BASE SYSTEM
3-6 AP Excel Series Drawings Guide
Programmable Squeegee Head 1007483 (1 of 2)
teflon washer
(supplied)
13
81
89
11
104
14
10
90
54
63
41
101
101
101
2
40
79
4
5
12
36
103
102
101
107
105
34
106
107
45
74
45
101
38
35
105
74
39
106
95
*
See Sheet 3 for mounting
*
*
*
*
*
101
101
1007483_1
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-7
Programmable Squeegee Head 1007483 (2 of 2)
46
73
52
109
105
53
113
112
113
112
113
112
49,70,71
109
105
In from
CA-471
Left Float
CA-589-2
19
58
Right Float
CA-589-1
1007483_2
49,70,71
49,70,71
114
73
6
3
59
17
18
111
43
108
88
32
83
56
110
30
32
31
102
teflon washer
(supplied)
supplied with
Part #83
1
37
102
Parts stack and
installation is identical
on both sides
Shown
Installed
77
71
70
71
49
Installation is identical
for all 4 Bearing Housings
77
93
67
129
65
65
65
113
112
49,70,71
114
BASE SYSTEM
3-8 AP Excel Series Drawings Guide
Programmable Squeegee Head 1007483 Parts Listing
Key No. Part No. Description Quantity
1 P0728 FITTING, ELBOW, 10-32 X .170 ID TUBING 2
2 1003906 ASSEMBLY, MOTOR, SQUEEGEE DOWN STOP 1
3 1004262 BAR, MOUNT RHEOMETRIC PUMP-HEAD 1
4 1001801 BRAKE, PROHEAD 1
5 1001838 LOCKNUT, BEARING, M6 1
6 P0857 SPACER, 1/4 RD, .140 ID X 1/4, AL 2
10 A2-1203 NOSE, CYLINDER 1
11 A2-1260 BLOCK, BEARING 1
12 A2-1261 PLATE, RETAINING 1
13 A2-1431 WASHER, PRECISION, .237" ID X .500" OD X .125", SS 1
14 A2-1554 SCREW, BALL, ASSY 1
17 A2-700 MOUNT, BEAM SPRING 1
18 A2-701 CLAMP, BEAM SPRING 1
19 A2-702 SHAFT, LEFT BEARING 1
30 A2-718 CONNECTOR, SHAFT 2
31 A2-719 MOUNT, CYLINDER 2
32 A2-720 PLATE, MOUNT, CYLINDER 4
34 A2-724-P1 MOUNT, BEARING 1
35 A2-724-P2 MOUNT, BEARING 1
36 A2-725 PLATE, MAIN MOUNTING 1
37 A2-726 MOUNT, BEARING PLATE 1
38 A2-727-P1 MOUNT, MOVING BEARING 1
39 A2-727-P2 MOUNT, MOVING BEARING 1
40 A2-728 MOUNT, MOTOR 1
41 A2-734 MOUNT, NUT 1
43 A2-775 FLAG, PROXIMITY SWITCH 1
45 A2-825 PLATE, MECHANICAL STOP 2
46 A2-826 SHAFT, SWING ARM 1
49 A2-829 HOUSING, BEARING 4
52 A2-832-P1 MOUNT, ZERO WEIGHT SENSOR, RIGHT 1
53 A2-832-P2 MOUNT, ZERO WEIGHT SENSOR, LEFT 1
54 A2-833 PLATE, NUT 1
56 A2-856 MOUNT, BALANCE CYLINDER 2
58 A2-866 ASSEMBLY, SHAFT, RIGHT BEARING 1
