Solder Frames

Figure Description Order No.

Center bar, length 420 mm

for solder frame with 420 mm length

4DKLE0-420-000

Center bar, length 500 mm

for solder frame with 500 mm length

4DKLE0-500-000

Center bar stainless steel,length 600 mm

for solder frame with 600 mm length

4DKLE600

Clamping clip 130 mm 6 finger, (SS)

clip for center- and sidebar to rivet

6IN127

Clamping clip 65 mm, 3 finger (SS)

clip for center- and sidebar to rivet

6IN126

Blind rivet 4,0x4,9AL5 K. BER. 1,6 - 2,9

rivet for rivet on the clamping clip

6IN126 and 6IN127

6NI4.0X04.9B

screw-star handle M4x16 (SS)

for the clamping assembly of the Ersa

center- and sidebar

29548

Figure Description Order No.

Support profile

Support profile front left

6IN512-0

Support profile front right

6IN513-0

Support profile back right

6IN526-0

Support profile back left

6IN527-0

Profile for segmented conveyor

profile (VL)

118115

profile (VR)

118119

profile (HL)

118121

profile (HR)

118123

Movable support rail

for supply of PCBs in Ersa soldering frame

330 mm working width

4ZH-330

400 mm working width

4ZH400

500 mm working width

4ZH500

Rail for Soldering frames

Like 4ZH-330 - only rail

330 mm working width

6ISK275-02

400 mm working width

6ISK275-03

500 mm working width

6ISK275-04

Mounting plate

for movable support. One sided PCB

holder

6IN490

Center mounting plate

for movable support. two sided PCB

holder

6IN490-1

Sidebar

length 420 mm

4KLE00-420-000

length 500 mm

4KLE00-500-000

length 600 mm

4KLE00-600-000

Spare Parts, 330 mm - 500 mm working width

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

Figure Description Order No.

Leak detection spray, 400 ml can

6ZT-SPRAY02

Epoxy glue Art.Nr. 071045600

2 components glue for examplfe

for fixing the thermal sensor on the

measurement board

6X00034

Spray 400 ml Molykote dry slide film

for lubrication at demandng sliding

applications. Temperature range .-

185 to +450 °C. not secreting resin,

high pressure resistance, ageing

resistance

77781

Antifreeze can 30 Liter

for use in cold water - cooling

circulation as Algizid, antifreeze and

corrosion protection

6ZT00167

adipic acid in 1 kg can

powder for nozzle activation of wet-

table selective nozzles

89593

SILIC ADHESIVE E43 TUBE 90 cm3

high temperature silicon glue up to

180 °C

6X00028

Solder wire SnAg3,8Cu0,7 ø 2 mm, 4 kg

50273

Solder Wire Sn63Pb37 ø 2 mm, 4 kg

61662

Solder wire SN100CE-SnNi Dia. 2 mm 4 kg

104134

Solder wire LF Sn96,5Ag3Cu0,5 D 2mm 4 kg

120268

Auxiliaries and Supplies

Auxiliaries and Supplies Auxiliaries and Supplies

Auxiliaries and Accessories

Figure Description Order No.

Filter case AN111.01 screwings NW3

filter housing for the residual oxygen

of different Ersa soldering machines

6FIL-HL-01

Filter cartridge, activated carbon

for the use in the filter hosuing

6FIL-HL-01 for the residual oxygen of

different Ersa soldering machines

6FIL-HL-ZT01

O-Ring for Filter 6FL-HL-01

for the transparent plunger of the

filter housing 6FIL-HL-01

6FIL-HL-ZT02

Figure Description Order No.

Reference Fixture

measurement and calibration board

for Ersa selective soldering machines.

390x 480 mm

6ISK47955141

Reference Fixture 350x350

measurement and calibration board

for Ersa selective soldering machines.

350x 350 mm

203532

Glass plate to verify Wave Set-Up

in order to measure the wetting

length Dimensions: 240 x 325 mm

4ZBGS0240x325

Glass plate to verify wave setup

Size: 380 x 380 mm. Suitable for any

wave soldering machine. Made of

high temperature glass with 10 mm

grid spacing.

4ZBGS0380x380

Glass plate, heat resistant

Grid 300 x 300, black edge for

conveyor of selective solderinge

machines

84584

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

Figure Description Order No.

All purpose pin puller

for cutting the conveyor chains

6ZT00187

Chain rivet remover

for chains with plunger diameter over

3 mm

6ZT00189

Service and Maintenance Trolley

for Wave-/ Multiwave-/ and Dip

Soldering machines. Service trolly

Including special lead-free coated

surfaces.

100388

Mounting sheet for tools

tool holder for keeping the soldering

pot cleaning tools

100387

Solder mould

aluminum bowl for keeping solder

during the exhaust of the soldering

pot

247629

Tool for gasification ring

for opening the gasing caps of the

Ersa soldering machines

243303

Key for control panel

electrical cabinet key

6VERSCHLÜ2531

Wrench for switch-cupboard

square key for opening special doors

252141

Lock three.corner part 7 mm 2545.000

triangle key for opening special doors

6VERSCHLÜ2554

Auxiliaries and Supplies

Auxiliaries and Accessories

Figure Description Order No.

Light metal precision level

for diverse adjustments

208659

Cleaning brush stainless steel

brush piece 100x 20 mm for example

to cleaning the wettable selective

nozzles

213024

Mould for alloy analysis

for delivery of the tin testing to ersa

in standardized form / size

6ISK714-05A

Pressing tool

for pressing dowl pins in nozzle

locking shafts

109687

Protective gloves (pair)

heavy, fleecy quality

men

127380

women

127382

Service gloves (pair), size M

for the hot area

6HDSGLGEW-289

Cover

cover without cut-out

233401

trape single pot without fluxer

253569

Cover cloth f. single pot with fluxer

253570

Drape Z varia without fluxer

253483

Drape Z-varia with fluxer

253484

cover cloth y viara without fluxer

253581

cover cloth y viara with fluxer

253582
