21 14 13 17 2 9 20 18 9 1 6 8 12 9 3 10 16 11 19 22 15 7 5 19 4 16 Slope / V alve T_Cutter KLS-1404 7-1 OLD NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 $KM-1 1 MUFFLER 2 2 $NK-2N NYLON CLIP 8 3 $TL4-…
29
20
27
8
43
8
37
14
4
28
38
34
24
25
5
34
23
41
11
12
19
7
9
37
17
7
2
28
5
22
31
42
35
1
32
21
11
13
3
2
10
44
18
7
9
26
39
36
4
30
33
1
40
42
15
6
16
43
Clamp
Clamp
KLS-1404
6-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-01J038
BOLT HEX,SOCKET HEAD
6
2
90990-01J065
BOLT HEX,SOCKET HEAD
4
3
90990-01J074
BOLT HEX,SOCKET HEAD
2
4
90990-20J008
PIN,DOWEL
4
5
91312-04006
BOLT HEX,SOCKET HEAD
6
6
91312-04020
BOLT HEX,SOCKET HEAD
2
7
91312-05010
BOLT HEX,SOCKET HEAD
6
8
91312-06012
BOLT HEX,SOCKET HEAD
8
9
91312-06020
BOLT HEX,SOCKET HEAD
4
10
91312-06040
BOLT HEX,SOCKET HEAD
2
11
KKU-M1138-00
CAM FOLLOWER
8
12
KLS-M3701-00
STAY,SIDE L
1
13
KLS-M3702-00
STAY,SIDE R
1
14
KLS-M3703-01
PLATE,GUIDE L
1
15
KLS-M3704-01
PLATE,GUIDE R-1
1
16
KLS-M3704-10
PLATE,GUIDE R-2
1
17
KLS-M3705-01
BLOCK,CLAMP L
1
18
KLS-M3706-01
BLOCK,CLAMP R
1
19
KLS-M3711-01
SIDE GUIDE L
1
20
KLS-M3712-01
SIDE GUIDE R
1
21
KLS-M3712-10
PLATE,SIDE GUIDE R
1
22
KLS-M3713-01
GUIDE,STOPPER 1
1
23
KLS-M3725-00
GUIDE,STOPPER 2
1
24
KLS-M3727-00
HINGE PIN
2
25
KLS-M3728-00
JOINT,ROLLER
2
26
KLS-M3729-02
BRACKET,SENSOR R
1
27
KLS-M3731-00
LOCATING PIN
1
28
KLS-M3733-00
CLAMP
2
29
KLS-M3734-00
ROLLER FOLLOWER
2
30
KLS-M3735-00
BLOCK,CLAMP 1
1
31
KLS-M3736-01
STAY,SENSOR L
1
32
KLS-M3737-01
BRACKET,SENSOR L
1
33
KLS-M3738-00
PLATE,GUIDE R-3
1
34
KLS-M3739-00
PLATE,GUIDE L-2
2
35
KLS-M652C-01
SEN.ATS CLAMP R ASSY
1
36
KLS-M652C-11
SEN.ATS CLAMP L ASSY
1
37
91312-08016
BOLT HEX,SOCKET HEAD
2
38
91312-08035
BOLT HEX,SOCKET HEAD
5
39
91312-08040
BOLT HEX,SOCKET HEAD
4
40
92A08-03304
SCREW SET
1
41
95302-08600
NUT HEXAGON
4
42
98502-03003
SCREW PAN HEAD
2
43
98780-04012
SCREW,FLAT HEAD
8
44
KLS-M371A-00
STAY,SENSOR R
1
KLS_4-1
21
14
13
17
2
9
20
18
9
1
6
8
12
9
3
10
16
11
19
22
15
7
5
19
4
16
Slope / Valve
T_Cutter
KLS-1404
7-1
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$KM-11
MUFFLER
2
2
$NK-2N
NYLON CLIP
8
3
$TL4-01M
JOINT
2
4
97602-04308
SCREW, PAN HEAD W/W
8
5
90990-12J001
SCREW, BIN. HEAD W/W
4
6
91312-03020
BOLT HEX,SOCKET HEAD
2
7
91312-04006
BOLT HEX,SOCKET HEAD
2
8
91312-04008
BOLT HEX,SOCKET HEAD
2
9
91312-05010
BOLT HEX,SOCKET HEAD
6
10
99480-06012
PIN,PARALLEL
1
11
KHJ-MC10T-01
PIN,LOCATE 2
1
12
KHY-M3T0C-00
CUTTER VALVE
1
13
KLS-M3T15-00
STAY,VALVE
1
14
KLS-M3T16-01
COVER,REAR
1
15
KLS-M3T17-00
STOPPER,REEL HLDR.
2
16
KLS-M3TB1-00
COVER,UPPER 12-1
1
16-1
KLS-M3TB1-01
COVER,UPPER 12-1
1
Resin tape
OK
ML20100-2014/3/13
17
KLS-M3TB5-00
COVER,UPPER 12-2
1
18
KLS-M3TC0-00
DUCT 12,ATS
1
19
98902-04006
SCREW BINDING HEAD
8
20
92902-05600
WASHER,PLAIN
2
21
$TL6-01M
JOINT
1
22
KLS-M3TB6-00
TAPE,SLOPE
1
ML20100-2014/3/13
8
34
29
35
22
19
22
33
23
33
6
27
6
33
17
16
36
15
18
10
10
28
26
4
2
11
15
38
3
16
32
39
36
30
8
20
40
5
21
8
12
25
1
14
26
4
9
13
1
7
24
31
37
TC.Main assy
T_Cutter
KLS-1404
7-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$TL4-02
JOINT
2
2
90990-18J029
PIN,PARALLEL
2
3
90K72-6L0130
LM RAIL,20
2
4
91312-03006
BOLT HEX,SOCKET HEAD
4
5
91312-04006
BOLT HEX,SOCKET HEAD
2
6
91312-04008
BOLT HEX,SOCKET HEAD
2
7
91312-04045
BOLT HEX,SOCKET HEAD
2
8
91312-05008
BOLT HEX,SOCKET HEAD
10
9
91312-05010
BOLT HEX,SOCKET HEAD
3
10
91312-05014
BOLT HEX,SOCKET HEAD
8
11
91312-05016
BOLT HEX,SOCKET HEAD
2
12
KHY-M3T0L-01
CYL. COLLAR 3
1
13
KHY-M3T13-00
CYL. COLLAR 1
1
14
KKT-M3T14-00
CYL. COLLAR 2
1
15
KLF-M3T22-00
SHOCK ABSORBER
2
16
KLF-M3T23-00
STAY,DAMPER
2
17
KLS-M3T01-00
FRAME,CUTTER 12
1
18
KLS-M3T02-00
PLATE,BASE 1
1
19
KLS-M3T03-00
CUTTER,UPPER 12
1
20
KLS-M3T04-00
PLATE,BASE 3
1
21
KLS-M3T05-00
CUTTER,LOWER 12
1
22
KLS-M3T06-00
BAR
2
23
KLS-M3T07-00
PLATE,4 12
1
24
KLS-M3T08-00
CYL.,TAPE CUTTER 12
1
25
KLS-M3T09-00
BLOCK,CYL.
1
26
KLS-M3T10-00
COVER,SIDE
2
27
KLS-M3T11-00
COVER,CUTTER 12-1
1
28
KLS-M3T12-00
STAY,DAMPER
1
29
KLS-M3T13-00
COVER,M 12
3
30
KLS-M3T14-00
COVER,CUTTER 12-2
1
31
KLS-M652B-00
SENSOR CUT. CL ASSY.
1
32
91312-05018
BOLT HEX,SOCKET HEAD
4
33
91312-05030
BOLT HEX,SOCKET HEAD
8
34
91312-06012
BOLT HEX,SOCKET HEAD
2
35
91312-06020
BOLT HEX,SOCKET HEAD
3
36
91312-06030
BOLT HEX,SOCKET HEAD
4
37
91312-06090
BOLT HEX,SOCKET HEAD
4
38
91312-08020
BOLT HEX,SOCKET HEAD
6
39
90K80-020L00
LM BLOCK HSR20-L
2
40
92B12-10035
SCREW,H.S.COUN
1
