ASYMTEK Vantage® Series Spares List

April 2024 6

FITNG,Q-D BLKHD FEM,GREEN

2

7201192

VALVE,MAC44,4-WAY AIR,24V

2

7201334

PLUG,10-32

1

7208633

FITNG,Q-D BLKHD FEM,M5 CLEAR

1

7209918

FTG,MINI,FEM,BULKHEAD DUAL

2

7221822

CABLE,BULKHEAD TO MAC VALVE

2

7233014

FITTING,STR,10-32X1/4 OD

4

7239683

CABLE,SAMTEC 30P TO CPC

1

7289188

COVER,BULKHEAD LEFT,Z2

1

7290948

COVER,BULKHEAD FRONT,Z2

1

7290949

MUFFLER, 10-32 UNC

4

382934

TUBING,PU,BLK 1/8"OD .079"ID

2

386953

TUBING,PU,BLU 1/8"OD 1/16"ID

1

386956

FITNG,Q-D BLKHD FEM 10-32 BLK

1

195402

FITTING,UNION,10-32THD-1/8TUBE

5

387427

FITTING,1/4"Y-1/8",QUICK-DISC

1

197668

SCREW, M3X5MM, SOCKET CAP

4

387978

SCREW,M4X0.7 BUTTON HEAD,X6

7

7226304

NUT, HEX M3 X 0.5

2

7242811

LABEL,BLANK,SELF LAMINATE

2

7220555

SCREW, M3 X 10MM, SOCKET CAP

5

387981

CLIP,WIRE HARNESS,.500 ID

1

194971

NUT,M5,HEX, W/TOOTH

1

7254144

LABEL,BLANK,COMPONENT,SMALL

2

7220558

PCA, BULKHEAD, TESTED

1

7297725

COVER,VTG,BH,Z2,REAR

1

6115937

COVER,BHEAD,COOLER,VANTAGE

1

6131369

CABLE,BULKHEAD ANALOG I/O

1

6124697

CABLE,BULKKHEAD DIGITAL I/O

1

6124698

HEX POST, D-SUB 4-40X3/16, SST

4

382564

ASSY,LIFT TABLE,LARGE,VTG

7297135

SCREW,FLAT,M10X1.5X25MM,SOC,

SS

1

193847

SCREW, M3X.5X16 SOCKET HEAD

2

387983

PLATE,TOP, LIFT TBL,X-LG

1

7223170

SCREW M5X20MM FLAT H.

PHILLIPS,SS

4

7244126

SCREW,M3X20,SOCK.HD.CAP,SS

2

387984

FRU,6100915,PCA,WHISTLE

MODULE,TESTED

6137473

PCA,WHISTLE MODULE,TESTED

1

6100915

FRU, REGULATOR,E/P,0-130PSI,0-5V

6105644

REGULATOR,E/P,0-130PSI,0-5V

1

7213397

ASSY,CONV/HEAT CNTRLR,VANTAGE

6110180

ASSY,CM CONV/HEAT CNTRLR

W/USB

1

7287575

ASSY,STOP PIN

7237716

AIR CYLINDER,15MM STROKE

1

392794

FITTING,UNION,10-32THD-1/8TUBE

2

387427

SCREW, M3X.5 X 8MM LNG.BUTTON

2

7244069

SCREW, M4X0.7 SOCKET FLAT X 10

2

7245171

SCREW, M4 X 0.7, SOCKET X 10

2

388027

NUT,SQUARE,M4,7X7X2

2

7207258

PIN,STOP

1

7237717

BRKT,STOP PIN MOUNT

1

7237718

CABLE,GROUND,STOP PIN

1

7238736

ASSY,20A,POWER MANAGER 2,STD,VTG

6137449

ASSY,20A,POWER MANAGER 2

1

7297070

VENT SWITCH BYPASS

1

194034

LABEL, WARNING, MOVING PARTS

2

7253636

LABEL,HOT SURFACE

2

7207206

WASHER,M6,STAR INT.TOOTH,SS

2

7206635

SCREW, M6X10, SOCK, CAP, SS

1

388099

CABLE-P,PWR,US,L6-6H 309,2.5M

1

7223281

SCREW,M5X.8X8 SHCS

4

7245989

ASYMTEK Vantage® Series Spares List

April 2024 7

ASSY,LIFT TABLE,VANTAGE

6119673

SCREW,FLAT,M10X1.5X25MM,SOC,

SS

1

193847

NUT PLATE,LIFT TABLE

1

193854

TUBING,170ID X .250OD,POLYURE

1

6126523

FITTING,1/8MNPT X QD CPC

1

392795

ROD,GUIDE,LIFT TABLE

1

7218073

BRKT,ANTI-ROT,LIFT TABLE

1

7218074

SHAFT,LIFT TABLE,20DIA X 106LG

1

7218078

BEARING,LINEAR,20MM,FLANGED

1

7218079

CYLINDER,FLAT,1.5"BORE,5/8"STR

1

7218080

BLOCK,HT ADJUST,LIFT TABLE

1

7218081

STAND,LIFT TABLE

1

7237690

SCREW,M4X0.7,SOC CAP X5

4

7253694

PLUG, NYLON LIFT MODULE

ENCAP

1

7244649

PIN,LOCATING,LIFT TABLE

2

7213303

BLOCK, PILLOW, 3/8 ADJUSTABLE

1

381634

ELBOW,90 SWIV.-1/8TUBEX1/8 NPT

2

387424

FITTING, 1/8NPT STREET ELBOW

1

382969

UNION, 1/4" Q-DISC.

1

382989

GREASE, USDA-H1, NLGI-2

1

382186

CLIP,WIRE HARNESS,1"DIA

4

7226307

SCREW, M3 X 10MM, SOCKET CAP

4

387981

SCREW, M3X.5X16 SOCKET HEAD

2

387983

SCREW,M3X20,SOCK.HD.CAP,SS

2

387984

SCREW M5X20MM FLAT H.

PHILLIPS,SS

4

7244126

SCREW,M5X.8X8 SHCS

1

7245989

SCREW, M5X0.8, SOCKET CAP, X12

4

388065

SCREW, M5X20MM SHCS SS

5

7243426

SCREW,M5-.8X10,SOC SET-CUP,SS

4

7275145

SCREW, M6X1.0, FLAT TIP SET,X8

1

7275156

SCREW,SET,CUP POINT,M6-

1X30,SS

1

7200457

GENERATOR, VACUUM

1

381764

PLATE,TOP,LIFT TABLE

1

7237692

SCREW, M5 X 0.8 SOCKET X 16

4

7245329

PLATE,BASE,LIFT TABLE

1

7237689

ASSY,USER INTERFACE,VTG

7287316

PIVOT,MONITOR

1

7214551

STANDOFF,6MM HEX M3X33.9

5

7214557

MNT,UPPER,MONITOR

1

7214549

CABLE TIE,4",BLACK

1

382767

HINGE,MONITOR

1

7214667

SCREW,M5X.8X8 SHCS

3

7245989

CLAMP,40mm DIA

2

7291036

SCREW, M3X6 BUTTON HEAD

10

7244697

SCREW, M4 X 0.7, SOCKET CAP,X8

8

388026

POLE,USER INTERFACE

1

7296964

CABLE,MONITOR POWER,2000mm

1

7296974

COVER,T-SLOT,40 SERIES,80/20

0.06

7205781

WASHER, 1/4 SPLITLOCK

8

7245330

SCREW, M6X10, SOCK, CAP, SS

8

388099

MOUNT, ARM S-920/940, BLACK

4

7297084

ARM, UI, 285MM

1

7297088

ARM, UI, 163MM

1

7297089

SCREW, M5 X 0.8 SOCKET X 16

2

7245329

CABLE, DISPLAY PORT M-M, 10FT

1

6119879

COMPUTER,PROGRAMMED,VANTAGE

SPARE

7296960

CABLE-P,USB 2.0 EXT.,6'GOLD

1

7206872

CABLE-P,DSUB-9,M-F,3M

1

7287053

ASYMTEK Vantage® Series Spares List

April 2024 8

ASSY,P340

COMPUTER,PROGRAMMED,VANTA

GE

1

7254002

KIT,Q-68XX EDGE CLMPS LFT TBL

7257972

SCREW, M3X6 BUTTON HEAD

3

7244697

RAIL,STATIONARY,6800

1

7257966

ASSY,RAIL ADJ,6800

1

7257967

FRU,Z1 HEAD,VANTAGE

6141395

Z1-HEAD,VANTAGE

1

7287315

Z1-CBL/PNEU CARRIER,VTG

7287314

TUBE,SPIRAL 0.25IN OD

0.04

195207

CABLE TIE,NYLONG,RED

5

7205965

LABEL,SELF LAMINATING 1X2.25"

16

7216610

LABEL,BLANK,SELF LAMINATE

25

7220555

SCREW,SHC,FLATHD,M4.0.7X8MM,

SS

11

7228081

NUT,M5,HEX, W/TOOTH

2

7254144

ENCODER READHEAD,TONIC 5M

2

7287387

BRKT., CAT-TRACK, Y LARGE

1

7287507

TRAY,CABLE CARRIER LEFT

1

7287585

CABLE,SPARES DE09

1

7287593

CABLE,SYS PCA TO HEAD CTRL

1

7287595

CABLE,CAT,INTELLIJET

1

7287598

CABLE,CT,5-CH LED

1

7287599

CABLE,Z-MOTOR EXTENSION

1

7287600

CABLE,HALLS+R-ENCODER,Z-

HEAD

1

7287602

CABLE,TEMP SENSOR,CAT TRACK

1

7287603

CABLE,HEAD POWER 24V

1

7287605

CABLE-P,FIBER OPTIC,LC,3MM

1

7287606

ASSY,BULKHEAD,Z1,VTG

1

7290931

MOUNT,Y CABLE CARRIER,

X1,LEFT

1

7290959

ASSY, CATTRACK HEAD1X, 20LINK

1

7290961

ASSY, CATTRACK HEAD Y , 27LINK

1

7290963

VERTICAL SEPARATOR E6-29

24

7290964

TIEWRAP PLATE, 8 TOOTH

2

7290965

TIEWRAP PLATE, 6 TOOTH

2

7290966

FULL WIDTH SHELF, 70MM , E6

10

7290967

FULL WIDTH SHELF, 80MM , E6

14

7290968

MOUNT,X CABLE CARRIER COMB

1

7290969

ASSY, X1 MOTOR SUPPORT

1

7290975

CABLE,CAT TRACK uE LHS

1

7294335

SUPPORT,CAT TRACK,105MM WIDE

1

7297086

TIE WRAP,8"-BLUE

4

7297096

CABLE,GROUND WIRE 720MM

1

7297425

CABLE,X-BEAM TO EM BOX

GROUND

1

7297426

FITTING,1/4"-1/8"UNION Q/DISC

1

197669

CABLE TIE,LOCK,NYL6/6

UVB,7.9"L,50LB,BLK

43

382864

CABLE TIE, FLAT

3

7243455

SCREW, M4X0.7 SOCKET FLAT X 10

2

7245171

SCREW, M4 X 0.7, SOCKET X 10

4

388027

SCREW,M4X0.7X10MM,BUT HD,SS

3

7246519

HEX POST, D-SUB 4-40X3/16, SST

2

382564

CABLE-

P,CAT6,6M,SH,HF,THMBSCRW

1

7298866

KIT,TUBE,CABLE CARRIER

1

7298344

STRIP,WEAR, X1,INSIDE, YE

2

6102145

STRIP,WEAR, X1,OUTSIDE,YE

2

6102146

STRIP,WEAR,Y,INSIDE,YE

2

6102149

STRIP,WEAR,Y,OUTSIDE,YE

2

6102150

INTERPOLATOR,TONIC,40MHZ

2

7298895

CABLE, NANO CAMERA, VANTAGE

1

7268874
