
solder
216540
Grease TAS-WT till 1400 °C - 100 g tube
LUBCON - special lubricant, TURMO-
PAST TAS WT, paste without dropping
points. Temperature application range
-30 °C up to +1400 °C (higher tahn 200
°C: the paste turns to a dry lubrication)
28444
Spindle grease, 50 g
NBU 15 for lubrication of the shaft
from the z-axis (Flex and dipmodul)
in selective and wave soldering
machines
210860
Grease gun filled w. Isoflex NBU15
contain 50 g grease
210996
Lubrication set Isoflex NBU15
tube 50 g and lube brush
214163
Grease Klueber Microlube GL 261 40 g
Lubrication of linear track with high
stress
210862
Lubricants & Cleaning Products
Figure Description Order No.
Pencil for grease
211209
Grease gun
Pressol plunger push press with cup-
ped and pointed adapter, connection
thread M10x1 size 80 cm³ AD43 mm
L = 140 mm
92159
High temp. grease Barrierta tube 50 gr.
for filling the high temperature
bering 6LAP40-15FD-T
163081
Lubricants Lubricants
Cleaning Products
Figure Description Order No.
ESD-Cleaner 1 l
for cleaning of ESD- slices - not
suitable for acrylic slices
211125
Reinigungsset Acrylscheiben + ESD Folie
ESD - cleaner with mircofiber high
ressistance cloth
211214
cleaning cloth vermop-Softy
for cleaning of acrylic glass slices in
machine covers in conjunction with
cleaner 211125
211207
Cleaning cloth for sprayheads
cleaning clothes lint-free, 100x100
17231
Syggol Cleaner in 5 l CAN
Cleaner for high contamination espe-
cially in reflow- and wave soldering
machines.
302619
Needle for cleaning 130-270 micro nozzle
for sprayhead of the versaflow and
ecocell selective soldering machine
78722
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
13
Figure Description Order No.
Flux IF 2005M
1,8 % solid content
suitable for wave soldering leaded and lead-free
10 l Can
4FMJF2005-10
25 l Can
4FMJF2005-25
200 l Barrel
4FMJF2005-200
Thinner IF TT2005M
Thinner for IF 2005M
10 l Can
4HMTT2005-10
25 l Can
4HMTT2005-25
Flux IF TS15
1,5 % solid content, foamable
10 l Can
4FMJFTS15-10
25 l Can
4FMJFTS15-25
200 l Barrel
4FMJFTS15-200
Thinner E3226
Thinner for IF TS15 and IF TS18
5 l Can
4HMVER-5
20 l Can
4HMVER-20
Flux RA200 5 l Can
4,5 % solid content; halogen free
activated; no resins contained
4FMRA200-5
Flux RA201 5 l Can
2 % solid content; halogen free
activated; no resins contained
4FMRA201-5
Thinner for Flux RA201, 5 l can
4HMVER201-5
Flux IF 2005K
2,5 % solid content; suitable for wave soldering lead-free and
selective soldering leaded
1 l Bottle
4FMJF2005K-1
10 l Can
4FMJF2005K-10
25 l Can
4FMJF2005K-25
Flux IF 2005C
3,4 % solid content; suitable for selective soldering leaded
and lead-free
1 l Bottle
4FMJF2005C-1
10 l Can
4FMJF2005C-10
25 l Can
4FMJF2005C-25
Flux
Figure Description Order No.
Flux IF 2009 MLF
3,6 % solid content; ultralow solder balling; suitable for wave-
and selective soldering
1 l Can
4FMMLF2009-1
10 l Can
4FMMLF2009-10
Flux Pacific IF 2009M
3,7 % solid content; low residue high compatibility with con-
formal coating; suitable for wave- and selective soldering
1 l Bottle
4FMJF2009-1
10 l Can
4FMJF2009-10
25 l Can
4FMJF2009-25
Flux Pacific IF2009
2,5 % solid content
10 l Can
4FMJF2009-2.5-10
25 l Can
4FMJF2009-2.5-25
Flux Pacific IF 2010F
2,5 % solid content; low residue high compatibility with con-
formal coating; suitable for wave soldering and foam contract
1 l Bottle
4FMJF2010-1
10 l Can
4FMJF2010-10
Flux IF 2040
6,5 % solid content; low residue high conpatibility with con-
formal coating; suitable for selective soldering
1 l Bottle
4FMJF2040-1
10 l Can
4FMJF2040-10
25 l Can
4FMJF2040-25
Low Residue - No-Clean Flux Water Based Flux
Flux for special applications
Figure Description Order No.
Flux GR8 5 l Can
14,5 % solid content; halogen free
activated; resins contained
4FMGR8-5
Flux R8 5 l Can
15 % solid content; activated with
organic halogens; resins contained
4FMR8-5
Thinner E3226
5 l Can
4HMVER-5
20 l Can
4HMVER-20
