Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
22
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
22
Figure Description Order No.
All purpose pin puller
for cutting the conveyor chains
6ZT00187
Chain rivet remover
for chains with plunger diameter over
3 mm
6ZT00189
Service and Maintenance Trolley
for Wave-/ Multiwave-/ and Dip
Soldering machines. Service trolly
Including special lead-free coated
surfaces.
100388
Mounting sheet for tools
tool holder for keeping the soldering
pot cleaning tools
100387
Solder mould
aluminum bowl for keeping solder
during the exhaust of the soldering
pot
247629
Tool for gasification ring
for opening the gasing caps of the
Ersa soldering machines
243303
Key for control panel
electrical cabinet key
6VERSCHLÜ2531
Wrench for switch-cupboard
square key for opening special doors
252141
Lock three.corner part 7 mm 2545.000
triangle key for opening special doors
6VERSCHLÜ2554
Auxiliaries and Supplies
Auxiliaries and Accessories
Figure Description Order No.
Light metal precision level
for diverse adjustments
208659
Cleaning brush stainless steel
brush piece 100x 20 mm for example
to cleaning the wettable selective
nozzles
213024
Mould for alloy analysis
for delivery of the tin testing to ersa
in standardized form / size
6ISK714-05A
Pressing tool
for pressing dowl pins in nozzle
locking shafts
109687
Protective gloves (pair)
heavy, fleecy quality
men
127380
women
127382
Service gloves (pair), size M
for the hot area
6HDSGLGEW-289
Cover
cover without cut-out
233401
trape single pot without fluxer
253569
Cover cloth f. single pot with fluxer
253570
Drape Z varia without fluxer
253483
Drape Z-varia with fluxer
253484
cover cloth y viara without fluxer
253581
cover cloth y viara with fluxer
253582
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
2323
Ersa product portfolio
Screen & Stencil Printer
VERSAPRINT screen printing systems with fully
integrated in-line post print inspection offer
unique cost and technology benefits. The revolu
-
tionary LIST camera offers an inspection beyond
compare: detection of paste on pad , print offset,
bridges and stencil blockages in in-line speed.
Reflow Soldering
Ersa reflow soldering systems convince by their
extraordinary thermal performance, highest ma-
chine availability and low operating costs. The Ersa
HOTFLOW 4 series has mastered to significantly
reduce the energy and N2 consumptionon a com-
parable performance level
Selective Soldering
As technology leader Ersa delivers perfect solu-
tions for all selective soldering tasks: the scope
of configurations ranges from start-up to high-
end, from inline to cell production, from single to
multi wave soldering and from highest flexibility
to highest throughput and make the VER-
SAFLOW, ECOCELL and ECOSELECT systems the
ideal match for the demands of the users.
Wave Soldering
The cost-benefit ratio of wave soldering is still
outstanding. But the demands of the users differ
widely. Therefore Ersa offers an extensive range
of individually configurable systems, from basic
to high-end.
Automation
Ersa presents the collaborative ROBOPLACE, an
innovative automation solution based on a flexible
2-arm technology, which lifts the inline production
of PCBs for industry and automotive to the next
level.
Rework
For more the a decade more then 5000 users all
around the world benefit from the patented Ersa
IR rework technology. Besides their excellent
cost-benefit-relation Ersa systems have conque
-
red their leading market position for their out-
standing results even in demanding rework tasks.
Inspection SMT / BGA
No matter if a reworked BGA needs to be inspec-
ted or the parameters of a production line need
to be verified – ERSASCOPE inspection
systems for the damage free inspection of
covered solder joints have become the standard
in electronic productions.
Soldering and Desoldering
Ersa soldering and desoldering stations impress
by their compact size, high performance, energy
efficiency and low operating costs, since inex-
pensive exchange soldering tips are used. Being
the i-CON family’s flagship it offers the user 4
tools to master demanding soldering applica-
tions.
Services/Employer Trainings
Beside the broad product range Ersa offers
comprehensive services like employer training
and qualification, machine and production process
audits, maintenance contracts, ramp-up support,
machine capability studies or online spare part ca-
talogues. Tell us your needs - we find the
solution!
Solders, Solder wires & Fluxes
All about soldering - supplied by one source:
beneath special tools, soldering tools and tem-
perature measuring devices Ersa also offers
operating supplies for the production and repair
of PCBs. Ersa solder wires contain only high qua-
lity raw materials and are manufactured
according to most modern standards to meet
all quality requirements.
Solder Fume Extraction
Ersa solder fume extractions are the efficient
and economic way to ensure clean PCBs an he-
althy breathing air. The big nozzles, which are
available in different shapes, efficiently extract
the solder fumes of an entire workspace.
Ersa Webshop
The Ersa Webshop offers spare and wear parts for
Ersa soldering machines as well as tools, rework-
and inspection systems.
Always up to date and
available 24/7!
www.ersashop.com
Ersa GmbH
Leonhard-Karl-Str. 24
97877 Wertheim/Germany
Phone +49 9342 800-0
Fax +49 9342 800-127
info@ersa.de
www.ersa.com
Production plants/
subsidiaries
Local agents
Other presence
Electronics Production Equipment
Presence in 135 countries
