SIPLACE Pro 14.0 (R16-2) / Version Description 12/2016 Edition
10
3 Prerequisites
NOTICE
System requirements
The Support Media included in the installation package checks the necessary system
requirements of your system and installs these. Amongst others e.g. Microsoft .NET
Framework, the ASM License Manager, the ASM Error Reporter Service and the ASM
Operation Manager.
The use of the Support Media V2.4 is mandatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the ASM Support Media 2.4
Software Version Description, item no. [00900052-xx].
SIPLACE Pro requires an NTFS partition for the installation. FAT or FAT32 file systems are not
supported.
3.1 Supported Station Software Versions and Machine Types
Station Software
Version
Machine Types
710 DX-series: DX1, DX2, DX4
*)
SX-series: SX1/SX2, SX1/SX2 V2, SX4
*)
X-series: X2
*)
, X3
*)
, X4
*)
, X4i
*)
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
TX-series: TX1, TX2, TX2i, TX2 micron, TX2i micron
709 DX-series: DX1, DX2, DX4
*)
SX-series: SX1/SX2, SX1/SX2 V2, SX4
*)
X-series: X2
*)
, X3
*)
, X4
*)
, X4i
*)
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
TX-series: TX1, TX2, TX2i
708 DX-series: DX1, DX2, DX4
*)
SX-series: SX1/SX2, SX1/SX2 V2, SX4
*)
X-series: X2
*)
, X3
*)
, X4
*)
, X4i
*)
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4
SIPLACE Pro 14.0 (R16-2) / Version Description 12/2016 Edition
11
605 D-series: D1, D2, D3
*)
, D4
X-series: X2
*)
, X3
*)
, X4
*)
505 S23HM
*)
, S25HM
*)
, S27HM
*)
, HS50
*)
, HS60
*)
,
HF
*)
, HF/3
*)
408/101 CS
*)
, CF
*)
407 S20
*)
, F4
*)
, F5
*)
, S23
*)
, F5HM
*)
Table 3-1: Supported station software versions and machine types
*)
discontinued
SIPLACE Pro 14.0 (R16-2) / Version Description 12/2016 Edition
12
3.2 Supported Feeder Types
The following feeders are supported by SIPLACE Pro:
– 4 mm – 104 mm X-feeder
– 2x8 mm X-feeder
– 16 mm XN-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– SIPLACE Glue Feeder
– SIPLACE JTF-S (X-series S and SX1/SX2 V2 only)
– SIPLACE JTF-M (X-series S, X4i S micron and SX1/SX2 V2 only)
– SIPLACE JTF-ML 14X and JTF-ML 18X (TX-series only)
– SIPLACE BulkFeeder X
– Arbitrary Carrier X
– Conveyor Carrier X
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– FFI feeders:
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE MSF 60 AX
IPTE MSF XL80 AX
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Dip module for X-tables (LDU_X)
– MTC2 (X2, X3, X4 on location 2 and 4, X2 S, X3 S, X4 S on location 2)
– WPC5 / WPC6 (SX1/SX2, X-series S on location 2)
– SIPLACE Wafer Systems (CA-series only)
– Splice sensor X-feeder
