ASYMTEK Vantage® Series Spares List

April 2024 13

ASSY,TROLLEY,HATCH,RIGHT

1

6102168

ASSY,TROLLEY,HATCH,LEFT

1

6112617

WASHER,#10,FLAT,SS

4

382149

WASHER, FLAT M4

2

387998

SCREW, M4 X 0.7, SOCKET CAP,X8

15

388026

SCREW, M4 X 0.7 SOCKET X 16

2

388030

NUT, HEX M5 X 0.8

6

388055

BRKT,INTERLOCK,TROLLEY TRACK

1

6102166

NUT PLATE,INTERLOCK,TROLLEY

1

6102167

NUT, LOC W WASHER, M5x0.8

6

6102169

MAGNET KEY CODED FOR SI-

MAGB2SM

1

6130097

SCREW, M5 X 0.8 SOCKET X 16

4

7245329

NUT,HEX,5/16"-18,.5W.27H,188SS

4

7246593

FCHS,M5x0.8 X 10mm,SS

4

7260309

WASHER,5/16 USS FLAT,ST-ZINC

8

7267068

MOUNT,GAS SPRING,UPPER

2

7287689

SPRING,GAS,70LB,15.23IN LONG

2

7291026

M8X20 SHLD,M6-1 THREAD,W/HEX

2

7297083

KIT,VISION ELECTRONICS,VTG

6655134

KIT, CAMERA CARE

1

383698

TILE,XY OFFSET, 3X6,PCB

2

6115952

CABLE,RGB PWA TO 5CH CT

ADAPTR

1

7254961

CABLE,5CH CT TO 5CH CT ADAPTR

1

7254963

CABLE,SPI COMM TO PNEUM & LED

1

7287615

PCA,CAMERA LIGHT INTERCONN

1

7287590

PCA, 5CH LIGHT DRIVER V2

TESTED

1

7298885

KIT,REPAIR,Z-HEADS,VTG

6655135

FRU,Z1 BRAKE ASSY,VANTAGE

1

6112718

FRU,Z2 BRAKE ASSY,VANTAGE

1

6112719

Q-LIMIT,MAGNET,BOLT ON

2

7258963

P LIMIT,MAGNET,BOLT ON

1

7258964

MOTOR MOUNT, Z-AXIS

1

7290902

MOTOR & ENCODER,Z-AXIS

1

7290907

SCALE,ENCODER,Z-AXIS

1

7290920

FLAG,Z2/Z1 COLLISION

1

7290957

FLAG,Z2/Z1

COLLISION,EXTENDED,INTEL

1

6136786

ASSY,COLLISION DETECT

1

7294265

KIT,X-Y MOTION REPAIR,VTG

6655136

ASSY,X-BEAM,BUMPER,LEFT,VTG

1

6650681

ASSY,X-BEAM,BUMPER,RIGHT,VTG

1

6650682

Q-LIMIT,MAGNET,BOLT ON

4

7258963

P LIMIT,MAGNET,BOLT ON

4

7258964

MAGNET,Q LIMIT 9MM OFFSET

4

6130755

ASSY,X-

BEAM,BUMPER,LEFT,EXTD,IDH,VTG

1

6650683

KIT,X-Y MOTION REBUILD,VTG

6655137

BLOCK, SLIDER,NS,IN-CHNG

8

7287497

ASSY,X-BEAM,BUMPER,LEFT,VTG

1

6650681

ASSY,X-BEAM,BUMPER,RIGHT,VTG

1

6650682

Q-LIMIT,MAGNET,BOLT ON

4

7258963

P LIMIT,MAGNET,BOLT ON

4

7258964

ENCODER,STRIP,550MM,50MM REF

2

7287573

MAGNET TRACK, 252MM, AUM5

1

7287638

MAGNET TRACK, 420MM, AUM5

2

7287639

ENCODER READHEAD,TONIC 3M

1

7290899

MAGNET,Q LIMIT 9MM OFFSET

4

6130755

ASSY,X-

BEAM,BUMPER,LEFT,EXTD,IDH,VTG

1

6650683

ENCODER READHEAD,TONIC 5M

3

7287387

ENCODER, SCALE,750MM, 50MM

REF

2

7287574

ASYMTEK Vantage® Series Spares List

April 2024 14

KIT,DISPENSE/SCALE,SERVICE,VTG

6655133

CABLE,NEEDLE/TACTILE SENSOR

1

7294318

LEVEL,BUBBLE

1

194540

PEDESTAL, METAL CUP, PRECISION

SCALE

1

6128611

LID, FID SCALE IHS

5

7257518

CUP PEDESTAL,SCALE

1

7239058

CABLE,SCALE COMM

1

7238613

SCALE LID W/ FIDUCIALS

1

7238690

CABLE,POWER,WZA SERIES SCALE

1

7276131

BREEZE SHIELD,SCALE,SLEEVE

1

7238689

COVER, SENSOR, VANTAGE,

CLEAR

1

6110171

INSERT,COVER,L-U CAMERA

1

6115910

MIRROR, LOOKUP DISPENSE

1

7297047

CABLE,PRECISION SCALE

SHUTTER

1

7298851

CABLE,24VDC, SCALE POWER

1

6146817

LID, PRECISION SCALE, W/SHUTTR

1

6100884

SCALE,PRECISION,VTG

1

6100885

RETAINER, SCALE SHUTTER

1

6100886

KIT,SYSTEM/SERVO,CABLES,VTG

6655139

CABLE-P,CAT6 XOVER,S/UTP,10FT

1

7298871

CABLE,PMAS DC PWR SUPPLY

1

7287614

CABLE-P,CAT6 SHIELDED 1FT

GREY

1

7262298

PIPE, LIGHT, 2.5MM DIA X 20.3

4

7232202

RETAINER, LIGHT PIPE,2.5MM DIA

4

7232203

CABLE,INTERLOCK BYPASS

2

7287621

PCA,24 VOLT EMI FILTER

1

7283700

CABLE,PZD TO SYS PCA

1

7287608

CABLE,EMI FILTER TO PZD POWER

1

7252488

CABLE,EMO POWER STATUS

1

7287594

CABLE-P,DC37M-M,2.5',26G,FOIL

1

7287607

CABLE,Z-BRAKE,E-PAN

1

7297147

CABLE,PM DC OUT

1

7298836

CABLE,SYSTEM LIGHT BREAKOUT

1

7287622

P11,SMEMA PNL

1

7287329

CABLE,SYSTEM LIGHT EXTENSION

2

7287623

CABLE,DC POWER

1

7244667

CABLE,DC POWER

1

7244506

E-ASSY,OPTIC XCVR,4.25Gbps,SFP

2

7283734

KIT,CONVEYOR PNEUMATICS,VTG

6655140

ASSY,MFLD,4 PORT,.25 QD TUBING

1

7208074

KIT,CONV PNEU,VTG

1

7287340

KIT,DUAL LANE FLOWMETER

1

7221085

KIT,UI ELECTRONICS,VTG

6655141

MONITOR,22"

WIDESCREEN,VANTAGE

1

6114668

KEYBOARD 104 KEYS, 2 USB

PORTS

1

7296970

CABLE,COMPUTER/MONITOR

POWER

1

7297023

CABLE,MONITOR POWER,2000mm

1

7296974

CABLE-P,USB,M/F A/A,3'

1

7236438

CABLE, DISPLAY PORT M-M, 10FT

1

6119879

TRACKBALL, W/SCROLL

1

6111133

KIT,CONVEYOR CABLES,VTG

6655142

CABLE, BP TO CC INTERLOCK

1

6100916

CABLE,CONVEYOR SENSOR

BREAKOUT

1

7209620

CABLE,USB,10 FT,TYPE A/B

1

7217468

CABLE,CV SOLENOID BREAKOUT

1

7212891

CABLE,CNVYR,AC PWR,1M

1

6140904

CABLE,SIGNAL TO PM2

1

7209097

ASYMTEK Vantage® Series Spares List

April 2024 15

CABLE,SMEMA UPSTREAM

1

7238775

CABLE,SMEMA DOWNSTREAM

1

7238776

CABLE,CONV.SOLENOIDS

1

7209636

CABLE,T/C 8 PIN HEAT ADAPTER

1

7215470

KIT,EDGE CLAMP,SNGL,VTG

7297140

FIBER ARRAY DIFFUSED

1

196582

TUBING,PU,BLK 1/8"OD .079"ID

1

386953

TUBING,PU,BLU 1/8"OD 1/16"ID

1

386956

FLOW CONTROL 1/8"

4

7212093

FITTING, REDUCER 1/4TBX1/8TB

2

387436

FITTING,1/4"Y-1/8",QUICK-DISC

2

197668

CABLE TIE,4",BLACK

1

382767

SCREW, M3X0.5, SOCKET CAP, X30

1

387986

SCREW, M4 X 0.7, SOCKET X 10

2

388027

SCREW,M4X0.7 BUTTON X 12

1

7241929

WASHER, FLAT M6

1

388088

SCREW,M6 X 1.0 SOCKET X 16

4

7243615

NUT,SQUARE,M4,7X7X2

3

7207258

ASSY,CLAMP,REAR

1

7239040

ASSY,CLAMP,FRONT

1

7239041

LABEL,SELF LAMINATING,1X2.2"

14

7268706

PIN,STOP,EXTENDED

1

7269916

BRKT,STOP PIN MOUNT,EXTENDED

1

7269917

KIT,INDEX 1,VTG

6149115

ASSY,STOP PIN

1

7237716

SENSOR,BOARD,LOW PROFILE

1

7209626

TUBING,PU,BLK 1/8"OD .079"ID

10

386953

TUBING,PU,BLU 1/8"OD 1/16"ID

10

386956

KIT,FLEX RAIL,400MM,PREQ

6650679

ASSY,MAG, RAIL,ADJ,395MM

1

6140102

RAIL,FRONT,400MM,PREQ,OFFSET

1

6140101

SCREW, M3X6 BUTTON HEAD

3

7244697

KIT,FLEX RAIL,400MM,POSTQ

6650680

ASSY,MAG, RAIL,ADJ,395MM

1

6140102

RAIL,FRONT,400MM,POSTQ,OFFSE

T

1

6140107

SCREW, M3X6 BUTTON HEAD

3

7244697

UK,XLG LIFT TABLE,290X450

6126781

PLATE,TOP,LIFT TABLE,290X450

1

6126083

SCREW,FLAT,M10X1.5X25MM,SOC,

SS

1

193847

SCREW, M3X.5X16 SOCKET HEAD

2

387983

SCREW,M3X.5X25 SOCKET CAP

2

387985

SCREW M5X20MM FLAT H.

PHILLIPS,SS

4

7244126

SCREW,M4X0.7,SOC CAP X5

1

7253694

ASSY,MAG,RAIL,ADJ,460MM

6138151

MAG,RAIL,ADJ,460MM

1

6138152

SCREW, M3 X 0.5 PH.FLAT X 5

6

387973

SCREW, BUTTON HEAD M3 X 10

4

387994

BLOCK,RAIL ADJ,6800

1

7257969

COVER,MAGNET,6800

1

7257970

MAGNET,.25X.5DIA,SAM-COB DISC

3

7274586

KIT,SERVICE,HORIZ DOOR,VTG

6655212

LATCH,PANEL 3 LB

2

392369

WINDOW,ESD POLYCARB,SWNG

DR, VNTG

1

6142857

LATCH,HOLE,45mm,VNTG

1

6142868

COVER,CLEAR,45MM HOLE,SWNG

DR,VNTG

1

6142867

HINGE,SMALL,45mm,HOLE

1

6142870

CABLE,MAG SNSR INTLK EXT

1

7298822

ASSY,MAG SENSOR INTLK

1

6130098

MAGNET KEY CODED FOR SI-

MAGB2SM

1

6130097
