Panel R epair F actory India pvt. Ltd. 7 A CF Bonding Pr ocess Check L CD/LE D P anel L CD/ LED P anel f ault mark R emov e C OF fr om PCB & IT O side Cleaning C OF , PCB & IT O Pr epar e C OF f or bo n…
Panel Repair Factory India pvt. Ltd. 6
In 1
st
image X3 COF is faulty & in 2
nd
image X2 COF is faulty.
CHECK PANEL FAULT BEFOR BONDING
X2 COF IS
FAULTY
X3 COF IS
FAULTY
Panel Repair Factory India pvt. Ltd. 7
ACF Bonding Process
Check LCD/LED Panel
LCD/LED Panel fault mark
Remove COF from PCB & ITO side
Cleaning COF, PCB & ITO
Prepare COF for bonding
Use acf bonding machine for bonding
Panel Repair Factory India pvt. Ltd. 8
REMOVE COF FROM PCB & GLASS SIDE
SMD RANGE-
TEMPRATURE-250 TO 300 °
AIR -4 TO 5
COF REMOVING
& HOT GUN
DIRECTION
