SUB CONTOROL PANEL SUB CONTOROL PANEL LOOP3 ADD-B 3110 NON USE 3160 NON USE 4030 INVERTOR RUN SIGNAL IN 3111 NON USE 3161 NON USE 4031 INVERTOR A…
IFR2 IFR2 SUB CONTOROL PANEL
2320 H MOVEMENT PATTERN 1 +0° M→S 2370 H MOVEMENT PATTERN 9 +180° M→S 3040 TAPE CUTTER DUMPER SW SUBCON
2321 H MOVEMENT PATTERN 2 +0° M→S 2371 H MOVEMENT PATTERN10 +180° M→S 3041 OPTION 4 SW SUBCON
2322 H MOVEMENT PATTERN 3 +0° M→S 2372 INSIDE OF TACT MOVEMENT +180° M→S 3042 OPTION 10 SW SUBCON
2323 H MOVEMENT PATTERN 4 +0° M→S 2373 OUT OF TACT MOVEMENT +180° M→S 3043 LOADER BELT SW SUBCON
2324 H MOVEMENT PATTERN 5 +0° M→S 2374 NON USE 3044 OPTION 13 SW SUBCON
2325 H MOVEMENT PATTERN 6 +0° M→S 2375 NON USE 3045 OPTION 19 SW SUBCON
2326 H MOVEMENT PATTERN 7 +0° M→S 2376 NON USE 3046 NON USE
2327 H MOVEMENT PATTERN 8 +0° M→S 2377 ENABLING INPUT 3047 NON USE
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2330 H MOVEMENT PATTERN 9 +0° M→S 3000 OPTION 1 SW SUBCON 3050 △ SW SUBCON
2331 H MOVEMENT PATTERN10 +0° M→S 3001 ROTARY CHUCK 1 SW SUBCON 3051 CHANGING TRANSFER PITCH. SW SUBCON
2332 INSIDE OF TACT MOVEMENT +0° M→S 3002 26 TRANSFER CHUCK SW SUBCON 3052 SLIDE TRAVERSE SW SUBCON
2333 OUT OF TACT MOVEMENT +0° M→S 3003 HEAD SERVO OFF SW SUBCON 3053 OPTION 5 SW SUBCON
2334 NON USE 3004 OPTION 7 SW SUBCON 3054 OPTION 11 SW SUBCON
2335 NON USE 3005 UNLOADER RAIL SW SUBCON 3055 CARRY TRAVERSE SW SUBCON
2336 NON USE 3006 P.C.B. PUSH IN SW SUBCON 3056 OPTION 14 SW SUBCON
2337 NON USE 3007 OPTION 16 SW SUBCON 3057 OPTION 20 SW SUBCON
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2340 H MOVEMENT PATTERN 1 +270° M→S 3010 NON USE 3060 NON USE
2341 H MOVEMENT PATTERN 2 +270° M→S 3011 NON USE 3061 NON USE
2342 H MOVEMENT PATTERN 3 +270° M→S 3012 LOAD SW SUBCON 3062 ▽ SW SUBCON
2343 H MOVEMENT PATTERN 4 +270° M→S 3013 ROTARY CHUCK 2 SW SUBCON 3063 CO. REMOVING A PART SW SUBCON
2344 H MOVEMENT PATTERN 5 +270° M→S 3014 52 TRANSFER CHUCK SW SUBCON 3064 SLIDE RETURN SW SUBCON
2345 H MOVEMENT PATTERN 6 +270° M→S 3015 OPTION 2 SW SUBCON 3065 OPTION 6 SW SUBCON
2346 H MOVEMENT PATTERN 7 +270° M→S 3016 OPTION 8 SW SUBCON 3066 OPTION 12 SW SUBCON
2347 H MOVEMENT PATTERN 8 +270° M→S 3017 UNLOADER BELT SW SUBCON 3067 CARRY RETURN SW SUBCON
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2350 H MOVEMENT PATTERN 9 +270° M→S 3020 P.C.B. SUPPLY SW SUBCON 3070 OPTION 15 SW SUBCON
2351 H MOVEMENT PATTERN10 +270° M→S 3021 OPTION 17 SW SUBCON 3071 OPTION 21 SW SUBCON
2352 INSIDE OF TACT MOVEMENT +270° M→S 3022 NON USE 3072 NON USE
2353 OUT OF TACT MOVEMENT +270° M→S 3023 NON USE 3073 NON USE
2354 NON USE 3024 RESET SW SUBCON 3074 NON USE
2355 NON USE 3025 ROTARY CHUCK 3 SW SUBCON 3075 NON USE
2356 NON USE 3026 JW SET SW SUBCON 3076 NON USE
2357 NON USE 3027 OPTION 3 SW SUBCON 3077 NON USE
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2360 H MOVEMENT PATTERN 1 +180° M→S 3030 OPTION 9 SW SUBCON 3100 OPTION 1 LED SUBCON
2361 H MOVEMENT PATTERN 2 +180° M→S 3031 LOADER RAIL SW SUBCON 3101 ROTARY CHUCK 1 LED SUBCON
2362 H MOVEMENT PATTERN 3 +180° M→S 3032 POSITIONER LEVER SW SUBCON 3102 26 TRANSFER CHUCK LED SUBCON
2363 H MOVEMENT PATTERN 4 +180° M→S 3033 OPTION 18 SW SUBCON 3103 HEAD SERVO OFF LED SUBCON
2364 H MOVEMENT PATTERN 5 +180° M→S 3034 NON USE 3104 OPTION 7 LED SUBCON
2365 H MOVEMENT PATTERN 6 +180° M→S 3035 NON USE 3105 UNLOADER RAIL LED SUBCON
2366 H MOVEMENT PATTERN 7 +180° M→S 3036 HEAD TEACHING SW SUBCON 3106 P.C.B. PUSH IN LED SUBCON
2367 H MOVEMENT PATTERN 8 +180° M→S 3037 ROTARY CHUCK 4 SW SUBCON 3107 OPTION 16 LED SUBCON
SUB CONTOROL PANEL SUB CONTOROL PANEL LOOP3 ADD-B
3110 NON USE 3160 NON USE 4030 INVERTOR RUN SIGNAL IN
3111 NON USE 3161 NON USE 4031 INVERTOR ABNORMAL SIGNAL IN
3112 LOAD LED SUBCON 3162 ▽ LED SUBCON 4032 CARRY ARM RETURN DETECTION IN
3113 ROTARY CHUCK 2 LED SUBCON 3163 CO. REMOVING A PART LED SUBCON 4033 CARRY ARM FEED SLOW DOWN DETE. IN
3114 52 TRANSFER CHUCK LED SUBCON 3164 SLIDE RETURN LED SUBCON 4034 CARRY ARM TRAVERSE DETECTION IN
3115 OPTION 2 LED SUBCON 3165 OPTION 6 LED SUBCON 4035 POSI.PIN COUPLING TRAVERSE LI. IN(OP)
3116 OPTION 8 LED SUBCON 3166 OPTION 12 LED SUBCON 4036 POSI.PIN COUPLING RETURN LIMI. IN(OP)
3117 UNLOADER BELT LED SUBCON 3167 CARRY RETURN LED SUBCON 4037 SPARE IN(OP)
SUB CONTOROL PANEL SUB CONTOROL PANEL LOOP3 ADD-C
3120 P.C.B. SUPPLY LED SUBCON 3170 OPTION 15 LED SUBCON 4040 VACUUM UPPER LIMIT (BSF-V) IN
3121 OPTION 17 LED SUBCON 3171 OPTION 21 LED SUBCON 4041 VACUUM LOWER LIMIT (BSF-V) IN
3122 NON USE 3172 NON USE 4042 PCB VACUUM DETECTION (BSF-V) IN
3123 NON USE 3173 NON USE 4043 PCB CARRY TRAVERSE LIM.(BSF-V) IN
3124 RESET LED SUBCON 3174 NON USE 4044 PCB CARRY RETURN LIMIT (BSF-V)IN
3125 ROTARY CHUCK 3 LED SUBCON 3175 NON USE 4045 BSF PCB DETECT LIMIT (BSF-V) IN
3126 JW SET LED SUBCON 3176 NON USE 4046 SAFETY COVER SW (BSF-V) IN
3127 OPTION 3 LED SUBCON 3177 NON USE 4047 MLP INPUT SIGNAL IN(OP)
SUB CONTOROL PANEL LOOP3 ADD-8 LOOP3 ADD-D
3130 OPTION 9 LED SUBCON 4000 UNLOADER RAIL TRAVERSE LIMIT IN 4050 VACUUM SW (BSF-V) IN
3131 LOADER RAIL LED SUBCON 4001 UNLOADER RAIL RETURN LIMIT IN 4051 UP SW (BSF-V) IN
3132 POSITIONER LEVER LED SUBCON 4002 P.C.B. DETECTION 3 IN 4052 DOWN SW (BSF-V) IN
3133 OPTION 18 LED SUBCON 4003 P.C.B. DETECTION 4 IN 4053 RAIL OPEN/CLOSE SW (BSF-V) IN
3134 NON USE 4004 LEFT SIDE EMERGENCY STOP SIG. IN 4054 FORWARD SW (BSF-V) IN
3135 NON USE 4005 P.C.B. DETECTION 6 IN(OP) 4055 REVERSE SW (BSF-V) IN
3136 HEAD TEACHING LED SUBCON 4006 PUSH ARM/PUSH UP TRAVERSE LIM. IN 4056 L SIDE W.CLOSING INTERLOCK IN(OP)
3137 ROTARY CHUCK 4 LED SUBCON 4007 PUSH ARM/PUSH UP RETURN LIMIT IN 4057 UL SIDE W.CLOSING INTERLOCK IN(OP)
SUB CONTOROL PANEL LOOP3 ADD-9 LOOP3 ADD-E
3140 TAPE CUTTER DUMPER LED SUBCON 4010 XY TABLE INSIDE PCB DETECTION IN 4060 NON USE
3141 OPTION 4 LED SUBCON 4011 TABLE COUPLING TRAVERSE LIMIT IN(OP) 4061 NON USE
3142 OPTION 10 LED SUBCON 4012 TABLE COUPLING RETURN LIMIT IN(OP) 4062 NON USE
3143 LOADER BELT LED SUBCON 4013 POSI.ERR DETECTION RETURN LIM. IN 4063 NON USE
3144 OPTION 13 LED SUBCON 4014 POSITIONER LEVER TRAVERSE LIM. IN 4064 NON USE
3145 OPTION 19 LED SUBCON 4015 POSITIONER LEVER RETURN LIMIT IN 4065 NON USE
3146 NON USE 4016 XY TABLE INSIDE PCB DETECTION2 IN(OP) 4066 NON USE
3147 NON USE 4017 SPARE IN(OP) 4067 NON USE
SUB CONTOROL PANEL LOOP3 ADD-A LOOP3 ADD-F
3150 △ LED SUBCON 4020 LOADER RAIL TRAVERSE LIMIT IN 4070 NON USE
3151 CHANGING TRANSFER PITCH. LED SUBCON 4021 LOADER RAIL RETURN LIMIT IN 4071 NON USE
3152 SLIDE TRAVERSE LED SUBCON 4022 P.C.B. DETECTION 1 IN 4072 NON USE
3153 OPTION 5 LED SUBCON 4023 P.C.B. DETECTION 2 IN 4073 NON USE
3154 OPTION 11 LED SUBCON 4024 RIGHT SIDE EMERGENCY STOP SIG. IN 4074 NON USE
3155 CARRY TRAVERSE LED SUBCON 4025 P.C.B. DETECTION 5 IN(OP) 4075 NON USE
3156 OPTION 14 LED SUBCON 4026 P.C.B. SUPPLY TRAVERSE LIMIT IN 4076 NON USE
3157 OPTION 20 LED SUBCON 4027 P.C.B. SUPPLY RETURN LIMIT IN 4077 NON USE
LOOP4 ADD-8 LOOP4 ADD-D LOOP3 ADD-2
4100 NON USE 4150 NON USE 4220 LOADER BELT MOTOR RIGHT TURN OUT
4101 NON USE 4151 NON USE 4221 LOADER BELT MOTOR REVERSE TURN OUT
4102 NON USE 4152 NON USE 4222 UNLOADER BELT MOTOR RIGHT TURN OUT
4103 NON USE 4153 NON USE 4223 UNLOADER BELT MOTOR REVE. TURN OUT
4104 NON USE 4154 NON USE 4224 JW SUPPLY MOTOR SIGNAL OUT(OP)
4105 NON USE 4155 NON USE 4225 JW SUPPLY FORWARD MOTOR RELAY OUT(OP)
4106 NON USE 4156 NON USE 4226 JW SUPPLY REVERSE MOTOR RELAY OUT(OP)
4107 NON USE 4157 NON USE 4227 DUST COLLECTOR ACTION SIGNAL OUT
LOOP4 ADD-9 LOOP4 ADD-E LOOP3 ADD-3
4110 NON USE 4160 NON USE 4230 RAIL OPEN/CLOSE VALVE (BSF-V) OUT
4111 NON USE 4161 NON USE 4231 PCB CONV.MOTOR REV.TURN(BSF-V) OUT
4112 NON USE 4162 NON USE 4232 PCB CONV.MOTOR RIG.TURN(BSF-V) OUT
4113 NON USE 4163 NON USE 4233 PCB CONV. MOTOR BRAKE (BSF-V) OUT
4114 NON USE 4164 NON USE 4234 VACUUM VALVE (BSF-V) OUT
4115 NON USE 4165 NON USE 4235 VACUUM SUCTION VALVE UP(BSF-V) OUT
4116 NON USE 4166 NON USE 4236 VACUUM SUCTION VAL.DOWN(BSF-V) OUT
4117 NON USE 4167 NON USE 4237 NON USE
LOOP4 ADD-A LOOP4 ADD-F LOOP3 ADD-4
4120 NON USE 4170 NON USE 4240 OUT
4121 NON USE 4171 NON USE 4241 HEAD ROTATE CYL (TRAVERSE) OUT
4122 NON USE 4172 NON USE 4242 HEAD ROTATE CYL (RETURN) OUT
4123 NON USE 4173 NON USE 4243 ANVIL ROTATE CYL (TRAVERSE) OUT
4124 NON USE 4174 NON USE 4244 ANVIL ROTATE CYL (RETURN) OUT
4125 NON USE 4175 NON USE 4245 SPARE OUT(OP)
4126 NON USE 4176 NON USE 4246 SPARE OUT(OP)
4127 NON USE 4177 NON USE 4247 SPARE OUT(OP)
LOOP4 ADD-B LOOP3 ADD-0 LOOP3 ADD-5
4130 NON USE 4200 LOADER RAIL VALVE OUT 4250 NON USE
4131 NON USE 4201 LOADER RAIL RETURN VALVE OUT 4251 NON USE
4132 NON USE 4202 UNLOADER RAIL VALVE OUT 4252 NON USE
4133 NON USE 4203 UNLOADER RAIL RETURN VALVE OUT 4253 NON USE
4134 NON USE 4204 POSITIONER LEVER VALVE OUT 4254 NON USE
4135 NON USE 4205 P.C.B. POSITIONER VALVE(R)POS. OUT(OP) 4255 NON USE
4136 NON USE 4206 P.PUSH TRAVERSE VALVE OUT 4256 CONVEYOR BELT MOTOR SIGNAL OUT
4137 NON USE 4207 P.PUSH RETURN VALVE OUT 4257 NON USE
LOOP4 ADD-C LOOP3 ADD-1 LOOP3 ADD-6
4140 NON USE 4210 INVERTOR FORWARD SIGNAL OUT 4260 NON USE
4141 NON USE 4211 INVERTOR REVERSE SIGNAL OUT 4261 NON USE
4142 NON USE 4212 INVERTOR SPEED COMMAND 1 OUT 4262 NON USE
4143 NON USE 4213 INVERTOR SPEED COMMAND 2 OUT 4263 NON USE
4144 P.C.B. STANDBY DETECTION 1 IN(OP) 4214 INVERTOR ABNORMAL RESET OUT 4264 NON USE
4145 NON USE 4215 TRANSFER BRAKE RELEASE OUT 4265 NON USE
4146 NON USE 4216 P.C.B. STOPPER 1 VALVE OUT(OP) 4266 NON USE
4147 NON USE 4217 P.C.B. STOPPER 2 VALVE OUT(OP) 4267 NON USE
