TYPE S330M / S168SW S168SA Weight 4 kg 7 kg Accessory Support wall 2 pcs Support pin 30 pcs Size 346(W) x 365mm(D) 465(W)x 540mm(D) LCF; Down Cut; Carbide end mills Overall Length (A): 38.2 ±0.30 mm Shank Diameter (B): 3…

Type

YSF-V553 YSF-V553 ZETA YSF-V605

Dimensions (WxDxH)

665x635x1610mm 930x855x1000mm 780x665x1900mm

Weight

180 kg 174 kg 242 kg

Power supply

3 phase 50Hz / 60Hz 220V

2.2 kw 3.7 kw

Motor power

3 HP 5HP

Inlet wind speed

26 m/sec 32 m/sec 28 m/sec

Inlet wind capacity

28 m³/min 28m³/min 35 m³/min

Inlet wind pressure

300 mm-Ag 1800 mm-Ag 380 mm-Ag

Inlet Diameter

150mm 127mm 150mm

Outlet Diameter

203mm 150mm 203mm

Cutting the static electricity of the dust generated by PCB

during routing to reduce the dust to attach to PCB and increase

the efficiency of Vacuum Cleaner.

YSF vacuum cleaner is designed for γ-S168 & γ-S330M to collect the dust &

scrap generated by router. High horse power motor & high efficiency fan

to ensure the suction with excellent efficiency.

YSF系列集塵器是專門用來收集

-S168/

-S330M 切割過程中的粉塵、碎片。內部使用

高馬力馬達及高效率風扇，集塵效率高，並可使切割中之粉塵附著產品情況減少到最低。

可消除粉塵所帶之靜電，有效減少附著及增加集塵效果。

YSFシリーズ集塵機は、γ-S168及びγ-S330M機種の切断粉塵や破片を集塵する清掃機。

ハイパワモータと高性能ファンを使用しており、より確実な吸引清掃が可能。

粉塵の静電気を除去し、PCBへの付着を減少させ、集塵

効率を向上させます。

Pin-Point Ionizer

YSF Series Vacuum Cleaner

Easy operation & programming.

Twin table to reduce the tact time.

Available in linear and circular cutting to diminish restrictions of PCB design.

Auto on/off function to save the power of vacuum cleaner.

(except for r-S168 DT)

Low cutting stress to avoid the PCB from cracking.

TYPE

S330M / S168SW

S168SA

Weight

4 kg 7 kg

Accessory

Support wall 2 pcs

Support pin 30 pcs

Size

346(W) x 365mm(D) 465(W)x 540mm(D)

LCF; Down Cut; Carbide end mills

Overall Length (A): 38.2 ±0.30 mm

Shank Diameter (B): 3.175 mm

Cutting Length (C): 6 ±0.50 mm

Cutting Diameter (D): 1.00 1.20 1.50 1.60 2.00 mm

Fit majority PCB sizes and shapes which reducing the

species of specific jig to save the expense of tooling.

The customized jig could meet kinds of requirement

from customer to provide precision and efficiency

routing.

萬用治具可以調整搭配大部分PC板使用，如此可以減少治具的開發

費用及時間。

可依照客戶要求，製作客製化專用治具，並能提高

切割精度及效率。

多様な基板サイズ、形状に対応可能。専用治具の数を減らし、経費

削減になります。

お客様の要望に応じて、カスタマイズ治具を製

作可能。

AV AILABLE SIZE:

Ø 1.0 Ø1.2 Ø1.6 Ø2.0

支柱

Support Pin

SIZE:

Ø 1 ~ Ø2 mm

銑刀

Router Bit

活動支撐座

Pin Supporter

Universal Fixture

Customized Jig (Option)

Single Table PCB Separator

1 station

X:600mm Y:600mm Z:60mm

Top side:15mm, Bottom side:45mm

0.5 ~ 2mm (It’s necessary to contac

Aurotek in advance for over 2mm )

Ø1 ~ Ø2 mm (Option: over Ø 2mm )

±0.1mm

±0.02mm

3(X,Y,Z)

X, Y: 750mm/sec Z: 325mm/sec

X, Y, Z: 100mm/sec

(it’s according to the speciﬁ cation

Bit for the best speed setting)

High speed variable frequency mot

150W(Max. 58,000rpm)

Linear, Arc, Circular, U-curve, L-curv

3 axes (AC Servo motor)

Max.2 sections

Direct coordinate input or manual g

with 10X CCD camera

Standard

Windows XP

HDD

USB

TFT monitor + keyboard + mouse

Manual

3-Phase AC220V±5℅ 50/60Hz

[3HP Vacuum included]3kw,11A

Dry air 0.5 Mpa

1124x1939x1343+587mm (Signal To

794kg

90cm±5cm

Twin Table PCB Separator

2 stations

X:330mm Y:330mm Z:15mm

Top side:15mm, Bottom side:45mm

0.5 ~ 2mm (It’s necessary to contact

Aurotek in advance for over 2mm )

Ø1 ~ Ø2 mm (Option: over Ø 2mm )

±0.1mm

±0.01mm

±0.02mm

4 (X,Y1,Y2,Z)

X, Y1,Y2: 1,000mm/sec Z: 750mm/sec

X, Y, Z: 100mm/sec

(it’s according to the speciﬁ cation of

Bit for the best speed setting)

High speed variable frequency motor,

150W(Max. 58,000rpm)

Linear, Arc, Circular, U-curve, L-curve

4 axes (AC Servo motor)

Max.2 sections

Direct coordinate input or manual guiding

with 10X CCD camera

Standard

Windows XP

HDD

USB

TFT monitor + keyboard + mouse

Manual

3 Phase AC220V±5℅ 50/60Hz

[3HP Vacuum included]3kw,11A

Dry air 0.5 Mpa

1190x1039x1401+535 mm (Signal Tower)

390kg

90cm±5cm

Desktop PCB Separator

1 station

X:330mm Y:330mm Z:70mm

Top side:15mm, Bottom side:45mm

0.5 ~ 2mm (It’s necessary to contact

Aurotek in advance for over 2mm )

Ø1 ~ Ø2 mm(Option: over Ø 2mm )

±0.1mm

±0.02mm

3 (X,Y,Z)

X, Y:500mm/sec Z: 100mm/sec

X, Y, Z: 100mm/sec

(it’s according to the speciﬁ cation of

Bit for the best speed setting)

High speed variable frequency motor,

150W(Max. 58,000rpm)

Linear, Arc, Circular, U-curve, L-curve

3 axes (AC Servo motor)

Max.2 sections

Dedicated Board Computer

EEPROM

USB

TP-104E

Manual

Single phase AC220V±5% 50/60Hz

(vacuum excluded) 1.5kw, 6A

Dry air 0.5 Mpa

670x840x840mm

118kg

120cm±5cm

Setting Fixture

Working Area

Component Height

PCB Thickness

Routing Bit Diameter

Precision of Cutting

Positioning Accuracy

Positioning Repeatability

Number of Axes in use

Driving Speed (Max.)

Cutting Speed (Max.)

Spindle

Cutting possibilities

Motor of Axes

Routing Bit Sectioning

Route Planning

Safety Area Sensor

Tool Break Detection

Operating System

Program Storage

Program Backup

Man-Machine Interface

Conveyor Adjustment

PCB Loading/Unloading

Power Supply

Air

Dimensions (W x D x H)

Weight (approx.)

Working Hight
