BASE SYSTEM 3-34 AP Excel Series Drawings Guide Optic Probe Kit 1000163 Parts Listing Key # Part # Description Quantity 1 P2180 CUBE, MIDDLE 1 2 P2179 CUBE, T OP 1 3 P2181 CUBE, BOTTOM 1 4 P1437 LENS ELEMENT NO. 1 POC-1 …
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-33
Optic Probe Kit 1000163
1000163
4
5
3
1
2
Not in this Assembly
See IPB AP20-73
BASE SYSTEM
3-34 AP Excel Series Drawings Guide
Optic Probe Kit 1000163 Parts Listing
Key # Part # Description Quantity
1 P2180 CUBE, MIDDLE 1
2 P2179 CUBE, TOP 1
3 P2181 CUBE, BOTTOM 1
4 P1437 LENS ELEMENT NO. 1 POC-1 1
5 P1438 LENS ELEMENT NO. 2 POC-2 1
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-35
Vision Platen Kit 990518
Not in this Assembly
See IPB AP25-26
990518
1
4
2
3
6
5
