11
Barrel Pistons
barrel
size
white
SmoothFlow
red
tight fit
beige
loose fit
orange
flat-wall
clear
flex
qty/box
3cc 7366134 7366133 7366126 7366132 7366131 100
5cc 7366141 7366140 7366135 7366139 7366138 100
10cc 7366125 7366124 7366117 7366123 7366122 100
30cc, 55cc, 70cc 7366084 7366083 7366076 7366082 7366081 50
barrel
size
blue
LV* Barrier
™
natural
eco-friendly
qty/box
3cc 7366128 7366129 100
5cc − 7366136 100
10cc 7366119 7366120 100
30cc, 55cc, 70cc 7366078 7366079 50
* For watery-thin fluids such as solvents and cyanoacrylates, specify the
blue LV Barrier piston.
Note: Black neoprene rubber pistons are available.
Please contact EFD for ordering information.
www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide. www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
12
Adapter Assemblies
EFD’s unique SnapLok molded barrel adapters ensure easy, positive connection
to the syringe barrel.
Assemblies include the adapter head with Buna N O-ring, 4.0 mm (5/32") OD
flexible polyurethane tubing, male quick-connect, and safety clip.
barrel
size
assembly with
3 ft. (0.9 m) hose
assembly with
6 ft. (1.8 m) hose
assembly with 3 ft (0.9 m)
hose w/ filter trap
blue blue blue
3cc 7012341 7012059 7012063
5cc 7012054 7012058 7012062
10cc 7012339 7012057 7012061
30cc, 55cc, 70cc 7012338 7012056 7012060
www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
13
End Cap
End Caps
• Unique design provides tight snap seal.
• Molded finger tab makes removal easy.
Tip Cap
EFD’s unique molded end caps and
tip caps ensure airtight sealing when
filling or storing syringe barrels.
Adapters, End Caps & Tip Caps
Tip Caps
• Thread-locking design provides positive sealing.
• Eliminates stress and prevents breakage of the barrel
luer taper if the sealed barrel is dropped.
• Opaque for use with any fluid, including UV-sensitive.
barrel size blue green eco-friendly qty/box
3cc 7366108 7366111 7366109 100
5cc 7366113 7366116 7366114 100
10cc 7366104 7366107 7366105 100
30cc, 55cc, 70cc 7366071 7366074 7366072 50
barrel size blue green eco-friendly qty/box
all sizes 7012198
–
7364679 50
all sizes
– 7362541 –
1000
