ASYMTEK Vantage® Series Spares List

April 2024 15

CABLE,SMEMA UPSTREAM

1

7238775

CABLE,SMEMA DOWNSTREAM

1

7238776

CABLE,CONV.SOLENOIDS

1

7209636

CABLE,T/C 8 PIN HEAT ADAPTER

1

7215470

KIT,EDGE CLAMP,SNGL,VTG

7297140

FIBER ARRAY DIFFUSED

1

196582

TUBING,PU,BLK 1/8"OD .079"ID

1

386953

TUBING,PU,BLU 1/8"OD 1/16"ID

1

386956

FLOW CONTROL 1/8"

4

7212093

FITTING, REDUCER 1/4TBX1/8TB

2

387436

FITTING,1/4"Y-1/8",QUICK-DISC

2

197668

CABLE TIE,4",BLACK

1

382767

SCREW, M3X0.5, SOCKET CAP, X30

1

387986

SCREW, M4 X 0.7, SOCKET X 10

2

388027

SCREW,M4X0.7 BUTTON X 12

1

7241929

WASHER, FLAT M6

1

388088

SCREW,M6 X 1.0 SOCKET X 16

4

7243615

NUT,SQUARE,M4,7X7X2

3

7207258

ASSY,CLAMP,REAR

1

7239040

ASSY,CLAMP,FRONT

1

7239041

LABEL,SELF LAMINATING,1X2.2"

14

7268706

PIN,STOP,EXTENDED

1

7269916

BRKT,STOP PIN MOUNT,EXTENDED

1

7269917

KIT,INDEX 1,VTG

6149115

ASSY,STOP PIN

1

7237716

SENSOR,BOARD,LOW PROFILE

1

7209626

TUBING,PU,BLK 1/8"OD .079"ID

10

386953

TUBING,PU,BLU 1/8"OD 1/16"ID

10

386956

KIT,FLEX RAIL,400MM,PREQ

6650679

ASSY,MAG, RAIL,ADJ,395MM

1

6140102

RAIL,FRONT,400MM,PREQ,OFFSET

1

6140101

SCREW, M3X6 BUTTON HEAD

3

7244697

KIT,FLEX RAIL,400MM,POSTQ

6650680

ASSY,MAG, RAIL,ADJ,395MM

1

6140102

RAIL,FRONT,400MM,POSTQ,OFFSE

T

1

6140107

SCREW, M3X6 BUTTON HEAD

3

7244697

UK,XLG LIFT TABLE,290X450

6126781

PLATE,TOP,LIFT TABLE,290X450

1

6126083

SCREW,FLAT,M10X1.5X25MM,SOC,

SS

1

193847

SCREW, M3X.5X16 SOCKET HEAD

2

387983

SCREW,M3X.5X25 SOCKET CAP

2

387985

SCREW M5X20MM FLAT H.

PHILLIPS,SS

4

7244126

SCREW,M4X0.7,SOC CAP X5

1

7253694

ASSY,MAG,RAIL,ADJ,460MM

6138151

MAG,RAIL,ADJ,460MM

1

6138152

SCREW, M3 X 0.5 PH.FLAT X 5

6

387973

SCREW, BUTTON HEAD M3 X 10

4

387994

BLOCK,RAIL ADJ,6800

1

7257969

COVER,MAGNET,6800

1

7257970

MAGNET,.25X.5DIA,SAM-COB DISC

3

7274586

KIT,SERVICE,HORIZ DOOR,VTG

6655212

LATCH,PANEL 3 LB

2

392369

WINDOW,ESD POLYCARB,SWNG

DR, VNTG

1

6142857

LATCH,HOLE,45mm,VNTG

1

6142868

COVER,CLEAR,45MM HOLE,SWNG

DR,VNTG

1

6142867

HINGE,SMALL,45mm,HOLE

1

6142870

CABLE,MAG SNSR INTLK EXT

1

7298822

ASSY,MAG SENSOR INTLK

1

6130098

MAGNET KEY CODED FOR SI-

MAGB2SM

1

6130097

ASYMTEK Vantage® Series Spares List

April 2024 16

ASSY,FRU,REG,MAT,VTG

6655213

REGULATOR,MAT,1/2

INL/OUT,4000PSI

1

7425206

FITTING,JIC,1/2 TO 1/2MNPT

2

6148405

GAUGE,2 1/2",0-400PSI,LF,1/4NPT

1

6148410

BUSHING, 1/4 NPT X 1/2 NPT

1

7216031

TEE,RIGHT ANGLE,1/2NPT

2

6148407

FITTING,JIC,1/2 TO 1/4MNPT

2

6148409

FITTING,90DEG,1/2 MNPT TO 1/2

FNPT

2

6148408

LABEL,ZEBRA, 4"X2", THERM WHT

1

7276386

SCREW, 1/4-20 X 1/2 SOCK, CAP

4

387789

ASSY,FRU,REG,FLUID,BF,VTG

6655214

ASSY,REGULATOR,FLUID

1

333825

FITTING, ELBOW,1/8NPT-1/4TUBE

1

387432

FITT,EL 45DEG,1/2-20JICX1/4NPT

1

7210985

LABEL,ZEBRA, 4"X2", THERM WHT

1

7276386

FTG,ELB 45,37D,JIC,1/2TUB,1/4-

18NPT

1

6650693

KIT,FLUID SUPPLY,SINGLE,BF,VTG

6655215

HOSE,PTFE,SS BRAIDED,6FT,#8

1

6148404

HOSE,PTFE,.25 ID,2 FT

1

842024

BRKT,IJ,BRAIDED HOSE TO FEED

TUBE

1

6148417

TIP ADAPT 1/4 NPT PLATED BRASS

1

7016945

CONN,BLKHD,37D,1/4NPT,SS

1

972516

NUT, 1/2-20 HEX

1

7216732

HOSE,1/2ID,5000 PSI,10FT

1

7261919

KIT,AMD,UF,LFS,IJ,30CC,VTG

6650672

SENSOR ASSY,FLUID

SENSORS,15IN

1

195681

HOLDER,SYRINGE,30CC

1

7201407

BASE,CONFIGURABLE 3CC-6OZ

1

6102271

SUPPORT,SYRINGE 3CC-30CC

1

6102264

BRACKET,CAP SENSOR IJ 3CC-6OZ

1

6102258

SCREW, M3 X 10MM, SOCKET CAP

2

387981

SCREW, M3 X 0.5 PH FLAT X 10

2

387975

NUT, HEX M3 X 0.5

2

7242811

SCREW, M3 X 0.5 SOCKET X 6

2

387979

SCREW,M3X4,FLT PT

2

7206804

THUMB SCREW,M3X0.5X11mm

1

6105841

ASSY,RMT FD,1GAL,PNUEMATIC SUB,VT

6147975

FITTING, ELBOW,1/8NPT-1/4TUBE

4

387432

FITTING, 1/4" PLUG-IN Y

1

383188

VALVE,CHECK,SMC

1

197329

FITTING, NIPPLE, HEX 1/4NPT

1

387443

REGULATOR, PILOT OPERATED

1

383798

HOSE,1/4 ID,1/4 NPTM SWIVEL,5'

1

7203818

VALVE, MECH., 3-WAY, 2 PORT

1

7251159

GAUGE,0-100 PSI/KPA

1

7203947

SCREW, M6X10, SOCK, CAP, SS

8

388099

T-NUT,M6,80/20,25 SERIES

8

7200649

BRKT,BEACON,COVER,FSL

1

7224077

T SLOT,1X1IN,1FT

1

6145529

BRKT,REMOTE FEED,VNTG

1

6145526

J1SY,FLUID REGULATOR,C940

1

7211533

FITTING, BULKHEAD, 1/4NPT

1

387435

HINGE,T SLOT,LEVEL LOCK

2

6145527

CONN,MALE,1/4T,X1/4NPT,DELRIN

1

971232

HOSE,PTFE,SS BRAIDED,4FT,#5

1

7241786

PLUG,QD,1/4X1/4NPTF

1

933553

NUT, WATT REGULATOR

1

382652

REGULATOR, MINIATURE, 0-60 PSI

1

7251142

TUBING,PU,BLK 1/4"OD 1/8"ID

2

7241753

PLUG, REGULATOR (BLACK)

1

7257499

ASYMTEK Vantage® Series Spares List

April 2024 17

FITTING,1/4"QD,1/8 NPT

1

7205775

TAPE,PTFE-1/4"

1

382382

T SLOT,1X1IN,2FT

1

6145528

FITT,EL 45DEG,1/2-20JICX1/4NPT

1

7210985

FITTING, PLUG 1/4MPT

2

7244873

LABEL,SILVER MYLAR .5"X1.75"

1

7275811

LABEL,BLANK, FOR PLD

2

7275814

FRU,UK,FLUID HOSE KIT

6653673

HOSE,OPAQUE,SS BRAIDED,4FT,#5

2

7229348

HOSE,OPAQUE,SS BRAIDED,4FT,#6

2

7229349

HOSE,OPAQUE,SS BRAIDED,2FT,#5

2

7229324

HOSE,OPAQUE,SS BRAIDED,3FT,#5

2

7229336

KIT,6 0Z,VTG DH,INTEL,EPX

6147916

ASSY,BRKT,60Z EFD

COOLER,VTG,EPX,LEFT

1

6126000

ASSY,BRKT,60Z EFD

COOLER,VTG,EPX,RIGHT

1

6130745

ASSY,RETAINER,6OZ

EFD,W/COOLER

2

7217475

SCREW, M4 X 0.7, SOCKET X 12

8

388029

ASSY,TUBING,SYRINGE COOLER

2

7218346

ASSY,TUBING,FLUID

PRESSURE,6OZ

2

7219933

MAGNET,35 OD X 25 ID X5THK,N50

NEO

2

6126004

KIT,6 OZ,VTG DH,INTEL,DLA

6147930

ASSY,FEED TUBE,ELBOW-M

LUER,PKG50

1

6130727

ASSY,BRKT,60Z EFD,VTG,DLA,LEFT

1

6147928

ASSY,BRKT,60Z

EFD,VTG,DLA,RIGHT

1

6147929

SCREW, M4 X 0.7, SOCKET X 12

8

388029

ASSY,TUBING,FLUID

PRESSURE,6OZ

2

7219933

MAGNET,35 OD X 25 ID X5THK,N50

NEO

2

6126004

FEED TB,100MM,1/4"MPT L (PAC 50)

1

6130738

ASSY.RETAINER,6OZ,EFD

2

7268468

ASSY,RFID SCANNER,VTG DH,LEFT

6147913

SCANNER, RFID, USB, BIS00W4

1

6120643

CABLE,USB-M12-5PIN, 1M

1

6125995

BRKT, RFID SYRINGE VANTAGE

1

6125993

SCREW, M4 X 0.7, SOCKET X 20

2

388032

CABLE TIE, 3/16" ROUND

1

387910

SCREW, M4 X 0.7, SOCKET CAP,X8

1

388026

ASSY,RFID SCANNER,VTG DH,RIGHT

6147914

SCANNER, RFID, USB, BIS00W4

1

6120643

CABLE,USB-M12-5PIN,1M,ROTATED

1

6136606

BRKT,2ND HEAD,RFID VANTAGE

1

6130744

SCREW, M4 X 0.7, SOCKET X 20

2

388032

CABLE TIE, 3/16" ROUND

1

387910

SCREW, M4 X 0.7, SOCKET CAP,X8

1

388026

ASSY,HEATER IMPNG,JEDEC,LOW MS

7265514

TUBING,PU,CLR 3/8"OD 1/4"ID

0.7

386954

TUBING,PU,TR GRN 1/4"OD 1/8"ID

0.3

7242173

CLAMP,HOSE,TWO-EAR

1

7208227

FITTING, 1/8 FNPT TEE, BRASS

1

7244869

FITTING, 1/8NPT STREET ELBOW

1

382969

FITTING,MALE QR,HI-TEMP,1/4ID

1

7244460

FITT'G, 1/4Q-DISC X 1/8MNPT

1

382656

ELBOW,3/8 TUBE X 1/8 MNPT

1

7200444

SOCKET,MINIFIT,19-24AWG

3

7242542

SOCKET,MINIFIT,22-28AWG TIN

2

7210863

PLUG-M,8S,MINIFIT JR

1

7215458

STRAIN RELIEF,8S MINIFIT JR

1

7215459
