Industry 4.0
Intelligent Software Solutions
Software solutions from Rehm allow the reliable control and monitor-
ing of the solar equipment
The software components are consisting of monitoring tools and vari-
ous modules, each of which completes its own individual task. Master
software compiles the data and evaluates it, for instance in order to
keep the specied parameters constant for the respective manufactur-
ing prole. The modular system can be assembled into individualized
packages and matched to the customer’s respective requirements.
Custom tailored master software is available for each system type.
With over 25 years of experience in the SMT industry, Rehm
has adapted its wafer tracking and traceability functions
from their vast experience in reflow ovens for the electronics
industry.
A variety of packages are possible for the Speedre Firing
Furnace and the RDS Dryer in the eld of traceability and
process interlocking:
› Traceability/Process traceability via hand-held
scanner (order-specific)
› Process interlocking via fixed position scanners
› Process interlocking and traceability via fixed
position scanners
Wafer tracking and traceability is becoming ever more impor-
tant to guarantee quality production and satisfy the end cus-
tomers. The seamless traceability of every wafer, paired with
the process and the actual production parameters should be
ensured.
A data set containing the relevant process parameters during
the process is generated in a le for each wafer. Means that
batch or serial numbers, work orders, temperatures, belt
speed, proles and others in the oven software are stored.
Internal wafer tracking provides the customer with the pos-
sibility to match every incoming wafer with the oven process
parameters, such IR lamp output, temperature, etc. at any
given position within the oven.
Traceability and process interlocking
optimal
traceability
4.0
industry
Data and facts:
Detail of Speedre Firing Furnace | Throughput 5300 wph
Technical specications
Supply data
Dimensions
TRANSPORT SYSTEM
Transport lanes: Dual lane
Belt system: Continuous belt system
Conveyor width: 540 mm
Product clearance: 30 mm
Belt speed range: 1–10 m/min
Belt speed accuracy: < 0,5 % max. speed
Belt type: Mesh belt
Transport height: 930 +/-50 mm
Throughput direction: Left to right/right to left
DIMENSIONS
Length: 10700 mm
Width: 1870 mm
Height: 2000 mm
HEATING ZONES
Furnace max. temp. ring: 1000 °C
Furnace max. temp. drying: 450 °C
Typical heat up time: 40 min
*
Typical ramp rate heatig: 80 – 140 K/s
Surface temperature covers: ≤ 35°C
Temperature uniformity (unloaded): +/- 1,0 °C
Temperature uniformity (loaded): +/- 5,0 °C
Heating zones drying: 7
Heating zones burnout/ring: 5/3
WAFER TEMPERATURE AT EXIT
Water temperature 12 – 15 °C
*:
≤ 35 °C
Water temperature 17– 20 °C
:
≤ 50 °C
COOLING ZONE
Cooling type: air/water
Cooling length: 2200 mm
Typical cooling rate: 40 – 120 k/s
Water pressure: min. 1,5 bar
Water temperature: 12 – 15 °C
Water flow rate: min. 20 l/min
WATER
Exhaust air dryer/ring: max. 700/2000 m³/h
Max. changeover rate: ~ 6/min
Flow rate CDA: max. 50 ³/h
Required CDA pressure: 6 bar
GAS/AIR
*
at 70 % heating output for
prolonged heater life time
*
recommended
Footprint: 20 m²
Weight: 5000 kg
Load per Base: 500 kg
15
