C-ATS_pl.pdf - 第22页

25 24 1 18 28 6 39 15 4 5 21 26 29 37 37 39 40 40 23 27 37 21 37 20 19 4 23 4 22 8 6 27 5 7 4 39 28 36 5 26 30 37 38 5 42 38 32 17 42 2 17 33 3 9 10 16 41 13 16 10 9 31 14 31 12 14 1 35 34 18 24 15 11 Hook Stocker KLS-13…

30

30

36

22

10

8

25

12

15

30

33

33

30

28

7

27

32

4

20

33

26

3

28

27

7

18

4

22

3

35

7

17

16

17

11

3

9

16

24

8

6

3

3

14

24

25

31

34

3

9

19

1

13

23

34

21

2

5

29

10

5

Screw

Stocker

KLS-1303

5-2

NO

Parts_No.

Parts_Name

Q_ty

Remarks

Compati

Revision_No._date

1

90152-04J03

SCREW SET

1

2

90152-04J08

SCREW SET

1

3

90933-02J688

BEARING

10

4

90990-28J063

WASHER,PLAIN

4

5

90990-28J070

WASHER,PLAIN

4

6

90KC0-012609

AC SERVO MOTOR

1

7

90990-28J124

WASHER,PLAIN

5

8

91312-03006

BOLT HEX,SOCKET HEAD

16

9

91312-04008

BOLT HEX,SOCKET HEAD

8

10

91312-04010

BOLT HEX,SOCKET HEAD

4

11

91312-04012

BOLT HEX,SOCKET HEAD

4

12

KLS-M1417-00

BELT 196

1

13

KLS-M1418-00

PULLEY 3

1

14

KLS-M1420-00

PLATE,MOTOR

1

15

KLS-M1423-00

BELT 1374

1

16

KLS-M1431-01

PLATE,BRG.

4

17

KLS-M1459-00

SHIM

4

18

KLS-M14B1-00

SHAFT,DRIVE

1

19

KLS-M14B2-00

WASHER

1

20

KLS-M14B3-00

HOUSING,BRG.

1

21

KLS-M14B4-00

PULLEY 1

1

22

KLS-M14B5-00

PULLEY 2

3

23

KLS-M14C1-00

SCREW,GUIDE R

2

24

KLS-M14C2-00

COLLAR

4

25

KLS-M14C3-00

SHAFT

4

26

KLS-M14C4-00

PULLEY

2

27

KLS-M14C5-00

WASHER 02

4

28

KLS-M14C6-00

SHIM

4

29

KLS-M14D1-00

SCREW,GUIDE L

2

30

KLS-M14E0-01

IDLER ASSY

6

A item

OK

MK80075-2013/9/5

31

92990-04200

WASHER,PLAIN

4

32

95602-05100

NUT, U

1

33

95602-06100

NUT, U

5

34

99480-03012

PIN,PARALLEL

4

35

KLS-M14C0-00

SCREW ASSY.1

1

Left

36

KLS-M14D0-00

SCREW ASSY.2

1

Right

25

24

1

18

28

6

39

15

4

5

21

26

29

37

37

39

40

40

23

27

37

21

37

20

19

4

23

4

22

8

6

27

5

7

4

39

28

36

5

26

30

37

38

5

42

38

32

17

42

2

17

33

3

9

10

16

41

13

16

10

9

31

14

31

12

14

1

35

34

18

24

15

11

Hook

Stocker

KLS-1303

5-3

NO

Parts_No.

Parts_Name

Q_ty

Remarks

Compati

Revision_No._date

1

$SC4-M5A

SPEED CONTROLLER

2

2

90152-03J03

SCREW SET

2

3

90990-01J056

BOLT HEX,SOCKET HEAD

2

4

91312-03005

BOLT HEX,SOCKET HEAD

12

5

91312-03006

BOLT HEX,SOCKET HEAD

12

6

91312-04005

BOLT HEX,SOCKET HEAD

4

7

KJY-M923G-00

BRACKET,AMP

1

8

KLH-M9108-10

SENSOR FIBER

1

9

KLH-M91B6-00

WASHER 05

2

10

KLH-M91BN-00

OIL FREE BUSH 2

2

11

KLS-M1406-00

CYLINDER

1

12

KLS-M1408-00

KNUCKLE

1

13

KLS-M1410-00

WASHER 05

1

14

KLS-M1411-00

OIL FREE BUSH 2

2

15

KLS-M1412-00

WASHER 05

2

16

KLS-M1416-01

LINK 2

2

17

KLS-M1419-00

WASHER 10

2

18

KLS-M1422-00

COLLAR

2

19

KLS-M1441-00

HOOK 1

1

20

KLS-M1442-00

HOOK 2

1

21

KLS-M1443-00

STOPPER 3

2

22

KLS-M1444-00

LM GUIDE 120

1

23

KLS-M1445-01

BLOCK

2

24

KLS-M1446-00

BRACKET,LINK

2

25

KLS-M1447-00

STOPPER

1

26

KLS-M1448-00

BRACKET 1

2

27

KLS-M1449-00

BRACKET 2

2

28

KLS-M1450-01

BLOCK,SENS.

2

29

KLS-M1451-01

BRACKET,SENS.1

1

30

KLS-M1452-01

BRACKET,SENS.2

1

31

KLS-M1455-00

BRACKET,SENS.

2

32

KLS-M1465-00

BRACKET,SENS.3

1

33

KLS-M653H-11

SEN.PICK ORG ASSY

1

34

KLS-M653L-00

SEN.P.GUIDE OP ASSY

1

35

KLS-M653L-10

SEN.P.GUIDE CL ASSY

1

36

KLS-M654A-00

AMP,SENSOR 2

1

37

91312-04006

BOLT HEX,SOCKET HEAD

10

38

91312-04008

BOLT HEX,SOCKET HEAD

2

39

91312-04010

BOLT HEX,SOCKET HEAD

6

40

91312-04012

BOLT HEX,SOCKET HEAD

8

41

91312-04020

BOLT HEX,SOCKET HEAD

2

42

92990-04200

WASHER,PLAIN

2

37

29

35

30

6

18

10

11

25

30

35

44

15

22

21

37

36

22

16

1

20

41

3

38

32

36

2

7

13

43

23

33

34

2

14

38

38

31

17

24

11

4

40

8

18

42

38

19

12

29

14

26

22

14

28

27

39

5

8

9

42

22

14

Base

Stocker

KLS-1404

5-4

OLD

NO

Parts_No.

Parts_Name

Q_ty

Remarks

Compati

Revision_No._date

1

$NK-3N

NYLON CLIP

7

2

90152-03J03

SCREW SET

4

3

90990-01J043

BOLT HEX,SOCKET HEAD

2

4

90990-01J049

BOLT HEX,SOCKET HEAD

2

5

90990-01J071

BOLT HEX,SOCKET HEAD

2

6

90990-11J007

SCREW, PAN HEAD W/W

2

7

90990-41J025

COLLAR

1

8

91312-03008

BOLT HEX,SOCKET HEAD

4

9

91312-04008

BOLT HEX,SOCKET HEAD

5

10

91312-04010

BOLT HEX,SOCKET HEAD

2

11

91312-04012

BOLT HEX,SOCKET HEAD

8

12

91312-04014

BOLT HEX,SOCKET HEAD

3

13

91312-04016

BOLT HEX,SOCKET HEAD

4

14

91312-04020

BOLT HEX,SOCKET HEAD

12

15

KKX-M6555-00

JUNCTION BOX V

1

16

KLS-M1401-00

BASE

1

17

KLS-M1402-00

PLATE

1

18

KLS-M1403-00

BASE

1

18-1

KLS-M1403-01

BASE

1

NG

MK30022-2013/4/24

19

KLS-M1421-01

BRACKET,TENSION

1

20

KLS-M1426-01

FRAME 1

1

21

KLS-M1427-01

FRAME 2

1

22

KLS-M1428-00

BLOCK

2

22-1

KLS-M1428-01

BLOCK

2

OK

MK30024-2013/5/7

23

KLS-M1432-00

GUIDE,STAY 1

1

24

KLS-M1433-01

GUIDE 1

1

25

KLS-M1434-01

STOPPER 1

1

26

KLS-M1437-00

GUIDE,STAY 2

1

27

KLS-M1438-00

GUIDE 2

1

28

KLS-M1439-00

STOPPER2

1

29

KLS-M1440-00

GUIDE 2

2

30

KLS-M1454-00

PLATE,AMP

1

30-1

KLS-M1454-01

PLATE,AMP

1

NG

MK30024-2013/5/7

31

KLS-M1461-00

BOLT

1

32

KLS-M1466-00

PLATE

1

33

KLS-M1467-00

BLOCK,MIRROR

1

34

KLS-M1470-00

MIRROR TAPE

1

35

KLS-M653J-00

SEN.PALLET LOW ASSY

1

36

91312-06040

BOLT HEX,SOCKET HEAD

4

37

91312-06045

BOLT HEX,SOCKET HEAD

6

38

92902-04200

WASHER,PLAIN

16

39

92990-04200

WASHER,PLAIN

2

40

95302-04600

NUT HEXAGON

1

41

97602-04308

SCREW PAN HEAD W/WASHER

7

42

99480-04014

PIN,PARALLEL

4

43

99480-04018

PIN,PARALLEL

1

44

91312-05012

BOLT HEX,SOCKET HEAD

2
