15 15 24 25 5 6 17 25 23 6 14 12 5 2 21 19 8 4 10 11 13 5 7 9 1 3 16 6 22 27 17 6 1 14 12 3 5 26 10 20 24 18 2 8 4 16 11 Cover FES12 Base Feeder holder KLS-1402 3-3 OLD NO Parts_No. Parts_Name Q_ty Remarks Compati Revisi…
33
24
27
5
31
10
29
21
30
2
5
32
10
28
5
23
32
26
17
5
6
3
35
17
22
9
22
11
18
9
13
11
14
36
20
34
16
15
8
16
19
25
15
4
11
12
25
1
11
7
3
33
Cover FES12 Top
Feeder holder
KLS-1402
3-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90440-01J030
CIRCLIP
2
2
90440-01J070
CIRCLIP
2
3
90990-01J074
BOLT HEX,SOCKET HEAD
7
4
90990-28J038
WASHER,PLAIN
2
5
91312-03006
BOLT HEX,SOCKET HEAD
8
6
91312-04006
BOLT HEX,SOCKET HEAD
4
7
91312-05008
BOLT HEX,SOCKET HEAD
1
8
91609-25008
PIN SPRING
2
9
92012-04006
BOLT, BOTTON HEAD
6
10
92902-03200
WASHER,PLAIN
4
11
92902-05200
WASHER,PLAIN
4
12
92A08-03303
SCREW SET
2
13
KHJ-MC289-00
PIN,CLAMP
2
14
KLF-M3741-00
PLATE,STOPPER
1
15
KLF-M3742-00
WASHER
2
16
KLF-M3748-00
WASHER
4
17
KLF-M3749-00
WASHER
2
18
KLF-M374A-00
BASE,CLAMP
2
19
KLF-M374B-00
LEVER,CLAMP
2
20
KLF-M374C-00
SPRING,CLAMP
2
21
KLF-M374D-00
BUSH,FLANGE
2
22
KLF-M374G-00
BOLT,SHOULDER
2
23
KLF-M374S-00
GUIDE,FEEDER UPPER
1
24
KLF-M374X-00
PIN,HINGE
2
25
KLS-M3744-00
WASHER
2
26
KLS-M374J-00
GAS DAMPER
1
27
KLS-M374M-00
COVER,TOP
1
28
KLS-M374N-01
DOG,SENSOR R
1
29
KLS-M374N-51
DOG,SENSOR L
1
30
KLS-M374R-00
ARM,UPPER GUIDE R
1
31
KLS-M374T-00
ARM,UPPER GUIDE L
1
32
KLS-M374V-00
HOOK,ARM UPPER GUIDE
2
33
98902-03004
SCREW BINDING HEAD
20
34
99480-04014
PIN,PARALLEL
2
35
KLS-M374P-00
PLATE,UPPER
1
36
KV5-M1356-00
SPACER DOOR
2
15
15
24
25
5
6
17
25
23
6
14
12
5
2
21
19
8
4
10
11
13
5
7
9
1
3
16
6
22
27
17
6
1
14
12
3
5
26
10
20
24
18
2
8
4
16
11
Cover FES12 Base
Feeder holder
KLS-1402
3-3
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
4
2
90990-10J008
SCREW, BINDING HEAD
4
3
90990-11J001
SCREW, PAN HEAD W/W
4
4
91312-03004
BOLT HEX,SOCKET HEAD
4
5
91312-04006
BOLT HEX,SOCKET HEAD
6
6
91312-04008
BOLT HEX,SOCKET HEAD
8
7
91312-05010
BOLT HEX,SOCKET HEAD
6
8
92902-03600
WASHER,PLAIN
4
9
95302-06600
NUT HEXAGON
1
10
97602-03310
SCREW PAN HEAD W/WASHER
2
11
98702-03006
SCREW,FLAT HEAD
4
12
KHJ-MC10S-01
PIN,LOCATE 1
2
13
KLF-M3747-00
PLUNGER
1
14
KLF-M374F-00
STOPPER,ARM
2
15
KLS-M3743-00
STOPPER, TAPE GUIDE
1
15-1
KLS-M3743-01
STOPPER,TAPE GUIDE
1
NG
MJX0088-2012/11/19
16
KLS-M3746-00
BRKT.,STOPPER R
1
16-1
KLS-M3746-01
BRKT.,STOPPER R
1
NG
MJX0088-2012/11/19
17
KLS-M3747-00
BRKT.,STOPPER L
1
17-1
KLS-M3747-01
BRKT.,STOPPER L
1
NG
MJX0088-2012/11/19
18
KLS-M374K-00
BRKT.,SENSOR R
1
19
KLS-M374L-00
BRKT.,SENSOR L
1
20
KLS-M374U-01
COVER,SENSOR R
1
21
KLS-M374U-51
COVER,SENSOR L
1
22
KLS-M374W-00
BASE,ARM R
1
23
KLS-M374Y-00
BASE,ARM L
1
24
KLS-M652D-00
SENSOR
2
25
98702-04006
SCREW,FLAT HEAD
4
26
98902-03004
SCREW BINDING HEAD
4
27
KLS-M3419-00
COVER,MARK
1
13
9
8
2
18
8
7
14
8
1
21
20
15
8
19
17
8
2
23
6
8
4
22
10
9
4
5
4
3
9
9
12
9
12
3
12
12
5
9
4
8
14
4
5
1
2
11
16
4
8
8
8
22
8
8
Reel holder assy
Feeder holder
KLS-1303
3-4
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-01J037
BOLT HEX,SOCKET HEAD
4
2
90990-01J039
BOLT HEX,SOCKET HEAD
14
3
90990-28J168
WASHER,PLAIN
5
4
90990-41J159
COLLAR
8
5
90990-41J160
COLLAR
6
6
91312-03004
BOLT HEX,SOCKET HEAD
2
7
91312-03008
BOLT HEX,SOCKET HEAD
3
8
KHY-M373D-00
BOLT,HEX.SOCKET HEAD
12
9
KHY-M3R15-00
ROLLER
28
10
KLS-M3R01-01
PLATE,SIDE R
1
11
KLS-M3R02-01
PLATE,SIDE L
1
12
KLS-M3R09-01
SHAFT,ROLLER
5
13
KLS-M3R16-00
PARTITION
5
14
KLS-M3R19-01
BRKT.,HOOK
2
15
KLS-M3R20-00
HOOK,REEL HOLDER
1
16
KLS-M3R21-00
HOOK,REEL HOLDER 1
1
17
KLS-M3R22-00
GUIDE,PARTITION
1
18
KLS-M3R24-00
COVER,UNDER 1
1
19
KLS-M3R25-00
COVER,UNDER 2
1
20
KLS-M3R26-00
COVER,REAR 1
1
21
KLS-M3R27-00
PLATE 1
1
22
KLS-M3R29-00
PLATE,GUIDE
2
23
92902-03200
WASHER,PLAIN
2
