1 2 3 4 5 6 7 8 9 10 111213 14 15 16 171819 20 212223 24252627 2829 3031323334353637383940414243444546474849505152535455565758596061626364 65666768 6970Ｃ ｏ ｍ ｍ ｅ ｎ ｔ Addr.
SAFETY STOP ;MEMORY 1011
FULL AUTO ;MEMORY 1104
SEMI AUTO ;MEMORY 1105
MANUAL ;MEMORY 1106
SAFETY INPUT ON ;MEMORY 1127
VACUUM SUCTION DOWN ACTION ;MEMORY 1162
VACUUM SUCTION UP ACTION ;MEMORY 1163
P.C.B. CONVERY FORWERD ;MEMORY 1164
P.C.B. CONVERY REVERSE ;MEMORY 1165
RESET 1 ;MEMORY 1166
RESET 2 ;MEMORY 1167
OPERATION START ;M→S 2030
RECOVERY ;M→S 2031
SAFETY COVER SW (BSF-V) ;IN 4046
PCB CONV.MOTOR REV.TURN(BSF-V) ;OUT 4231
PCB CONV.MOTOR RIG.TURN(BSF-V) ;OUT 4232
PCB CONV. MOTOR BRAKE (BSF-V) ;OUT 4233
VACUUM SUCTION VALVE UP(BSF-V) ;OUT 4235
VACUUM SUCTION VAL.DOWN(BSF-V) ;OUT 4236
ENABLING INPUT ; 2377
ＮＡＭＥ
Ｎｏ.
AVK3/JVK3B SC V01.11
VACUUM SUCTION PCB SEP. SAFETY (COMMON) 75
M30871-41-075-00-CAE
