2nd SMT Engineering Division Software Group
IM Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50395
1/11
Chip Vacuum Check
Function Specifications
History of revision
Rev Version Chapter Contents
00 V3.45STD R1.000
V4.49STD R1.000
All Created
01 V3.47STD R1.000
V4.51STD R5.000
6, 8 Change of defaults in “Parts Fall Vacuum Level”
本文書に含まれる技術内容は当社の秘密情報です。当社の許諾無く第三者への開示はできません。
The information contained in this message may be confidential and legally protected under applicable
law. The message is intended solely for the addressee(s).
If you are not the intended recipient, you are hereby notified that any use, forwarding, dissemination, or
reproduction of this message is strictly prohibited and maybe unlawful.
2nd SMT Engineering Division Software Group
IM Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50395
2/11
Contents
Contents..............................................................................................................................................................................2
1. Model and Version....................................................................................................................................................3
2. Purpose of function..................................................................................................................................................3
2.1 Background..........................................................................................................................................................3
2.2 Purpose..................................................................................................................................................................3
3. Function overview.....................................................................................................................................................4
3.1 Outline.....................................................................................................................................................................4
3.2 Period of Chip Vacuum Check....................................................................................................................4
3.3 Timing to output errors....................................................................................................................................5
4. Error Message............................................................................................................................................................5
5. Recovery from error.................................................................................................................................................6
6. Setting Method...........................................................................................................................................................7
7. Log Function................................................................................................................................................................9
7.1 Overview................................................................................................................................................................9
7.2 Format.....................................................................................................................................................................9
7.3 Setting Method....................................................................................................................................................9
Table 7.1 Setting Item (Software Setting).....................................................................................................9
8. Precaution at using this function.....................................................................................................................10
8.1 Recommended Nozzle Type.....................................................................................................................10
8.2 Nozzle Specification at update.................................................................................................................10
2nd SMT Engineering Division Software Group
IM Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50395
3/11
1. Model and Version
Supported models and version are as follows.
Table1.1 Model and Version
Model Software Version Note
YS12 / YS12P / YS12F
YG12 / YG12F
YS88
YS100
YS24 / YS24X
YC8
V3.45STD R1.000 or later
YSM20 V4.49STD R1.000 or later
2. Purpose of function
2.1 Background
On small chip parts such as 0603, difference of vacuum level between open and close is
too small to judge parts existence properly. Therefore, parts existence used to be checked
by camera recognition, but it couldn’t find dropped parts after recognition.
2.2 Purpose
This function enables parts existence check by vacuum level from after camera recognition
until before mounting. This will prevent mount failure and misalignment.
