BASE SYSTEM 3-10 AP Excel Series Drawings Guide Theta\Z Movement Assembly AP25-07 (1 of 2) 41 AP2507_1 37 15 40 39 41 42 42 17 31 16 43 43 28 36 36 37 45 46 18 27 44 46 6 32 Note: Items 13, 18 and 32 Mount to Main Base F…
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-9
59 A2-867 CLAMP, SWING BAR ARM 1
63 P0183 SWITCH, PROXIMITY 1
65 P0423 CLAMP, WIRE AND CABLE, NYLON, 3/8" DIA, STYLE A 3
66 1001525 COVER, STATIC, PROHEAD 1
67 P6135 WASHER, CURVED SPRING, .203 ID X .322 OD X .043 2
70 P1476 BEARING, SUPER 8 4
71 P1477 RING, INTERNAL RETAINING, .875 ID HOUSING 8
73 P1591 BEARING, NEEDLE ROLLER, 1/4 ID X 7/16 OD X1/4 2
74 P1594 BEARING, LINEAR RAIL 2
77 1004645 BRACKET, HINGE, PRO-HEAD COVER 2
79 P1606 MOTOR COUPLING 1
81 P1623 SCREW, SET, NYLON TIP, 4-40 X 5/32" LG. 1
83 P1811 CYLINDER, RODLESS, .627" BORE, .50" STROKE 2
88 P1834 CYLINDER, AIR, RODLESS, W/1/8" NPT, ELBOW FITTING 2
89 P2169 BEARING, ANGULAR CONTACT, 6MM ID X 24MM OD X 15MM 1
90 P2219 CYLINDER, SINGLE ACTING, REVERSE, 1/2" BORE, 1/2" ST 1
93 P6077 MAGNET, ROUND HORSESHOE, .687 DIA. X .688 THK. 2
95 P4078 SPACER, SHAFT, 7/16" ID X 9/16" OD X .125", SS 1
98 P0422 CLAMP, WIRE AND CABLE, NYLON, 5/16" DIA STYLE A 3
101 10-32 X 1/2" SHCS —
102 10-32 X 3/8"" SHCS —
103 6-32 X 3/8" FHS —
104 4-40 X 3/4" SHCS —
105 6-32 X 3/8" SHCS —
106 2-56 X 1/4" SHCS —
107 2MM X 10MM SHCS —
108 6-32 X 5/16" SHCS —
109 #6 FLAT WASHER —
110 10-32 X 1/4" SHCS —
111 8-32 X 3/8" SHCS —
112 10-32 X 3/4" SHCS —
113 10-32 X 1" SHCS —
114 4-40 X 3/8" SHCS —
129 P4153 SCREW, SHOULDER, .187 DIA X .375, #8-32, SS303 2
Programmable Squeegee Head 1007483 Parts Listing (Continued)
Key No. Part No. Description Quantity
BASE SYSTEM
3-10 AP Excel Series Drawings Guide
Theta\Z Movement Assembly AP25-07 (1 of 2)
41
AP2507_1
37
15
40
39
41
42
42
17
31
16
43
43
28
36
36
37
45
46
18
27
44
46
6
32
Note: Items 13, 18 and 32 Mount to Main Base Frame.
(Same parts on both sides)
(Same parts on both sides)
19
37
13
13
36
37
36
37
36
34
37
49
20
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-11
Theta\Z Movement Assembly AP25-07 (2 of 2)
AP2507_2
Theta Stop
mounting
1
14
34
33
14
33
26
25
See AP25-75
Theta Drive Assembly
See detail
above
1
14
33
47
2
34
Front
Sets
Only
7
34
34
12
3
4
47
38
8
38
11
38
5
38
8
2
Rear
sets
only
5
