. . . . . BASE SYSTEM AP Excel Series Drawings Guide 3-31 Vision Assembly AP25-26 Parts Listing Key No. Part No. Description Quantity 1 1003648 BRACKET, CABLE CARRIER , RIGHT 1 2 1003651 BRACKET, CABLE CARRIER , LEFT 1 3…
BASE SYSTEM
3-30 AP Excel Series Drawings Guide
Vision Assembly AP25-26
29
7
62
Not in this Assembly
See IPB 990518
63
5
22
46
46
16
14
55
6
27
45
8
13
39
43
53
42
43
12
26
10
4
40
3
32
15
20
41
40
41
32
17
11
20
2
1
25
37
37
37
38
52
25
30
30
44
24
40
25
25
9
30
27
45
30
30
24
40
43
18
36
32
19
35
23
AP2526_1
36
36
37
37
37
39
42
40
15
44
31
54
29
43
53
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-31
Vision Assembly AP25-26 Parts Listing
Key No. Part No. Description Quantity
1 1003648 BRACKET, CABLE CARRIER, RIGHT 1
2 1003651 BRACKET, CABLE CARRIER, LEFT 1
3 1003652 CAP, LEFT Y-FORCER 1
4 1003653 CAP, RIGHT Y-FORCER 1
5 1004240 DAMPENER, NOISE, VISION CABLE CARRIER 1
6 A2-1252-P1 MOUNT, X CABLE TRAY, LEFT 1
7 A2-1252-P2 MOUNT, X CABLE TRAY, RIGHT 1
8 A2-1328 SUPPORT, LEFT GANTRY 1
9 A2-1329 SUPPORT, GANTRY NO 2 1
10 A2-467 SUPPORT, GANTRY NUMBER 1, RIGHT 1
11 1004117 BRACKET, X CABLE CARRIER 1
12 A2-472-P1 SUPPORT, GANTRY NUMBER 3, RIGHT 1
13 A2-472-P2 SUPPORT, GANTRY NUMBER 3, LEFT 1
14 A2-475 TRAY, X-CABLE, UPPER 1
15 A2-476 MOUNT, PROXIMITY SWITCH, X-AXIS 2
16 1004118 TRAY, VISION, X CABLE, CARRIER 1
17 A2-485 CAP, X-FORCER 1
18 A2-536-P1 RAIL, VEE GUIDE, RIGHT 1
19 A2-536-P2 RAIL, VEE GUIDE, LEFT 1
20 A2-563 CABLE WAY 2
21 A2-567 HARD INSERT (NOT SHOWN) 4
22 A2-651 CABLE WAY COVER 1
23 A2-652 CLAMP, U-JOINT NO. 1, RIGHT 1
24 A2-654 SHAFT, Y-BEARING 2
25 A2-662 CLAMP, U-JOINT, NUMBER 3 4
26 A2-664 BEARING SHAFT, X-RIGHT 1
27 P0050 WASHER, FLAT, 13/64 ID X 1/2 OD X 3/32 W 4
28 P0183 SWITCH, PROXIMITY (NOT SHOWN) 3
29 P0962 TUBING, POLYURETHANE, 1/8 X 3/16 BLACK —
30 P1329 BEARING, BALL, .250 I.D. X .625 O.D. X .196 THK. 10
31 P1959 LABEL, CAUTION, PLATEN 1
32 P2235 FITTING, ELBOW, SWIVEL, 10-32 X 1/8 ID TUBE 3
34 P2888 CARRIER, CABLE, 1.46 WD, 1.18 RAD, 41 LINKS (NOT SHOWN) 2
35 1004247 CARRIER, CABLE, 17 LINKS, ASSY 1
BASE SYSTEM
3-32 AP Excel Series Drawings Guide
36 10-32 X 3/8” FHS —
37 6/32 X 1/2” SHCS —
38 4-40 X 3/16” FHS —
39 4-40 X 3/16” SHCS —
40 6/32 X 1/4” SHCS —
41 6/32 X 3/8” SHCS —
42 4-40 X 1/4” SHCS —
43 8-32 X 3/8” SHCS —
44 6-32 X 1-1/8” SHCS —
45 10-32 X 5/8” SHCS —
46 4-40 X 1/4” BHCS —
52 10-32 X 1/4’ SS DOG POINT —
53 #8 FLAT WASHER —
54 6-32 X 1/4” BHCS —
55 6-32 X 1/4” FHS —
62 P3201 BRACKET, IGUS, WITH PIN 1
63 P3202 BRACKET, IGUS, WITH BORE 1
VISION PLATEN KIT (SEE IPB 990518)
VISION PNEUMATIC ASSEMBLY (SEE ASSY DWG 1000145)
