Apply right amount of ACF Remover G540 on Glass, PCB and COF both sides. T o o less or too much is not working good. Don’t apply liquid on other part of them , because the liquid is corrosion, wil l dam age polarizer fil…

1. REMOVE SEALING GLUE

2. REMOVE COF FROM :

FIRST ON PCB SIDE

SECOND GLASS SIDE

REMOVE

SEELING

GLUE FROM

PANEL

REMOVE

COF FROM

GLASS SIDE

REMOVE

COF FROM

PCB SIDE

9 Panel Repair Factory India pvt. Ltd.

Apply right amount of ACF Remover G540 on Glass, PCB and

COF both sides. Too less or too much is not working good.

Don’t apply liquid on other part of them, because the liquid is

corrosion, will damage polarizer film or protection film.

Don’t touch the liquid with your finger or skin.

ACF REMOVER G 450 use for COF cleaning.

APPLY ACF

REMOVER

G450 FOR 10

to 15 SECONDS

ACF

REMOVER

G450

10 Panel Repair Factory India pvt. Ltd.

Panel Repair Factory India pvt. Ltd. 11

COF CLEANING WITH ACETON

Dip cotton buds in acetone

& COF clean only vertical

direction

Fold cloth on stick & dip in

acetone and COF clean

only vertical direction

Acetone
