ASYMTEK Vantage® Series Spares List

April 2024 2

Spares Kit List

All parts listed in the following table are sold only within kits, not individually. The informaon in the Lookup Part

Number column allows you to locate a part that you previously ordered separately but is now only available as

part of a kit. The Quanty column shows the quanty you will receive for each part in a kit.

Kit Name

Kit Part

Number

Part Description

Quantity

Lookup Part Number

KIT,SCALE,VTG

7287320

CABLE,SCALE COMM

1

7238613

SCALE PWA HOUSING,BASE

1

7238653

SCALE PWA HOUSING,COVER

1

7238654

SCALE PWA HOUSING,END PLATE

1

7238655

BRKT,SCALE BREEZE

SHIELD,COVER

1

7238688

BREEZE SHIELD,SCALE,SLEEVE

1

7238689

SCALE LID W/ FIDUCIALS

1

7238690

BREEZE SHIELD,SCALE,MOAT

1

7239028

CUP PEDESTAL,SCALE

1

7239058

O-RING,45MM ID,3MM CS,VITON

2

7239059

BRKT,SCALE COVER

3

7239060

HEIGHT ADJ PLATE,SCALE

1

7239061

NUTPLATE, SCALE

1

7255485

SCALE TESTED/CALIBRATION

1

7265200

LABEL,SCALE CAL SERIAL NUMBER

2

7270907

SCREW,M3-.5 PH FLAT X 12,SS

8

7243059

SCREW, M3X6 BUTTON HEAD

6

7244697

SCREW, M4 X 0.7, SOCKET CAP,X8

3

388026

SCREW, M5X20MM SHCS SS

3

7243426

SCREW, M6X10, SOCK, CAP, SS

3

388099

SCREW,M6X1.0 SET,CUP X12,SS

3

7275157

CABLE,POWER,WZA SERIES SCALE

1

7276131

BKT,SCALE,VANTAGE,CLEAN STN

1

6101353

FERRITE,SNAP-ON,10MM DIA

2

7252912

SCREW, 4-40 X 3/16 PH, PAN

2

387633

CABLE TIE,4",BLACK

4

382767

INSERT,COVER,PRE SCALE

1

6115911

SCR,SHC,FLATHD,M4X0.7X6MM,SS

2

7228080

P3,SYSTEM PNEU CNTRL ASSY,VTG

7287334

VALVE, 3 WAY, HIGH FLOW

2

383240

FITTING,MALE,3/8TUBE X1/8 NPT

1

7243915

FITTING, ELBOW, 3/8 TUBE OD

3

383432

FITTING, 1/8M X 1/8F X 1/8FNPT

2

7244870

FITTING, TEE, 3/8, BRASS

2

7244346

VALVE, 3 WAY, 24V

2

382928

FITTING, ELBOW,1/8NPT-1/4TUBE

3

387432

MUFFLER, 1/8 MPT

5

382929

FITTING,1/8NPT X DUAL-Y 1/4OD

2

392803

REGULATOR,E/P,0-130PSI,0-5V

1

7213397

ELBOW, 1/4MNPTX1/4Q-DISC, SWIV

2

381674

FITTING,1/8"NPT,3X1/4" QUICK

1

7220150

BHCS,M4 X 45MM

2

7225963

SCREW,M4X0.7X35MM SHCS,SS

2

7265106

SCREW,M3X20,SOCK.HD.CAP,SS

4

387984

TAPE,PTFE-1/4"

1

382382

TUBING,PU,CLR 3/8"OD 1/4"ID

5

386954

TUBING,PU,CLR 1/4"OD 1/8"ID

15

7242264

PNL3,SYSTEM AIR CONTROL SM2

1

7291023

PLUG, ONE TOUCH

3

383428

FTT'G, BULKHEAD 1/4X1/4 NYCOIL

2

7274878

SCREW, M4 X 0.7, SOCKET CAP,X8

4

388026

ASYMTEK Vantage® Series Spares List

April 2024 3

TERM,DUAL,FEEDTHR,SCRW,DINR

AIL

4

7243246

TRM BLK,END PLT,FOR WDK2.5

1

7271842

TRM BLK,BRACKET END,WEW35/2

2

7243454

LABEL,T.B.1 SHEET OF 144,WS1

4

7279052

LABEL,SELF LAMINATING 1X2.25"

18

7216610

LABEL,BLANK,COMPONENT

10

7220557

DIN RAIL,SLOT,35x7.5x90mm

1

7254839

PLUG,QUICK DISCONNECT,3/8

1

199433

STANDOFF, HEX 6x20MM, M4 M-F

2

7290886

SOCKET,MICROFIT,20-24G,5A,30G

4

7202772

PLUG-M,4S,MICROFIT,3mm DUAL

1

7204217

HEAT SHRINK,1/4",3X,BLACK

0.1

7246621

BUMPER, 0.30, BLACK

2

7243344

PLUG-M,8S,PHOENIX

3.81MM,SCREW

1

7212377

CABLE,PNEUMATIC SOLENOID

1900

4

7287618

TIE WRAP, 5.5" BLACK

4

7254056

CABLE TIE, FLAT

2

7243455

SCREW, M4X0.7, PHILIPS FLAT,X8

2

388008

FITTING,REDUCER,3/8T TO 1/4

3

387475

PIN,FERRULE,20AWG GREY 8mm

8

6117229

LABEL,BLANK,COMPONENT,SMALL

4

7220558

TIE WRAP, 4" WHITE W/ FLAG

4

7246612

TIE WRAP,8"RED

2

6104881

FRU,6100905,PCA,BACKPLANE,TESTED

6137472

PCA,BACKPLANE,TESTED

1

6100905

FRU,6650691,TROMBONE

MODULE,V2,TESTED

6654460

PCA,TROMBONE

MODULE,V2,TESTED

1

6650691

FRU, ASSY,MAIN AIR REGULATOR,S-9XXN

6105624

SCREW,M5X.8X8 SHCS

2

7245989

WASHER,M4,12MM OD

2

7220757

SCREW, M4 X 0.7, SOCKET X 10

2

388027

MAIN AIR REGULATOR

1

6120507

LARGE OD FLAT WASHER,M5,15MM

2

7251823

ASSY, RGBW LZP, LIGHT BOX, VANTAGE

6128638

BAG,SEALTOP4X6,2 MIL,W/WHT

1

7257493

LOCTITE 222MS,50ML BOTTLE

1

7252898

CABLE TIE, 3/16" ROUND

1

387910

SCREW,M2X.40X6 FLTHD. PH. REC.

4

387957

SCREW,M2-0,4X6 SOCKET CAP

9

7275113

SCREW, M3X.05 FLAT

1

392120

BLOCK,BEAMSPLITTER LIGHTBOX

1

7214493

LENS,FRESNEL,RECT.LIGHTBOX

1

7214495

DIFFUSER,RECT.LIGHTBOX

1

7214496

BEAMSPLITTER,VOF LIGHTBOX

1

7214512

HOLDER,OPTICS,VOF

2

7217763

SCREW,FLAT,M2 X 0.4 X 4SST

2

7217764

BLOCK,VOF LIGHT BOX 40W

1

7239586

SCREW,M2X0.4 SOCKET X8,SS

2

7275114

PLATE, MOUNT, RGB LIGHT BOX,

VANTAGE

1

6128603

SETTING, STAR LED LIGHTBOX

40W

1

6135678

ASSY,RGB LZP, 40W

1

6133145

PAPER,FLOCKED,BLACK

1

6126542

FRU,6138269,SCALE,PRECISION,VTG

6137475

PEDESTAL, CALIBRATION,

PRECISION SCALE

1

6128610

KIT, INSTALL, SCALE .01MG,

VANTAGE

1

6138269

SCREW, M6X10, SOCK, CAP, SS

2

388099

ASYMTEK Vantage® Series Spares List

April 2024 4

E-ASSY, VAC GAUGE TO I_F PCA

6138717

LABEL,THERMAL,WH,LONG

2

7251947

GAUGE,DIGITAL VACUUM SWITCH

1

7233256

PLUG-M,4S,NANOFIT,2.5mm,2R

1

6138697

HEATSHRINK,3/16",2:1,BLACK

0.2

6126525

SOCKET,NANOFIT,24-26G,5A,30AU

4

7253333

FITTING,10-32-1/8"ELBOW,Q-DISC

1

199564

ASSY,DUAL PURGE,SRV STN,VTG

6138732

BASE,SERVICE STATION,DUAL

PURGE

1

6138720

FITTING, ELBOW,1/8NPT-1/4TUBE

2

387432

FITTING,10-32-1/8"ELBOW,Q-DISC

2

199564

INSERT,18X36 DISPENSE CARD

HOLDER

1

6138726

SCREW, M3 X 0.5 SOCKET X 8

2

387980

BUSHING,TACTILE, DUAL STN

1

6115909

ASSY,Z TCTL,CERAM INST,ADSZ

1

6112270

SCREW,SET,M3X15MM,FLAT PT

4

6131391

BOOT,VAC .120 ID OLIVE

2

381523

LID,PURGE,ANTI-SPATTER

2

6115929

O-RING, 1 7/8 OD X 1/16

2

381649

PCB,TILE,XY OFFST & JDO,DUAL

HD

1

6112913

ASSY,TACTILE SENSOR,DUAL SVC

STN

1

6148560

FRU, PWA,CM PNEUMATICS CONTROL

6105628

PWA,CM PNEUMATICS CONTROL

1

7226025

P4,V1/V2 PNEU MODULE,VTG

7287335

FITTING,REDUCER,3/8T TO 1/4

2

387475

VALVE, 3 WAY, 24V

4

382928

FITTING, ELBOW,1/8NPT-1/4TUBE

7

387432

MUFFLER, 1/8 MPT

7

382929

REGULATOR,E/P,0-130PSI,0-5V

3

7213397

ELBOW, 1/4MNPTX1/4Q-DISC, SWIV

5

381674

FTG,ELB-3,1/4MNPT X 3/8

1

195969

SCREW,M3X20,SOCK.HD.CAP,SS

6

387984

PNL4+5,HEAD AIR CONTROL SM2

1

7291024

CABLE TIE,4",BLACK

4

382767

SCREW, M4 X 0.7, SOCKET CAP,X8

6

388026

FITTING, 1/4" PLUG-IN Y

1

383188

TUBING,PU,CLR 1/4"OD 1/8"ID

5.5

7242264

TUBING,PU,CLR 3/8"OD 1/4"ID

2

386954

TERM,DUAL,FEEDTHR,SCRW,DINR

AIL

3

7243246

TRM BLK,END PLT,FOR WDK2.5

1

7271842

TRM BLK,BRACKET END,WEW35/2

2

7243454

LABEL,T.B.1 SHEET OF 144,WS1

3

7279052

LABEL,SELF LAMINATING 1X2.25"

28

7216610

DIN RAIL,SLOT,35x7.5x90mm

1

7254839

LABEL,BLANK,COMPONENT

7

7220557

SCREW, M4X0.7, PHILIPS FLAT,X8

4

388008

SOCKET,MICROFIT,20-24G,5A,30G

12

7202772

PLUG-M,4S,MICROFIT,3mm DUAL

3

7204217

TAPE,PTFE-1/4"

1

382382

FITTING,1/8NPT X DUAL-Y 1/4OD

1

392803

SCREW,M5-0.8X6 SOCKET CAP,SS

1

7275139

HEAT SHRINK,1/4",3X,BLACK

0.4

7246621

BUMPER, 0.30, BLACK

2

7243344

CABLE,PNEUMATIC SOLENOID

2200

3

7287617

PLUG-M,4S,PHOENIX

3.81mm,SCRW

1

7297454

PLUG-M,6S,PHOENIX

3.81mm,SCRW

1

7294268

CABLE TIE, FLAT

4

7243455
