SM481_PLUS_TRM(Ver1.2_CS17.02).pdf - 第67页
Page +$1:+$ 55 SM481 PLUS Conveyor Ass’y(2/4) NO. Lev . PA R T N O . P ART NAME Q'TY Old No. Supply Supply L T Reference
Page
+$1:+$
54
SM481
PLUS
Conveyor Ass’y(2/4)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
27 J70531029B STOPPER_POST 1
28 J7053770A IDLER SHAFT-M[J7053770A] 3
29 J7053048A IDLER SPACER-M 3
31 J7253009B STOPPER 2 [J7253009B] 2
32 J7153036A SLIDE GUIDE 3
33 J7253008A STOPPER 2
34 J7153010B ADJUST SHAFT [J7153010B] 2
35 J7153034A CLAMP SHAFT 2
36 FC18-901355 C-RING DIA11(HOLE) 2
37 MC06-900006 BALL_BUSH LMU5 2
38 J7153033A BUSH SPACER 2
39 MC06-900006 BALL_BUSH LMU5 2
40 J70531100B BRACKET_SENSOR_IN 2 CX-461A-C05 (PANASONIC)
41 FC09-002127A BRACKET-SENSOR_OUT_P;SPCC 1 BYD30-DDT (AUTONICS)
J70531100B BRACKET_SENSOR_IN 1 CX-461A-C05 (PANASONIC)
42 FC39-000975A FRAME-CONV_FRONT_P;A6N01S-T5 1
43 EP19-900092 PHOTOELECTRIC SENSOR [BYD30-DDT] 2 BYD30-DDT (AUTONICS)
EP19-001025 SENSOR,OPTIC-[CX-461],1,MIGRATION 2 CX-461A-C05 (PANASONIC)
44 J90831439B_AS CONV_BELT1_STEP_MOTOR_ASSY 1 AM03-007407A / AM03-007407B LONG TYPE: J90831441B
45 J90831439B_AS CONV_BELT1_STEP_MOTOR_ASSY 1 AM03-007405A / AM03-007405B LONG TYPE: J90831431B
Page
+$1:+$
55
SM481
PLUS
Conveyor Ass’y(2/4)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
Page
+$1:+$
56
SM481
PLUS
Conveyor Ass’y(3/4)
1
22
2
2
6
24
12
15
17
19
5
5
6
24
25
7
8
4
3
3
20
20
5
24
6
5
6
8
24
27
26
10
13
23
8
5
6
16
18
11
11
9
10
11
21
24
14
8
5
6
24
7
6
24
5
19
25
