Copyright © ViT rox All Rights Reserved . Engineer Inspection Result 16 NEW Existing ❖ Inspection List display inspection result in Part Number and Reference Designator . ➢ The existing GUI only shows Ref Des. ❖ Smart GU…
Copyright © ViTrox All Rights Reserved.
Engineer mode UI
15
Algo Trainer
Copyright © ViTrox All Rights Reserved.
Engineer Inspection Result
16
NEWExisting
❖ Inspection List display inspection
result in Part Number and
Reference Designator.
➢ The existing GUI only
shows Ref Des.
❖ Smart GUI also display the total
defects and cycle time.
➢ The existing GUI only
shows the failed quantity.
❖ Summary table for defect
captured by AOI.
Copyright © ViTrox All Rights Reserved.
Package Manager
17
Additional Info during
package board
