ＡＤＤＲＥＳＳ ＮＯ． ＦＵＮＣＴＩＯＮ ＲＥＭＡＲＫＳ ０００００∼０００７７ ＬＯＯＰ１ (INPUT) （＃８∼＃Ｆ） ＩＮ ００１００∼００１７７ ＬＯＯＰ２ (INPUT) （＃８∼＃Ｆ） ＩＮ ００２００∼００２７７ ＬＯＯＰ１ (OUTPUT) （＃０∼＃７）ＯＵＴ ００３００∼００３７７ ＬＯＯＰ２ (OUTPUT) （＃０∼＃７）ＯＵＴ ０１０００∼０１３７７ ＭＥＭＯＲＹ１ ０２０００∼０２１７７ ＩＦＲ１ （Ｍ→Ｓ…
Program Sheet Symbols
Types Symbols Reading
Logic
conditions
Monitoring
Indication
Actions
Input
This symbol indicates the first priority of the conditions that conform “OFF”.
or
Output
Comp
ound
This symbol indicates the conditions”AND”,that conform”ON”.
Auxi
liary
This symbol indicates “OFF”of the output power(Lamp etc).
This symbol indicates the conditions”OR”,that conform”ON”.
This symbol indicates the first priority of the conditions that conform “ON”.
This symbol indicates the conditions”AND”,that conform”OFF”.
This symbol indicates the conditions”OR”,that conform”OFF”.
This symbol indicates”ON” (Self retainer)of the output power(Lamp etc).
This symbol indicates “ON”or”OFF” (Self retainer)of the output power(Lamp etc).
If conditions are satisfied in the line where symbol mark””exists,the program
is executed till the next””appears for the following lines.
If not,the program is not executed.
If signal(memory,output power)is set to ON,it is switched to OFF.
If signal(memory,output power)is set to OFF,it is switched to ON.
ＡＤＤＲＥＳＳ ＮＯ．
ＦＵＮＣＴＩＯＮ ＲＥＭＡＲＫＳ
０００００∼０００７７
ＬＯＯＰ１(INPUT)
（＃８∼＃Ｆ） ＩＮ
００１００∼００１７７
ＬＯＯＰ２(INPUT)
（＃８∼＃Ｆ） ＩＮ
００２００∼００２７７
ＬＯＯＰ１(OUTPUT)
（＃０∼＃７）ＯＵＴ
００３００∼００３７７
ＬＯＯＰ２(OUTPUT)
（＃０∼＃７）ＯＵＴ
０１０００∼０１３７７ ＭＥＭＯＲＹ１
０２０００∼０２１７７ ＩＦＲ１ （Ｍ→Ｓ）
０２２００∼０２３７７ ＩＦＲ２ （Ｍ→Ｓ）
０３０００∼０３０７７
SUB CONTOROL PANEL(INPUT) SUB CONTOROL PANEL SW
０３１００∼０３１７７
SUB CONTOROL PANEL(OUTPUT) SUB CONTOROL PANEL LED
０４０００∼０４０７７
ＬＯＯＰ３(INPUT)
（＃８∼＃Ｆ） ＩＮ
０４１００∼０４１７７
ＬＯＯＰ４(INPUT)
（＃８∼＃Ｆ） ＩＮ
０４２００∼０４２７７
ＬＯＯＰ３(OUTPUT)
（＃０∼＃７）ＯＵＴ
０４３００∼０４３７７
ＬＯＯＰ４(OUTPUT)
（＃０∼＃７）ＯＵＴ
０５０００∼０５００７ ＳＹＳＴＥＭ ＩＮＦＯＭＡＴＩＯＮ
０５３００∼０５３５７ ＳＣ ＳＯＦＴ ＴＩＭＥＲ
TIMER START OUTPUT/TIMER UP INPUT
０５３６０∼０５３７７ ＣＯＵＮＴＥＲ
COUNTER INC.OUTPUT/COUNTER UP INPUT
０６０００∼０６０１７ ＣＯＵＮＴＥＲ
COUNTER DEC.OUTPUT/COUNTER ACK.INPUT
０６０２０∼０６０３７
ＣＯＵＮＴＥＲ／ＳＹＳＴＥＭ ＩＮＦ．
COUNTER RESET OUTPUT/LOOP ERROR INPUT
０７０００∼０７３７７ ＭＥＭＯＲＹ２
１２０００∼１２１７７ ＩＦＲ１
（Ｓ→Ｍ）
１２２００∼１２３７７ ＩＦＲ２
（Ｓ→Ｍ）
【ＳＣ ＡＤＤＲＥＳＳ ＭＡＰ】
LOOP1 ADD-8 LOOP1 ADD-D LOOP2 ADD-A
0000 M.ORIGIN CT1 0050 CHUCK SLIDE STOP TRAVERSE LIM. IN 0120 AIR DOWN (PRESSURE SW) IN
0001 1BLOCK CHECK/POINTER RENEW CT2 0051 CHUCK SLIDE STOP RETURN LIMIT IN 0121 COVER SW AT FRONT IN
0002 C.CHUCK(TACT P. OUT T)/U TASK CT3 0052 PARTS DETECTION IN 0122 COVER SW AT REAR IN
0003 θH TASK START/WH TASK CT4 0053 DUMPER RETURN DETECTION IN 0123 COVER SW OF LEFTSIDE AT FRONT IN
0004 Z&T 2nd T.ZONE CHECK/XY TASK CT5 0054 CASSETTE DETECTION (52mm) IN 0124 REAR UPPER COVER SW IN
0005 POINTER RENEW/WA TASK CT6 0055 BAD MARK DETECTION IN(OP) 0125 LOADER COVER SW IN
0006 θH 180ﾟ&270ﾟH DECELE. START CT7 0056 DOUBLE PCB TRANSFER INPUT IN(OP) 0126 UNLOADER COVER SW IN
0007 U AXIS INTERFERENCE FREE ZONE CT8 0057 LCD FAN OPERATION DETECTION IN 0127 ENABLEING SW IN
LOOP1 ADD-9 LOOP1 ADD-E LOOP2 ADD-B
0010 θH 180ﾟ&270ﾟH AXIS STOP CT9 0060 T AXIS ORIGIN DETECT IN 0130 LEFT COVER SW OF CENTER AT RE. IN
0011 AXISES TASK START/INS CHECK CT10 0061 26mm SHUNTING DETECTION IN 0131 RIGHT COVER SW OF CENTER AT R. IN
0012 26&52 EXCHANGE COMPLETION CHE. CT11 0062 JW SET TRAVERSE LIMIT IN 0132 COVER SW OF LEFTSIDE AT REAR IN
0013 T AXIS INTACT CT12 0063 JW SET RETURN LIMIT IN 0133 COVER SW OF RIGHTSIDE AT REAR IN
0014 10 PATTREN DECELERATION START CT13 0064 CHUCK No.1 IN 0134 EMERGENCY STOP SIGNAL(ES3/4/5) IN
0015 H AXIS DECELERATION START CT14 0065 CHUCK No.2 IN 0135 ZL SHUNTING SW CHECK SIGNAL IN
0016 T AXIS OUT OF TACT CT15 0066 H AXIS BRAKE RELEASE (INPUT) IN 0136 ZR SHUNTING SW CHECK SIGNAL IN
0017 INSERTION ERROR CHECK CT16 0067 H AXIS BRAKE SW IN 0137 FOR EVALUATION INPUT IN
LOOP1 ADD-A LOOP1 ADD-F LOOP2 ADD-C
0020 SIGNAL FOR SC OUTPUT CT17 0070 NON USE 0140 DO (P937) IN
0021 26 CHUCK BACKWARD CYL CT18 0071 NON USE 0141 D1 (P937) IN
0022 ROT CHUCK STATION (QH 0 ROT) CT19 0072 NON USE 0142 D2 (P937) IN
0023 ROT CHUCK STATION (QH 90 ROT) CT20 0073 NON USE 0143 D3 (P937) IN
0024 CENTERING CHUCK (PATTERN 4) CT21 0074 NON USE 0144 D4 (P937) IN
0025 SLIDER CHUCK (QH 0 ROT CT22 0075 NON USE 0145 D5 (P937) IN
0026 ROTARY CHUCK SLIDE STATION CT23 0076 NON USE 0146 D6 (P937) IN
0027 CENTERING CHUCK CT24 0077 NON USE 0147 D7 (P937) IN
LOOP1 ADD-B LOOP2 ADD-8 LOOP2 ADD-D
0030 XY MULTI INTERLOCK 1 CT25 0100 INSERTION CHECK 1 IN 0150 DVLD (P937) IN
0031 SLIDER CHUCK (QH 180 ROT) CT26 0101 INSERTION CHECK 2 IN 0151 X/Y (P937) IN
0032 XY MULTI INTERLOCK 2 CT27 0102 EMERGINCY STOP SIGNAL IN 0152 OUT OF AREA (P937) IN
0033 CT28 0103 SERVO FREE SIGNAL IN 0153 ANVIL ROTATION TRAVERSE LIMITIN
0034 ROT CHUCK STATION (QH 180 ROT) CT29 0104 LOADER SROCKER READY SIGNAL IN 0154 ANVIL ROTATE TRAVERSE LIMIT IN
0035 INSERTION INSPECTION CT30 0105 UNLOADER STOCKER READY SIGNAL IN 0155 AUTO WIDTH OPERAT.COMLE.SIGNAL IN(OP)
0036 COMPONENT INSPECTION CT31 0106 THERMAL TRIP (VACUUM PUMP) IN 0156 NON USE
0037 SLIDER CHUCK (QH 90 ROT) CT32 0107 THERMAL TRIP (DUST COLLECTOR) IN 0157 NON USE
LOOP1 ADD-C LOOP2 ADD-9 LOOP2 ADD-E
0040 MAINTENANCE SW INPUT IN 0110 ZL SHUNTING SW IN 0160 LOADER RAIL UP SW IN(OP)
0041 HEAD ROTATE RETURN LIMIT IN 0111 ZL CHANGE SW IN 0161 LOADER RAIL DOWN SW IN(OP)
0042 HEAD ROTATE TRAVERSE LIMIT IN 0112 ZL CASSETTE GAP IN 0162 UNLOADER RAIL UP SW IN(OP)
0043 HANDLE DETECTION IN 0113 SAFETY RELEASE BUZZER NOR. DET. IN 0163 UNLOADER RAIL DOWN SW IN(OP)
0044 HEAD BRAKE RELEASE ENABLE SW IN 0114 ZR SHUNTING SW IN 0164 WARNING LAMP (GREEN)(LM→SC) IN(OP)
0045 PARTS EXHAUST DETECTION IN 0115 ZR CHANGE SW IN 0165 WARNING LAMP (WHITE)(LM→SC) IN(OP)
0046 JUMPER SUPPLY IN 0116 ZR CASSETTE GAP IN 0166 WARNING LAMP (YELLOW)(LM→SC) IN(OP)
0047 JUMPER SUPPLY STOP IN 0117 IN 0167 WARNING LAMP (Y BLINK)(LM→SC) IN(OP)
