ASYMTEK Vantage® Series Spares List
April 2024 19
SPRING,.60ODx.75L CONE
4
7257516
RING,6mm Ext, .7thk
4
7257517
PIN,DOWEL,1/8X1/2 SST
4
7204471
HOUSING, SPRING PIN,RT
1
7262973
SCREW, M3X0.5, PHILIPS PAN, X5
8
7252391
WASHER, FLAT M6
20
388088
SCREW, M4 X 0.7, SOCKET CAP,X8
4
388026
SCREW, M5X0.8, SOCKET CAP, X12
2
388065
BALL,3/32 NYLON
8
7268742
SPRING,ROLLING PIN
8
6149447
SET SCREW,M3-.5X3,SS,CUP
8
210851
ASSY, DLA LIFT TABLE
7269938
PLATE,LEVELING,LIFT TABLE
1
7241470
PLATE,BASE,LIFT TABLE
1
7241469
PLATE,TOP,LIFT TABLE
1
7241471
PLATE,X ADJUST,LIFT TABLE
1
7259271
POST,VACUUM,LIFT TABLE
1
7259272
LEVELING SCREW
3
7251499
BEARING,LINEAR,8MM SHAFT
1
7218569
ROD,GUIDE,LIFT TABLE
1
7218568
CYLINDER, COMPACT
1
7259276
BLOCK,HEIGHT ADJUST,DLA
1
7269932
LINEAR SHAFT,20mm DIA.
1
7218553
BEARING,LINEAR,20MM SHAFT
1
7218552
GENERATOR,VACUUM,PIAB M20
1
392116
FITTING, M5X4MM ELBOW,Q-DISC
2
7259280
FITTING,1/8"X6MM ELBOW,Q-DISC
1
7259281
FITTING,3/8"X6MM ELBOW,Q-DISC
1
7259282
FITTING,BRANCH ELBOW 3/8"X6MM
1
7259283
PIN,LOCATING,LIFT TABLE
1
7213303
BRACKET,ANTI-ROTATE,G5 LIFT
1
7260317
NUT,M8X1.25,THIN
3
7259285
O-RING,11/16"ID X 7/8"OD
1
7259273
SHCS,M3X0.5X35mm,SS
2
7203339
SCREW,M5X.8X8 SHCS
2
7245989
SCREW, M3X.5X16 SOCKET HEAD
1
387983
SCREW, M4X0.7X25MM SHCS, SS
3
388033
SCREW, M4X0.7, BUTTON HEAD, X8
4
388040
SCREW,M8X1.25X20 SOC FLAT HD
1
7222442
SCREW,SET NYLTP
M6X1.0X6MM,SS
1
7260310
WASHER, FLAT M3
2
387964
TUBING,4MM,BLUE
200
7252647
TUBING,4MM,BLACK
200
7252646
TUBING,6MM,BLACK
320
7252645
CABLE,GND,LIFT TABLE
1
7262363
SCREW,D M4X6,SS,SOC HEAD
1
7207192
WASHER, #8 INTERNAL STAR
2
381697
SCREW,M5X14 FHSCS
4
7269937
PLUG, 6MM PUSH
1
7269934
SPRING PLUNGER,M6
1
7225989
SET SCREW,M6X25,FLAT
1
7226647
SCREW, M4 X 0.7, SOCKET X 10
1
388027
FITTING,1/8 FNPT TO 1/8 TUBE
2
7269935
FITTING,1/8 MNPT TO 4MM TUBE
2
7269936
FITTING,1/4" TO 6MM PUSH
1
7269933
KIT,REBUILD,CONVEYOR,EPX
6655130
RAIL,Z STOP JDEC TOOLING
4
7236739
ASSY,STOP PIN,INTEL,HARD
2
6110557
ASSY,INSERT,CONV,W/RLRS,VTG
4
6110562
GUARD DRIVE PULLEY CONV
4
7225401
CLIP,GUARD DRIVE PULLEY CONV
4
7225402
RETAINER,BELT,CMP
20
7213118
ASSY,S-9XX 6MM BELT PULLEY
20
7214226
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
ASYMTEK Vantage® Series Spares List
April 2024 20
SCREW, M4 X 0.7, SOCKET X 10
20
388027
NUT,SQUARE,M4,7X7X2
36
7207258
BELT,FLAT 6MM X 1810MM
8
6110576
MOTOR,NEMA 23 STEPPER
W/CONN
4
7263550
PULLEY,DRIVE,FLAT,ORING,CMP
4
7239006
SCREW, M4 X 0.7, SET, CUP X 10
4
388039
SCREW, M4 X 0.7, SOCKET CAP,X8
16
388026
INSERT,UPPER GUIDE,6MM FLAT
4
7296958
SCREW, M3X.05 FLAT
36
392120
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
KIT,REBUILD,CONVEYOR,DLA
6655131
ASSY,STOP PIN,INTEL,HARD
2
6110557
GUARD DRIVE PULLEY CONV
4
7225401
CLIP,GUARD DRIVE PULLEY CONV
4
7225402
CLAMP,Z STOP
12
7256789
RETAINER,BELT,CMP
20
7213118
ASSY,S-9XX 6MM BELT PULLEY
20
7214226
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
SCREW, M4 X 0.7, SOCKET X 10
20
388027
NUT,SQUARE,M4,7X7X2
36
7207258
BELT,FLAT 6MM X 1810MM
8
6110576
MOTOR,NEMA 23 STEPPER
W/CONN
4
7263550
PULLEY,DRIVE,FLAT,ORING,CMP
4
7239006
SCREW, M4 X 0.7, SET, CUP X 10
4
388039
SCREW, M4 X 0.7, SOCKET CAP,X8
16
388026
INSERT, LOWER GUIDE RAIL
4
7290982
INSERT,UPPER GUIDE,6MM FLAT
4
7296958
SCREW, M3X.05 FLAT
36
392120
SCREW, M4X0.7 SOCKET FLAT X 12
60
388012
KIT,CONVEYOR PNEUMATICS,DLA/EPX
6655132
ASSY,VISUAL FLW CNTRL,INT,VTG
1
6126668
ASSY,PNEUM PAN,VTG,DL
PRG,INTEL
1
6146367
Individual Part List
The following items are sold individually.
Part Description
Lookup Part Number
TIP ADAPT 1/4 NPT PLATED BRASS
7016945
BOOT,VAC .020 ID ORANGE
381521
BOOT,VAC .120 ID OLIVE
381523
O-RING, 1 7/8 OD X 1/16
381649
BOOT,VAC.045 ID GREEN
383818
LID,PURGE,ANTI-SPATTER
6115929
MONITOR,22" WIDESCREEN,VANTAGE
6114668
CABLE-P,PWR,US,L6-6H 309,2.5M
7223281
SW,CANVAS,GEM ADAPTER AND LICENSE
6143242
ASSY,NEEDLE X-Y LOCATOR
392435
BOOT,VAC .031 ID PINK
381522
MOTION CTRL, ELMO PLATINUM
6147352
ENCODER READHEAD,TONIC 5M
7287387
CAMERA,GENIE-NANO 1456X1088
6111122
CABLE-P,PWR,EEUR,IEC309.2.4M
7223282
FIBER ARRAY DIFFUSED
196582
TILE CALIBRATION & DUAL OFFSETS
6138731
PCA,I_F,EXP VAC GAUGE+HTR CNTRL,PRGMD
6139145
MOTOR,NEMA 23 STEPPER W/CONN
7263550
AIR CYLINDER,15MM STROKE
392794
SENSOR,BOARD,LOW PROFILE
7209626
ASSY,Z TCTL,CERAM INST,ADSZ
6112270
ASYMTEK Vantage® Series Spares List
April 2024 21
ASSY,TACTILE SENSOR,DUAL SVC STN
6148560
ASSY,FAN SHELF
7290977
ASSY,FAN 24V W/LEADS
6100934
ASSY, 30A CM POWER MANAGER C30
6100927
ASSY,DOVETAIL MNT BRKT,LEFT,NARW
6136790
PWA,LED DRIVER 1.25A
7216705
SERVO AXIS, DELTA-Y
7291019
AT,CUSTOM IMPG TOOL,318X135,VNTG
6142041
ASSY,RESERVOIR,1GAL,NON-CIRC
7212932
HOSE,1/4 ID,1/4 NPTM SWIVEL,5'
7203818
PLUG,QD,1/4X1/4NPTF
933553
SCANNER, RFID, USB, BIS00W4
6120643
KIT,PURGE LINE,FILTER
7236585
SENSOR,FIBER M3 REFLECTIVE
7236737
BELT,FLAT 6MM X 1810MM
6110576
GENERATOR,VACUUM,PIAB M20
392116
PCA,SYSTEM PROGRAMMED
7287565
