ASYMTEK Vantage® Series Spares List
April 2024 18
ASSY,HEATER
IMPNG,JEDEC,SHELL INT
1
6653925
ASSY,BLKHD UPGRADE,VTG,DH,INTEL
6131389
CLAMP, 5/8 IN, LOOP
4
7274635
CABLE,FSENSE,BH SIDE TO REAR
2
6124690
PANEL,CONNECT,LEVEL
SENSE,INTEL
2
6115933
PNL 9, OPTIONS SM
1
7287555
ASSY,COOLER,BKHD,VTG,INTEL
2
6131370
SPACER, ALUM., 1/2OD,1/4IDX1/8
4
387927
SCREW, M5 X 10MM, BUTTON SS
4
7255797
SCREW,M4X0.7 BUTTON HEAD,X6
7
7226304
FCHS,M5x0.8 X 10mm,SS
6
7260309
CABLE CLAMP, 1/4" BLACK NYLON
3
7242719
CLIP,WIRE HARNESS,1"DIA
3
7226307
SCREW,D M4X6,SS,SOC HEAD
4
7207192
SCREW,M5-0.8X6 SOCKET CAP,SS
4
7275139
PLUG, ONE TOUCH
1
383428
ASSY,COOLER CONTROL,DH,VTG
INTEL
1
6142252
ASSY,LIFT TABLE,EPOXY,VTG
6110566
STAND,LIFT TABLE,EPOXY,VTG
1
6110567
SCREW,FLAT,M10X1.5X25MM,SOC,
SS
1
193847
BLOCK, PILLOW, 3/8 ADJUSTABLE
1
381634
ELBOW,90 SWIV.-1/8TUBEX1/8 NPT
2
387424
GREASE, USDA-H1, NLGI-2
1
382186
CLIP,WIRE HARNESS,1"DIA
4
7226307
SCREW, M3X.5X16 SOCKET HEAD
2
387983
SCREW M5X20MM FLAT H.
PHILLIPS,SS
4
7244126
SCREW,M5 X 0.8 SOCKET X 10
5
388064
SCREW, M5X20MM SHCS SS
9
7243426
SCREW,M5-.8X10,SOC SET-CUP,SS
4
7275145
BEARING,LINEAR,20MM,FLANGED
1
7218079
SCREW,M6-1,NYLON TIP
1
7237681
LOCATING PIN,LIFT TABLE
2
7237683
NUT PLATE,LIFT TABLE
1
7237686
BRACKET,ANTI-ROTATION,LT TABLE
1
7237687
PLATE,BASE,LIFT TABLE
1
7237689
PLATE,TOP,LIFT TABLE
1
7286907
SHAFT, LIFT TABLE, SHORT
1
7286908
ROD,GUIDE,LIFT TABLE
1
7238734
SCREW,M6-30,FLAT TIP
1
7238741
BLOCK,HT ADJUST,LIFT TABLE
1
7238974
SCREW,M4X0.7,SOC CAP X5
4
7253694
CYLINDER,FLAT,1.5"BOR,5/8"STK,BI
MBA
1
6142636
ASSY,DISP. COVER,6OZ,VTG
6146766
COVER, SENSOR, VANTAGE,
CLEAR
1
6110171
INSERT,COVER,L-U CAMERA
1
6115910
COVER,VAC GAUGES,VTG
1
6131386
COVER,DUAL DISP,CLEAN RAIL &
GUAGES,VANT
1
6138730
LABEL, HOT SURFACE
1
7207207
MIRROR, LOOKUP DISPENSE
1
7297047
SCREW, NYLON M3 X 0.5 X 6 FLAT
2
7297048
ASSY,LIFT PIN, S900 JEDEC
7264386
HOUSING,SPRING PIN
1
7256787
COVER,HOUSING,SPRING
2
7256786
PIN,JEDEC LIFT, LEFT SIDE
2
7246645
PIN,JEDEC LIFT, RIGHT SIDE
2
6108861
BEARING,LINEAR 6MM
4
7257514
BUSHING,6.35x3.175x6.35L
4
7257515
ASYMTEK Vantage® Series Spares List
April 2024 19
SPRING,.60ODx.75L CONE
4
7257516
RING,6mm Ext, .7thk
4
7257517
PIN,DOWEL,1/8X1/2 SST
4
7204471
HOUSING, SPRING PIN,RT
1
7262973
SCREW, M3X0.5, PHILIPS PAN, X5
8
7252391
WASHER, FLAT M6
20
388088
SCREW, M4 X 0.7, SOCKET CAP,X8
4
388026
SCREW, M5X0.8, SOCKET CAP, X12
2
388065
BALL,3/32 NYLON
8
7268742
SPRING,ROLLING PIN
8
6149447
SET SCREW,M3-.5X3,SS,CUP
8
210851
ASSY, DLA LIFT TABLE
7269938
PLATE,LEVELING,LIFT TABLE
1
7241470
PLATE,BASE,LIFT TABLE
1
7241469
PLATE,TOP,LIFT TABLE
1
7241471
PLATE,X ADJUST,LIFT TABLE
1
7259271
POST,VACUUM,LIFT TABLE
1
7259272
LEVELING SCREW
3
7251499
BEARING,LINEAR,8MM SHAFT
1
7218569
ROD,GUIDE,LIFT TABLE
1
7218568
CYLINDER, COMPACT
1
7259276
BLOCK,HEIGHT ADJUST,DLA
1
7269932
LINEAR SHAFT,20mm DIA.
1
7218553
BEARING,LINEAR,20MM SHAFT
1
7218552
GENERATOR,VACUUM,PIAB M20
1
392116
FITTING, M5X4MM ELBOW,Q-DISC
2
7259280
FITTING,1/8"X6MM ELBOW,Q-DISC
1
7259281
FITTING,3/8"X6MM ELBOW,Q-DISC
1
7259282
FITTING,BRANCH ELBOW 3/8"X6MM
1
7259283
PIN,LOCATING,LIFT TABLE
1
7213303
BRACKET,ANTI-ROTATE,G5 LIFT
1
7260317
NUT,M8X1.25,THIN
3
7259285
O-RING,11/16"ID X 7/8"OD
1
7259273
SHCS,M3X0.5X35mm,SS
2
7203339
SCREW,M5X.8X8 SHCS
2
7245989
SCREW, M3X.5X16 SOCKET HEAD
1
387983
SCREW, M4X0.7X25MM SHCS, SS
3
388033
SCREW, M4X0.7, BUTTON HEAD, X8
4
388040
SCREW,M8X1.25X20 SOC FLAT HD
1
7222442
SCREW,SET NYLTP
M6X1.0X6MM,SS
1
7260310
WASHER, FLAT M3
2
387964
TUBING,4MM,BLUE
200
7252647
TUBING,4MM,BLACK
200
7252646
TUBING,6MM,BLACK
320
7252645
CABLE,GND,LIFT TABLE
1
7262363
SCREW,D M4X6,SS,SOC HEAD
1
7207192
WASHER, #8 INTERNAL STAR
2
381697
SCREW,M5X14 FHSCS
4
7269937
PLUG, 6MM PUSH
1
7269934
SPRING PLUNGER,M6
1
7225989
SET SCREW,M6X25,FLAT
1
7226647
SCREW, M4 X 0.7, SOCKET X 10
1
388027
FITTING,1/8 FNPT TO 1/8 TUBE
2
7269935
FITTING,1/8 MNPT TO 4MM TUBE
2
7269936
FITTING,1/4" TO 6MM PUSH
1
7269933
KIT,REBUILD,CONVEYOR,EPX
6655130
RAIL,Z STOP JDEC TOOLING
4
7236739
ASSY,STOP PIN,INTEL,HARD
2
6110557
ASSY,INSERT,CONV,W/RLRS,VTG
4
6110562
GUARD DRIVE PULLEY CONV
4
7225401
CLIP,GUARD DRIVE PULLEY CONV
4
7225402
RETAINER,BELT,CMP
20
7213118
ASSY,S-9XX 6MM BELT PULLEY
20
7214226
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
ASYMTEK Vantage® Series Spares List
April 2024 20
SCREW, M4 X 0.7, SOCKET X 10
20
388027
NUT,SQUARE,M4,7X7X2
36
7207258
BELT,FLAT 6MM X 1810MM
8
6110576
MOTOR,NEMA 23 STEPPER
W/CONN
4
7263550
PULLEY,DRIVE,FLAT,ORING,CMP
4
7239006
SCREW, M4 X 0.7, SET, CUP X 10
4
388039
SCREW, M4 X 0.7, SOCKET CAP,X8
16
388026
INSERT,UPPER GUIDE,6MM FLAT
4
7296958
SCREW, M3X.05 FLAT
36
392120
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
KIT,REBUILD,CONVEYOR,DLA
6655131
ASSY,STOP PIN,INTEL,HARD
2
6110557
GUARD DRIVE PULLEY CONV
4
7225401
CLIP,GUARD DRIVE PULLEY CONV
4
7225402
CLAMP,Z STOP
12
7256789
RETAINER,BELT,CMP
20
7213118
ASSY,S-9XX 6MM BELT PULLEY
20
7214226
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
SCREW, M4 X 0.7, SOCKET X 10
20
388027
NUT,SQUARE,M4,7X7X2
36
7207258
BELT,FLAT 6MM X 1810MM
8
6110576
MOTOR,NEMA 23 STEPPER
W/CONN
4
7263550
PULLEY,DRIVE,FLAT,ORING,CMP
4
7239006
SCREW, M4 X 0.7, SET, CUP X 10
4
388039
SCREW, M4 X 0.7, SOCKET CAP,X8
16
388026
INSERT, LOWER GUIDE RAIL
4
7290982
INSERT,UPPER GUIDE,6MM FLAT
4
7296958
SCREW, M3X.05 FLAT
36
392120
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
KIT,CONVEYOR PNEUMATICS,DLA/EPX
6655132
ASSY,VISUAL FLW CNTRL,INT,VTG
1
6126668
ASSY,PNEUM PAN,VTG,DL
PRG,INTEL
1
6146367
Individual Part List
The following items are sold individually.
Part Description
Lookup Part Number
TIP ADAPT 1/4 NPT PLATED BRASS
7016945
BOOT,VAC .020 ID ORANGE
381521
BOOT,VAC .120 ID OLIVE
381523
O-RING, 1 7/8 OD X 1/16
381649
BOOT,VAC.045 ID GREEN
383818
LID,PURGE,ANTI-SPATTER
6115929
MONITOR,22" WIDESCREEN,VANTAGE
6114668
CABLE-P,PWR,US,L6-6H 309,2.5M
7223281
SW,CANVAS,GEM ADAPTER AND LICENSE
6143242
ASSY,NEEDLE X-Y LOCATOR
392435
BOOT,VAC .031 ID PINK
381522
MOTION CTRL, ELMO PLATINUM
6147352
ENCODER READHEAD,TONIC 5M
7287387
CAMERA,GENIE-NANO 1456X1088
6111122
CABLE-P,PWR,EEUR,IEC309.2.4M
7223282
FIBER ARRAY DIFFUSED
196582
TILE CALIBRATION & DUAL OFFSETS
6138731
PCA,I_F,EXP VAC GAUGE+HTR CNTRL,PRGMD
6139145
MOTOR,NEMA 23 STEPPER W/CONN
7263550
AIR CYLINDER,15MM STROKE
392794
SENSOR,BOARD,LOW PROFILE
7209626
ASSY,Z TCTL,CERAM INST,ADSZ
6112270
