Memory2 Memory2 Memory2 7100 CHUCK STATION CHUCK NO.1 MEMORY 7150 P.C.B. DETECTION 4 MEMORY 7220 HEAD ROTATE TRAVERSE ERROR 1 MEMORY 7101 CHUCK …
S C SOFT TIMMER LOOP ERROR Memory2
5350 ZR PARTS EXHAUST FINISH TM41 6020 NON USE 7030 OPTION 9 MEMORY
5351 PCB POSITION (R) TRAVERSE TM42 6021 NON USE 7031 LOADER RAIL MEMORY
5352 POSITIONER LEVER ACTION TM43 6022 NON USE 7032 POSITIONER LEVER MEMORY
5353 CHUCK SLIDE TRAVERSE ACTION TM44 6023 NON USE 7033 OPTION 18 MEMORY
5354 CHUCK SLIDE RETURN ACTION TM45 6024 NON USE 7034 JUMPER SET VALVE (RETURN) MEMORY
5355 MAINTENANCE ACTION 1 TM46 6025 NON USE 7035 NON USE
5356 PARTS CHANGE MOTOR POWER CUT TM47 6026 NON USE 7036 HEAD TEACHING MEMORY
5357 ZL PARTS EXHAUST FINISH TM48 6027 NON USE 7037 ROTARY CHUCK 4 MEMORY
COUNTER UP (INPUT) LOOP ERROR Memory2
5360 NON USE 6030 NON USE 7040 TAPE CUTTER DUMPER MEMORY
5361 NON USE 6031 NON USE 7041 OPTION 4 MEMORY
5362 NON USE 6032 NON USE 7042 OPTION 10 MEMORY
5363 NON USE 6033 NON USE 7043 LOADER BELT MEMORY
5364 NON USE 6034 NON USE 7044 OPTION 13 MEMORY
5365 NON USE 6035 NON USE 7045 OPTION 19 MEMORY
5366 NON USE 6036 NON USE 7046 NON USE
5367 NON USE 6037 NON USE 7047 NON USE
COUNTER UP (INPUT) Memory2 Memory2
5370 NON USE 7000 OPTION 1 MEMORY 7050 △ MEMORY
5371 NON USE 7001 ROTARY CHUCK 1 MEMORY 7051 CHANGING TRANSFER PITCH MEMORY
5372 NON USE 7002 26 TRANSFER CHUCK MEMORY 7052 SLIDE TRAVERSE MEMORY
5373 NON USE 7003 HEAD SERVO OFF MEMORY 7053 SLIDE RETURN MEMORY
5374 NON USE 7004 OPTION 7 MEMORY 7054 OPTION 11 MEMORY
5375 NON USE 7005 UNLOADER RAIL MEMORY 7055 CARRY TRAVERSE MEMORY
5376 NON USE 7006 P.C.B. PUSH IN MEMORY 7056 OPTION 14 MEMORY
5377 NON USE 7007 OPTION 16 MEMORY 7057 OPTION 20 MEMORY
COUNTER UP (INPUT) Memory2 Memory2
6000 NON USE 7010 NON USE 7060 NON USE
6001 NON USE 7011 NON USE 7061 NON USE
6002 NON USE 7012 LOAD MEMORY 7062 ▽ MEMORY
6003 NON USE 7013 ROTARY CHUCK 2 MEMORY 7063 CO. REMOVING A PART MEMORY
6004 NON USE 7014 52 TRANSFER CHUCK MEMORY 7064 SLIDE RETURN MEMORY
6005 NON USE 7015 OPTION 2 MEMORY 7065 OPTION 6 MEMORY
6006 NON USE 7016 OPTION 8 MEMORY 7066 OPTION 12 MEMORY
6007 NON USE 7017 UNLOADER BELT MEMORY 7067 CARRY RETURN MEMORY
COUNTER UP (INPUT) Memory2 Memory2
6010 NON USE 7020 P.C.B. SUPPLY MEMORY 7070 OPTION 15 MEMORY
6011 NON USE 7021 OPTION 17 MEMORY 7071 OPTION 21 MEMORY
6012 NON USE 7022 NON USE 7072 NON USE
6013 NON USE 7023 NON USE 7073 NON USE
6014 NON USE 7024 RESET MEMORY 7074 NON USE
6015 NON USE 7025 ROTARY CHUCK 3 MEMORY 7075 COVER OPEN MEMORY
6016 NON USE 7026 JW SET MEMORY 7076 COVER CLOSE MEMORY
6017 NON USE 7027 OPTION 3 MEMORY 7077 SAFETY SEQUENCE CHECK MEMORY
Memory2 Memory2 Memory2
7100 CHUCK STATION CHUCK NO.1 MEMORY 7150 P.C.B. DETECTION 4 MEMORY 7220 HEAD ROTATE TRAVERSE ERROR 1 MEMORY
7101 CHUCK STATION CHUCK NO.2 MEMORY 7151 P.C.B. DETECTION 6 MEMORY 7221 HEAD ROTATE RETURN ERROR 1 MEMORY
7102 CHUCK STATION CHUCK NO.3 MEMORY 7152 XY TABLE INSIDE PCB DETECTION MEMORY 7222 ANVIL ROTATE TRVERSE ERROR MEMORY
7103 CHUCK STATION CHUCK NO.4 MEMORY 7153 XY TABLE INSIDE PCB DETECTION2 MEMORY 7223 ANVIL ROTATE RETURN ERROR MEMORY
7104 CENTERING ACTION 1 MEMORY 7154 CARRY ARM RETURN DETECTION MEMORY 7224 JW SUPPLY STOP DETECT ERROR MEMORY
7105 CENTERING ACTION 2 MEMORY 7155 CARRY ARM TRAVERSE DETECTION MEMORY 7225 HANDLE ERROR MEMORY
7106 CENTERING ACTION 3 MEMORY 7156 LOADER COVER SW MEMORY 7226 HEAD ROTATE TRAVERSE ERROR 2 MEMORY
7107 CENTERING ACTION 4 MEMORY 7157 UNLOADER COVER SW MEMORY 7227 HEAD ROTATE RETURN ERROR 2 MEMORY
Memory2 Memory2 Memory2
7110 DOUBLE PCB TRANSFER MODE MEMORY 7160 LOADER RAIL VALVE MEMORY 7230 ROTARY CHUCK(CENTERING) VAL.1 A MEMORY
7111 DOUBLE PCB TRANSFER SW ERROR MEMORY 7161 UNLOADER RAIL VALVE MEMORY 7231 ROTARY CHUCK(CENTERING) VAL.2 A MEMORY
7112 DOUBLE PCB TAKE OUT MEMORY 7162 P.C.B. STOPPER 1 VALVE MEMORY 7232 ROTARY CHUCK(CENTERING) VAL.3 A MEMORY
7113 XY INSIDE PCB DETECT CHECK MEMORY 7163 P.C.B. STOPPER 2 VALVE MEMORY 7233 ROTARY CHUCK(CENTERING) VAL.4 A MEMORY
7114 1ST PCB TAKE OUT MEMORY 7164 INVERTOR FORWARD SIGNAL MEMORY 7234 CENTERING CHUCK VALVE1 ACTION MEMORY
7115 2ND PCB TAKE OUT MEMORY 7165 INVERTOR REVERSE SIGNAL MEMORY 7235 CENTERING CHUCK VALVE2 ACTION MEMORY
7116 LOADER RAIL LOAD MISS 2 MEMORY 7166 LD BELT MOTOR RIGHT TURN MEMORY 7236 CENTERING CHUCK VALVE3 ACTION MEMORY
7117 L.STOP MEMORY 7167 LD BELT MOTOR REVERSE TURN MEMORY 7237 CENTERING CHUCK VALVE4 ACTION MEMORY
Memory2 Memory2 Memory2
7120 LOADER RAIL PCB EFFECTIVE MEMORY 7170 UL BELT MOTOR RIGHT TURN MEMORY 7240 NON USE
7121 UNLOADER RAIL PCB EFFECTIVE MEMORY 7171 UL BELT MOTOR REVERSE TURN MEMORY 7241 NON USE
7122 DIVISION TRANSFER MODE 1 MEMORY 7172 RAIL LOWERING MEMORY 7242 NON USE
7123 DIVISION TRANSFER MODE 2 MEMORY 7173 LOADER RAIL RETURN ACTION MEMORY 7243 NON USE
7124 DIVISION TRANSFER MODE 3 MEMORY 7174 UNLOADER RAIL RETURN ACTION MEMORY 7244 NON USE
7125 DIVISION PCB TAKE IN PROHIBIT. MEMORY 7175 POSITIONER LEVER ACTION MEMORY 7245 NON USE
7126 AUTO WIDTH ACTION MEMORY 7176 SEMI AUTO 1 MEMORY 7246 NON USE
7127 WARNING LAMP GREEN MEMORY 7177 SEMI AUTO 2 MEMORY 7247 NON USE
Memory2 Memory2 Memory2
7130 ROTARY CHUCK 1 DETECTION MEMORY 7200 SPECIAL SPEC SELECT 5 MEMORY 7250 NON USE
7131 ROTARY CHUCK 2 DETECTION MEMORY 7201 W. LAMP SPECIAL SPEC. 8 MEMORY 7251 NON USE
7132 ROTARY CHUCK 3 DETECTION MEMORY 7202 SPECIAL SPEC SELECT 6 MEMORY 7252 NON USE
7133 ROTARY CHUCK 4 DETECTION MEMORY 7203 W. LAMP SPECIAL SPEC. 9 MEMORY 7253 NON USE
7134 T AXIS NORMAL POSITION MEMORY 7204 SPECIAL SPEC SELECT 7 MEMORY 7254 NON USE
7135 BRAKE RELEASE RELAY 1 ACTIVE MEMORY 7205 W. LAMP SPECIAL SPEC. 10 MEMORY 7255 NON USE
7136 T AXIS ABNORMAL POSITION MEMORY 7206 W. LAMP SPECIAL SPEC. 11 MEMORY 7256 NON USE
7137 SEMI AUTO MEMORY 7207 NON USE 7257 NON USE
Memory2 Memory2 Memory2
7140 LOADER RAIL TRAVERSE LIMIT MEMORY 7210 HEAD ROTATE START MEMORY 7260 NON USE
7141 LOADER RAIL RETURN LIMIT MEMORY 7211 HEAD ROTATE END MEMORY 7261 NON USE
7142 P.C.B. DETECTION 1 MEMORY 7212 JW UNIT SAFETY STOP MEMORY 7262 NON USE
7143 P.C.B. DETECTION 2 MEMORY 7213 ENABLING SW PRESS(FOR H BRAKE) MEMORY 7263 NON USE
7144 P.C.B. DETECTION 5 MEMORY 7214 H BRAKE IN SEQUENCE MEMORY 7264 NON USE
7145 UNLOADER RAIL TRAVERSE LIMIT MEMORY 7215 H BRAKE RELEASE SET MEMORY 7265 NON USE
7146 UNLOADER RAIL RETURN LIMIT MEMORY 7216 H AXIS BRAKE SW DETECTION MEMORY 7266 NON USE
7147 P.C.B. DETECTION 3 MEMORY 7217 QH 0°ROTATION MEMORY 7267 NON USE
Memory2 Memory2 IFR1
7270 NON USE 7340 NON USE 2010 SERVO FREE SW S→M
7271 NON USE 7341 NON USE 2011 THERMAL TRIP (DUST COLLETTER) S→M
7272 NON USE 7342 NON USE 2012 SAFETY INPUT S→M
7273 NON USE 7343 NON USE 2013 JW SETTING S→M
7274 NON USE 7344 NON USE 2014 SLIDE CHUCK SETTING RETURN S→M
7275 NON USE 7345 NON USE 2015 SLIDE CHUCK SETTING TRAVERSE S→M
7276 NON USE 7346 NON USE 2016 MAINTENANCE SW RELEASE S→M
7277 NON USE 7347 NON USE 2017 BRAKE RELEASE SIGNAL S→M
Memory2 Memory2 IFR1
7300 NON USE 7350 NON USE 2020 M.ORIGIN S→M
7301 NON USE 7351 NON USE 2021 L.ORIGIN S→M
7302 NON USE 7352 NON USE 2022 THERMAL TRIP (VACUUM PUMP) S→M
7303 NON USE 7353 NON USE 2023 T AXIS SENSOR 1 S→M
7304 NON USE 7354 NON USE 2024 T AXIS SENSOR 2 S→M
7305 NON USE 7355 NON USE 2025 T AXIS SENSOR 3 S→M
7306 NON USE 7356 NON USE 2026 DOUBLE PCB TRANSFER INPUT S→M
7307 NON USE 7357 NON USE 2027 BAD MARK DETECTION S→M
Memory2 Memory2 IFR1
7310 NON USE 7360 NON USE 2030 XY TABLE PCB DETECTION 1 S→M
7311 NON USE 7361 NON USE 2031 XY TABLE PCB DETECTION 2 S→M
7312 NON USE 7362 NON USE 2032 LOADER P.C.B. DETECTION S→M
7313 NON USE 7363 NON USE 2033 POSITIONER DETECTION S→M
7314 NON USE 7364 NON USE 2034 LEFT LEAD ANVIL SHORT ERROR S→M
7315 NON USE 7365 NON USE 2035 RIGHT LEAD ANVIL SHORT ERROR S→M
7316 NON USE 7366 NON USE 2036 P.C.B. WAIT MESSAGE (L) S→M
7317 NON USE 7367 NON USE 2037 P.C.B. WAIT MESSAGE (UL) S→M
Memory2 Memory2 IFR1
7320 NON USE 7370 NON USE 2040 ZL AXIS SAFETY DETECTION S→M
7321 NON USE 7371 NON USE 2041 ZR AXIS SAFETY DETECTION S→M
7322 NON USE 7372 NON USE 2042 Z CENTER SAFETY DETECTION S→M
7323 NON USE 7373 NON USE 2043 LEFTSIDE COVER (C) DETECTION S→M
7324 NON USE 7374 NON USE 2044 RIGHTSIDE COVER (C) DETECTION S→M
7325 NON USE 7375 NON USE 2045 ZL AXIS CASSETTE GAP DETECTION S→M
7326 NON USE 7376 NON USE 2046 ZR AXIS CASSETTE GAP DETECTION S→M
7327 NON USE 7377 NON USE 2047 NON USE
Memory2 IFR1 IFR1
7330 NON USE 2000 1 BLOCK STOP ERROR S→M 2050 ZL SHUNTING DETECTION S→M
7331 NON USE 2001 HANDLE STOP S→M 2051 ZR SHUNTING DETECTION S→M
7332 NON USE 2002 HANDLE STOP (S) S→M 2052 ROTARY CHUCK ORG. DETECTIONS→M
7333 NON USE 2003 FRONT COVER STOP S→M 2053 ZL SHUNTING CHECK SW ERRORS→M
7334 NON USE 2004 REAR COVER STOP S→M 2054 ZR SHUNTING CHECK SW ERROR S→M
7335 NON USE 2005 LOADER COVER STOP S→M 2055 NON USE
7336 NON USE 2006 UNLOADER COVER STOP S→M 2056 NON USE
7337 NON USE 2007 AIR DOWN DETECTION S→M 2057 NON USE
