ASYMTEK Vantage® Series Spares List

April 2024 9

TIE WRAP,8"RED

4

6104881

GROMMET, "U" CHANNEL, .062"

1

6126527

FITTING, UNION ELBOW, 1 TOUCH,

1/4"

4

6138258

FITTING, UNION ELBOW, 1

TOUCH,1/4"-5/32"

2

6138261

TUBING,PU,CLR 1/4"OD 1/8"ID

5

7242264

CLIP,CABLE.19-.31

OD,BAND,ORNGE

1

7297106

TIE WRAP, 20", 120 LB.

4

7279071

KIT, LHS, UE, VTG

7297113

ASSY,uEPSILON LHS,ILD1420(203)

1

7294336

MOUNT PLATE, LHS

1

7290914

BRACKET, COVER, LHS

1

7290922

COVER,QUARTZ,LHS,SHIELD,32mm

1

7254822

SCREW, M3 X 0.5 SOCKET X 6

2

387979

SPACER,M2.5X2,

M4.5OD,ALUMINUM

2

6127673

ASSY, X1 MOTOR SUPPORT

7290975

MOUNT,X MOTOR FORCER

1

7287359

ASSY,MOTOR,LINEAR,X

1

7287577

SCREW, M4 X 0.7, SOCKET X 10

6

388027

LABEL,SELF LAMINATING 1X2.25"

2

7216610

ASSY,Z2 HEAD,TESTED

6141757

Z2-HEAD,VANTAGE

1

7287344

ASSY,DISP. COVER,VTG

6146765

COVER, SENSOR, VANTAGE,

CLEAR

1

6110171

INSERT,COVER,L-U CAMERA

1

6115910

COVER, DUAL DISP,CLEAN RL,NO

VAC, VANTG

1

6139162

LABEL, HOT SURFACE

1

7207207

MIRROR, LOOKUP DISPENSE

1

7297047

SCREW, NYLON M3 X 0.5 X 6 FLAT

2

7297048

ASSY,LIFT TABLE,S-9XX

7217641

PLUG, NYLON LIFT MODULE

ENCAP

1

7244649

PIN,LOCATING,LIFT TABLE

2

7213303

SCREW,FLAT,M10X1.5X25MM,SOC,

SS

1

193847

NUT PLATE,LIFT TABLE

1

193854

TUBING,170ID X .250OD,POLYURE

1

6126523

FITTING,1/8MNPT X QD CPC

1

392795

BLOCK, PILLOW, 3/8 ADJUSTABLE

1

381634

ELBOW,90 SWIV.-1/8TUBEX1/8 NPT

2

387424

FITTING, 1/8NPT STREET ELBOW

1

382969

UNION, 1/4" Q-DISC.

1

382989

GREASE, USDA-H1, NLGI-2

1

382186

SCREW, M3 X 10MM, SOCKET CAP

4

387981

SCREW, M3X.5X16 SOCKET HEAD

2

387983

SCREW,M3X20,SOCK.HD.CAP,SS

2

387984

SCREW M5X20MM FLAT H.

PHILLIPS,SS

4

7244126

SCREW,M5X.8X8 SHCS

1

7245989

SCREW, M5X0.8, SOCKET CAP, X12

4

388065

SCREW, M5X20MM SHCS SS

4

7243426

SCREW,M5-08X25 SOCKET CAP

1

7242064

SCREW,M5-.8X10,SOC SET-CUP,SS

4

7275145

SCREW, M6X1.0, FLAT TIP SET,X8

1

7275156

SCREW,SET,CUP POINT,M6-

1X30,SS

1

7200457

GENERATOR, VACUUM

1

381764

PLATE,BASE,LIFT TBL,MOD,S-9XX

1

7217265

SPACER,BASE,LIFT TABLE

1

7218071

ROD,GUIDE,LIFT TABLE

1

7218073

ASYMTEK Vantage® Series Spares List

April 2024 10

BRKT,ANTI-ROT,LIFT TABLE

1

7218074

PLATE,TOP,LIFT TABLE

1

7218076

SHAFT,LIFT TABLE,20DIA X 106LG

1

7218078

BEARING,LINEAR,20MM,FLANGED

1

7218079

CYLINDER,FLAT,1.5"BORE,5/8"STR

1

7218080

BLOCK,HT ADJUST,LIFT TABLE

1

7218081

FRU,7287578,ASSY,MOTOR,LINEAR,Y,VTG

6140577

ASSY,MOTOR,LINEAR,Y

1

7287578

ASSY,SOLENOID,4-WAY

7216036

PLUG-F,2P,CMT/LK

1

194711

VALVE, 4 WAY AIR, 24V

1

382933

MUFFLER, 10-32 UNC

1

382934

FITTING,UNION,10-32THD-1/8TUBE

2

387427

DIODE, SCHOTTKY, 1 AMP 40VOLTS

1

7275284

PIN,CMT/LK,14-20AWG,13A

2

7204650

HEATSHRINK,3/16",2:1,BLACK

1

6126525

HEATSHRINK,1/8",2:1,BLACK

1

7246623

HEATSHRINK,16MM,4:1,ADHESIVE

1

7243458

FITTING,ELB,10-32X1/4QD

1

7201541

Z2-CBL/PNEU CARRIER,VTG

7287345

ASSY, X2 MOTOR SUPPORT

1

7290976

TRAY,CABLE CARRIER RIGHT

1

7287586

ASSY,BULKHEAD,Z2,VTG

1

7290951

ASSY, CATTRACK HEAD2X , 19LINK

1

7290962

ASSY, CATTRACK HEAD Y , 27LINK

1

7290963

VERTICAL SEPARATOR E6-29

24

7290964

TIEWRAP PLATE, 8 TOOTH

2

7290965

TIEWRAP PLATE, 6 TOOTH

2

7290966

FULL WIDTH SHELF, 70MM , E6

10

7290967

FULL WIDTH SHELF, 80MM , E6

14

7290968

BRKT., CAT-TRACK, Y LARGE

1

7287507

MOUNT,Y CABLE

CARRIER,X2,RIGHT

1

7290960

CABLE,HALLS+R-ENCODER,Z-

HEAD

2

7287602

CABLE,Z-MOTOR EXTENSION

2

7287600

CABLE,SPARES DE09

1

7287593

CABLE,SYS PCA TO HEAD CTRL

1

7287595

CABLE,HEAD POWER 24V

1

7287605

CABLE-P,FIBER OPTIC,LC,3MM

1

7287606

CABLE,CAT,INTELLIJET

1

7287598

SCREW, M4 X 0.7, SOCKET X 10

4

388027

CABLE TIE,LOCK,NYL6/6

UVB,7.9"L,50LB,BLK

45

382864

ENCODER READHEAD,TONIC 5M

3

7287387

MOUNT,X CABLE CARRIER COMB

1

7290969

LABEL,SELF LAMINATING 1X2.25"

21

7216610

CABLE,CAT TRACK uE LHS

1

7294335

FITTING,1/4"-1/8"UNION Q/DISC

1

197669

SCREW,SHC,FLATHD,M4.0.7X8MM,

SS

7

7228081

CABLE TIE, FLAT

3

7243455

NUT,M5,HEX, W/TOOTH

2

7254144

LABEL,BLANK,SELF LAMINATE

26

7220555

HEX POST, D-SUB 4-40X3/16, SST

2

382564

TUBE,SPIRAL 0.25IN OD

0.023

195207

TIE WRAP,RED,15"

6

7269031

CABLE,GROUND WIRE 720MM

1

7297425

SCREW,M4X0.7X10MM,BUT HD,SS

3

7246519

SUPPORT,CAT TRACK,105MM WIDE

1

7297086

SCREW, M4X0.7 SOCKET FLAT X 10

4

7245171

STRIP,WEAR, X2,INSIDE, YE

2

6102147

STRIP,WEAR, X2,OUTSIDE, YE

2

6102148

STRIP,WEAR,Y,INSIDE,YE

2

6102149

STRIP,WEAR,Y,OUTSIDE,YE

2

6102150

ASYMTEK Vantage® Series Spares List

April 2024 11

INTERPOLATOR,TONIC,40MHZ

3

7298895

KIT,TUBE,CABLE CARRIER

1

7298344

TIE WRAP,8"RED

4

6104881

TIE WRAP,8"-BLUE

2

7297096

FITTING, UNION ELBOW, 1 TOUCH,

1/4"

4

6138258

FITTING, UNION ELBOW, 1

TOUCH,1/4"-5/32"

2

6138261

TUBING,PU,CLR 1/4"OD 1/8"ID

5

7242264

LENS ASSY,MONOCLE 0.5X,VTG

6116664

BRACKET,CO-AX LED,HR VIS,SR

1

7286002

LENS,ASPHERIC,10X6.6 MM

1

7254992

BUSHING,10MMX4MM

1

7254965

SCREW,M1.6X.35X5MM,SHCS

4

7275109

ASSY,LEDX1 ON-AXIS,SII VISION

1

7270704

COVER,CO-AX LED

1

7286003

SCREW,M2-0,4X6 SOCKET CAP

2

7275113

LENS, TELECENTRIC, 0.5X, CLOCK

1

6119665

SCREW, M3X.05 FLAT

2

392120

ASSY, LIGHT, OFF-AXIS,4X WHT

7290944

BUSHING,10MMX4MM

4

7254965

LENS,ASPHERIC,10X6.6 MM

4

7254992

ASSY,LEDX4 OFF-AXIS,VISION

1

7290943

BRACKET,LED LENS,HR VIS

4

7254976

PLATE,MOUNT,LIGHT BOX

1

7290916

SCREW,M2-0,4X6 SOCKET CAP

8

7275113

LUBRICANT, DRY FILM PASTE

1

382901

SCREW,M2X.40X6 FLTHD. PH. REC.

3

387957

SCREW, M3 X 0.5 SOCKET X 6

2

387979

TAPE,POLYIMIDE FILM 1",3M,36YD

1

7274911

CABLE TIE,4",BLACK

1

382767

BRACKET,LED RING

1

7297161

COVER,LED RING

1

7297162

ASSY,FAN SHELF

7290977

FAN SHELF,SM

1

7290978

SNAP,ESD FEMALE

1

7209416

JACK,BANANA,INSULATED BLACK

1

7257497

SCREW,M3-.5 PH FLAT X 12,SS

1

7243059

STRIP, TERMINAL 6 POS.

1

7257496

JUMPER, TERMINAL BLOCK

4

7259622

GUARD,FAN

3

7213259

SCREW,M4X0.7X35MM SHCS,SS

12

7265106

SCREW, M4 X 0.7, SOCKET X 10

4

388027

CLIP, WIRE HARNESS

7

387922

WASHER, FLAT M4

1

387998

WIRE,18AWG,STR,GRN/YEL,600V

0.25

7257505

DISCONECT,18-22AWG,.187X.020

1

7256274

TERMINAL RING, #6 22-16AWG

1

7256275

LABEL,PROTECTIVE GROUND

250/RL

1

7246625

BUSHING,SNAP,2IN

4

7216899

CABLE,DC POWER

1

7244667

ASSY,FAN 24V W/LEADS

3

6100934

LABEL,BLANK, FOR PLD

2

7275814

CABLE,DC POWER

1

7244506

SCREW,D M4X6,SS,SOC HEAD

7

7207192

LABEL,BLANK,COMPONENT,SMALL

3

7220558

CABLE,DC POWER

1

7244506

SCREW,D M4X6,SS,SOC HEAD

7

7207192

LABEL,BLANK,COMPONENT,SMALL

3

7220558

SPACER,#10X1/8,ALUM

2

7275012

SCREW, M4 X 0.7 SOCKET X 16

2

388030

COVER,TERMINAL BLOCK, 3 PIECE

1

7298348

MOTION CTRL, ELMO PLATINUM

1

6147352

LABEL,BLANK,GREY MYLAR

1

7254893
