7 WF3 SX1/2 Check and clean the X- and Y-Axis magnets. 1.5 min 2 / 2 C A U T I O N ! R e f e r t o s a f e t y i n s t r u c t i o n s i n u s e r m a n u a l b e f o r e c o m m e n c i n g M a i n t e n a n c e Machi…
7 WF3 SX1/2 Check and clean the X- and Y-Axis magnets. 1.5 min 1 / 2
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status OFF Transport Empty
NOTICE! ESD guidelines are to be followed Tool:
T3
Wear Part: Consumables:
C3
www.asm-smt.com
1 Move all gantries to the end limit. 2 Check all X-Axis magnets for contamina-
tion and damage.
3 Clean all X-Axis magnets.
4 Move the gantry to the other side. 5 Check all Y-Axis magnets for contamina-
tion and damage.
6 Clean all Y-Axis magnets.
7 WF3 SX1/2 Check and clean the X- and Y-Axis magnets. 1.5 min 2 / 2
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status OFF Transport Empty
NOTICE! ESD guidelines are to be followed Tool:
T3
Wear Part: Consumables:
C3
www.asm-smt.com
7 Repeat all steps at the other gantry.
8 WF3 SX1/2 Clean the X-Axis loose bearing and contact surface. 1 min 1 / 1
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status OFF Transport Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
C4, C31
www.asm-smt.com
1 Move all gantries to the end limit. 2 Clean the loose bearing at the left side of
the head.
3 Clean the loose bearing at the right side of
the head.
4 Clean the contact surface over the entire
length.
5 Repeat all steps at the other gantry.
