SC Program Sheet.pdf - 第9页
IFR1 IFR2 IFR2 2130 WH AXIS ORIGIN M→S 2200 X/Y AXIS INTERLOCK 1 M→S 2250 PATTERN 1 INFORMATION M→S 2131 WA AXIS ORIGIN M→S 2201 X/Y AXIS INTERLO…
Memory IFR1 IFR1
1340 CYCLE TIMER CH1 ON MEMORY 2010 ONLINE MODE M→S 2060 ROTARY CHUCK ST1 CYL M→S
1341 CYCLE TIMER CH2 ON MEMORY 2011 FULL AUTO MODE M→S 2061 ROTARY CHUCK ST2 CYL M→S
1342 CYCLE TIMER CH3 ON MEMORY 2012 SEMI AUTO MODE M→S 2062 ROTARY CHUCK ST3 CYL M→S
1343 CYCLE TIMER CH4 ON MEMORY 2013 MANUAL MODE M→S 2063 ROTARY CHUCK ST4 CYL M→S
1344 CYCLE TIMER CH5 ON MEMORY 2014 DISPLAY SWITCHING (LCD/CRT) M→S 2064 CENTERING CHUCK1 CYL M→S
1345 CYCLE TIMER CH6 ON MEMORY 2015 Z AXIS CONNECT MODE M→S 2065 CENTERING CHUCK2 CYL M→S
1346 CYCLE TIMER CH7 ON MEMORY 2016 Z AXIS PREPARATION MODE M→S 2066 CENTERING CHUCK3 CYL M→S
1347 CYCLE TIMER CH8 ON MEMORY 2017 Z EXCHANGE･PRIORITY MODE M→S 2067 CENTERING CHUCK4 CYL M→S
Memory IFR1 IFR1
1350 CYCLE TIMER CH9 ON MEMORY 2020 1 BLOCK MODE M→S 2070 JW UNIT SET (TRAVERSE) CYL M→S
1351 CYCLE TIMER CH10 ON MEMORY 2021 EOP MODE M→S 2071 JW UNIT SET (RETURN) CYL M→S
1352 CYCLE TIMER CH11 ON MEMORY 2022 CONTINUOUS MODE M→S 2072 TAPE CUTTER DUMPER CYL M→S
1353 CYCLE TIMER CH12 ON MEMORY 2023 ACTION START NO INSERTION M→S 2073 INSERTION GUIDE CYL M→S
1354 CYCLE TIMER CH13 ON MEMORY 2024 ROTARY CHUCK NO.1 M→S 2074 NON USE
1355 CYCLE TIMER CH14 ON MEMORY 2025 ROTARY CHUCK NO.2 M→S 2075 NON USE
1356 CYCLE TIMER CH15 ON MEMORY 2026 ROTARY CHUCK NO.3 M→S 2076 NON USE
1357 CYCLE TIMER CH16 ON MEMORY 2027 ROTARY CHUCK NO.4 M→S 2077 NON USE
Memory IFR1 IFR1
1360 CYCLE TIMER CH1 ON MEMORY 2030 OPERATION START M→S 2100 ZL AXIS PARTS CHANGING M→S
1361 CYCLE TIMER CH2 ON MEMORY 2031 RECOVERY M→S 2101 ZR AXIS PARTS CHANGING M→S
1362 CYCLE TIMER CH3 ON MEMORY 2032 TEACHING M→S 2102 ZL AXIS CHANGING CONFIRM M→S
1363 CYCLE TIMER CH4 ON MEMORY 2033 FINAL INSERTION SIGNAL M→S 2103 ZR AXIS CHANGING CONFIRM M→S
1364 CYCLE TIMER CH5 ON MEMORY 2034 NO INSERTION SIGNAL M→S 2104 NON USE
1365 CYCLE TIMER CH6 ON MEMORY 2035 ANVIL DETECT EXHAUST SIGNAL M→S 2105 NON USE
1366 CYCLE TIMER CH7 ON MEMORY 2036 PARTS DETECT EXHAUST SIGNAL M→S 2106 COVER OPEN/CLOSE CHECK REQUEST M→S
1367 CYCLE TIMER CH8 ON MEMORY 2037 EIGING ACTION SIGNAL M→S 2107 Z MOVING WARNING BUZZER M→S
Memory IFR1 IFR1
1370 CYCLE TIMER CH9 ON MEMORY 2040 LOADER START M→S 2110 TIMING ZONE CONTROL 1 M→S
1371 CYCLE TIMER CH10 ON MEMORY 2041 L.STOP M→S 2111 NO INSERTION SIGNAL 1 TIME M→S
1372 CYCLE TIMER CH11 ON MEMORY 2042 P.C.B. TAKE OUT POSSIBLE M→S 2112 FULCULUM CHANGE RESTART M→S
1373 CYCLE TIMER CH28 ON MEMORY 2043 P.C.B. DISCHARGE M→S 2113 26mm→52mm CHANGE SIGNAL M→S
1374 CYCLE TIMER CH13 ON MEMORY 2044 LOADER MAGAZIN DISCHARGE M→S 2114 H AXIS PATTERN 3 TO 10 M→S
1375 CYCLE TIMER CH14 ON MEMORY 2045 UNLOADER MAGAZIN DISCHARGE M→S 2115 NON USE
1376 CYCLE TIMER CH15 ON MEMORY 2046 LOADER MAGAZIN UNLOADING M→S 2116 NON USE
1377 CYCLE TIMER CH16 ON MEMORY 2047 NON USE 2117 NON USE
IFR1 IFR1 IFR1
2000 WARNING LAMP RED ON M→S 2050 SLIDE CHUCK STOP (T) CYL M→S 2120 X AXIS ORIGIN M→S
2001 WARNING LAMP RED BLINK M→S 2051 26mm T.CHUCK SHUNTING CYL M→S 2121 Y AXIS ORIGIN M→S
2002 WARNING LAMP YELLOW ON M→S 2052 26mm TRANSFER CHUCK CYL M→S 2122 ZL AXIS ORIGIN M→S
2003 WARNING LAMP YELLOW BLINK M→S 2053 52mm TRANSFER CHUCK CYL M→S 2123 H AXIS ORIGIN M→S
2004 WARNING LAMP GREEN ON M→S 2054 SLIDE CHUCK STOP (R) CYL M→S 2124 θH AXIS ORIGIN M→S
2005 WARNING LAMP GREEN BLINK M→S 2055 26mm T.CHUCK SHUNTING SIGNAL M→S 2125 θA AXIS ORIGIN M→S
2006 NON USE 2056 26mm T.CHUCK OUTPUT SIGNAL M→S 2126 ZR AXIS ORIGIN M→S
2007 NON USE 2057 NON USE 2127 U AXIS ORIGIN M→S
IFR1 IFR2 IFR2
2130 WH AXIS ORIGIN M→S 2200 X/Y AXIS INTERLOCK 1 M→S 2250 PATTERN 1 INFORMATION M→S
2131 WA AXIS ORIGIN M→S 2201 X/Y AXIS INTERLOCK 2 M→S 2251 PATTERN 2 INFORMATION M→S
2132 V AXIS ORIGIN M→S 2202 ZL AXIS(NORMAL) M→S 2252 PATTERN 3 INFORMATION M→S
2133 T AXIS ORIGIN M→S 2203 ZL AXIS(SLOW) M→S 2253 PATTERN 4 INFORMATION M→S
2134 NON USE 2204 ZR AXIS(NORMAL) M→S 2254 PATTERN 5 INFORMATION M→S
2135 NON USE 2205 ZR AXIS(SLOW) M→S 2255 PATTERN 6 INFORMATION M→S
2136 NON USE 2206 NON USE 2256 PATTERN 7 INFORMATION M→S
2137 NON USE 2207 NON USE 2257 PATTERN 8 INFORMATION M→S
IFR1 IFR2 IFR2
2140 X AXIS RUN M→S 2210 HEAD SERVO ON SIGNAL M→S 2260 PATTERN 9 INFORMATION M→S
2141 Y AXIS RUN M→S 2211 ZL AXIS SERVO WORKING M→S 2261 PATTERN 10 INFORMATION M→S
2142 ZL AXIS RUN M→S 2212 ZR AXIS SERVO WORKING M→S 2262 TIMING ZONE CONTROL 2 M→S
2143 H AXIS RUN M→S 2213 ALL AXIS SERVO WORKING M→S 2263 θH AXIS 90ﾟROTATION (BACKWARD) M→S
2144 θH AXIS RUN M→S 2214 NON USE 2264 θH AXIS 180 TURN ANGLE SIGNAL M→S
2145 θA AXIS RUN M→S 2215 NON USE 2265 M2 M→S
2146 ZR AXIS RUN M→S 2216 NON USE 2266 JUMPPER LINE SUPLY SIGNAL M→S
2147 U AXIS RUN M→S 2217 NON USE 2267 NON USE
IFR1 IFR2 IFR2
2150 WH AXIS RUN M→S 2220 TABLE AXIS COUPLING ACTION M→S 2270 CAM STARTM→S
2151 WA AXIS RUN M→S 2221 PIN AXIS COUPLING ACTION M→S 2271 P.END (READ START) M→S
2152 V AXIS RUN M→S 2222 NON USE 2272 INSERT DETECT EXIST/NONE M→S
2153 T AXIS RUN M→S 2223 NON USE 2273 HOUR METER OUTPUT M→S
2154 NON USE 2224 NON USE 2274 READ COMPLETE M→S
2155 NON USE 2225 NON USE 2275 T1 DIRECTION ROTATE M→S
2156 NON USE 2226 EVALUATION OUTPUT M→S 2276 T2 DIRECTION ROTATE M→S
2157 NON USE 2227 NON USE 2277 JVK3 SELECTION M→S
IFR1 IFR2 IFR2
2160 X AXIS P.END M→S 2230 ROTARY CHUCK 1 DELIVERY ST CYL M→S 2300 H MOVEMENT PATTERN 1 +90° M→S
2161 Y AXIS P.END M→S 2231 ROTARY CHUCK 2 DELIVERY ST CYL M→S 2301 H MOVEMENT PATTERN 2 +90° M→S
2162 ZL AXIS P.END M→S 2232 ROTARY CHUCK 3 DELIVERY ST CYL M→S 2302 H MOVEMENT PATTERN 3 +90° M→S
2163 H AXIS P.END M→S 2233 ROTARY CHUCK 4 DELIVERY ST CYL M→S 2303 H MOVEMENT PATTERN 4 +90° M→S
2164 θH AXIS P.END M→S 2234 NON USE 2304 H MOVEMENT PATTERN 5 +90° M→S
2165 θA AXIS P.END M→S 2235 NON USE 2305 H MOVEMENT PATTERN 6 +90° M→S
2166 ZR AXIS P.END M→S 2236 NON USE 2306 H MOVEMENT PATTERN 7 +90° M→S
2167 U AXIS P.END M→S 2237 NON USE 2307 H MOVEMENT PATTERN 8 +90° M→S
IFR1 IFR2 IFR2
2170 WH AXIS P.END M→S 2240 EMPTY INSERTION SIGNAL 2310 H MOVEMENT PATTERN 9 +90° M→S
2171 WA AXIS P.END M→S 2241 INSERTION SIGNAL 2311 H MOVEMENT PATTERN10 +90° M→S
2172 V AXIS P.END M→S 2242 INSERTION UNIT 90ﾟROTATION 2312 INSIDE OF TACT MOVE. +90° M→S
2173 T AXIS P.END M→S 2243 NON USE 2313 OUT OF TACT MOVEMENT +90° M→S
2174 NON USE 2244 NON USE 2314 NON USE
2175 NON USE 2245 NON USE 2315 NON USE
2176 NON USE 2246 NON USE 2316 NON USE
2177 NON USE 2247 NON USE 2317 NON USE
IFR2 IFR2 SUB CONTOROL PANEL
2320 H MOVEMENT PATTERN 1 +0° M→S 2370 H MOVEMENT PATTERN 9 +180° M→S 3040 TAPE CUTTER DUMPER SW SUBCON
2321 H MOVEMENT PATTERN 2 +0° M→S 2371 H MOVEMENT PATTERN10 +180° M→S 3041 OPTION 4 SW SUBCON
2322 H MOVEMENT PATTERN 3 +0° M→S 2372 INSIDE OF TACT MOVEMENT +180° M→S 3042 OPTION 10 SW SUBCON
2323 H MOVEMENT PATTERN 4 +0° M→S 2373 OUT OF TACT MOVEMENT +180° M→S 3043 LOADER BELT SW SUBCON
2324 H MOVEMENT PATTERN 5 +0° M→S 2374 NON USE 3044 OPTION 13 SW SUBCON
2325 H MOVEMENT PATTERN 6 +0° M→S 2375 NON USE 3045 OPTION 19 SW SUBCON
2326 H MOVEMENT PATTERN 7 +0° M→S 2376 NON USE 3046 NON USE
2327 H MOVEMENT PATTERN 8 +0° M→S 2377 ENABLING INPUT 3047 NON USE
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2330 H MOVEMENT PATTERN 9 +0° M→S 3000 OPTION 1 SW SUBCON 3050 △ SW SUBCON
2331 H MOVEMENT PATTERN10 +0° M→S 3001 ROTARY CHUCK 1 SW SUBCON 3051 CHANGING TRANSFER PITCH. SW SUBCON
2332 INSIDE OF TACT MOVEMENT +0° M→S 3002 26 TRANSFER CHUCK SW SUBCON 3052 SLIDE TRAVERSE SW SUBCON
2333 OUT OF TACT MOVEMENT +0° M→S 3003 HEAD SERVO OFF SW SUBCON 3053 OPTION 5 SW SUBCON
2334 NON USE 3004 OPTION 7 SW SUBCON 3054 OPTION 11 SW SUBCON
2335 NON USE 3005 UNLOADER RAIL SW SUBCON 3055 CARRY TRAVERSE SW SUBCON
2336 NON USE 3006 P.C.B. PUSH IN SW SUBCON 3056 OPTION 14 SW SUBCON
2337 NON USE 3007 OPTION 16 SW SUBCON 3057 OPTION 20 SW SUBCON
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2340 H MOVEMENT PATTERN 1 +270° M→S 3010 NON USE 3060 NON USE
2341 H MOVEMENT PATTERN 2 +270° M→S 3011 NON USE 3061 NON USE
2342 H MOVEMENT PATTERN 3 +270° M→S 3012 LOAD SW SUBCON 3062 ▽ SW SUBCON
2343 H MOVEMENT PATTERN 4 +270° M→S 3013 ROTARY CHUCK 2 SW SUBCON 3063 CO. REMOVING A PART SW SUBCON
2344 H MOVEMENT PATTERN 5 +270° M→S 3014 52 TRANSFER CHUCK SW SUBCON 3064 SLIDE RETURN SW SUBCON
2345 H MOVEMENT PATTERN 6 +270° M→S 3015 OPTION 2 SW SUBCON 3065 OPTION 6 SW SUBCON
2346 H MOVEMENT PATTERN 7 +270° M→S 3016 OPTION 8 SW SUBCON 3066 OPTION 12 SW SUBCON
2347 H MOVEMENT PATTERN 8 +270° M→S 3017 UNLOADER BELT SW SUBCON 3067 CARRY RETURN SW SUBCON
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2350 H MOVEMENT PATTERN 9 +270° M→S 3020 P.C.B. SUPPLY SW SUBCON 3070 OPTION 15 SW SUBCON
2351 H MOVEMENT PATTERN10 +270° M→S 3021 OPTION 17 SW SUBCON 3071 OPTION 21 SW SUBCON
2352 INSIDE OF TACT MOVEMENT +270° M→S 3022 NON USE 3072 NON USE
2353 OUT OF TACT MOVEMENT +270° M→S 3023 NON USE 3073 NON USE
2354 NON USE 3024 RESET SW SUBCON 3074 NON USE
2355 NON USE 3025 ROTARY CHUCK 3 SW SUBCON 3075 NON USE
2356 NON USE 3026 JW SET SW SUBCON 3076 NON USE
2357 NON USE 3027 OPTION 3 SW SUBCON 3077 NON USE
IFR2 SUB CONTOROL PANEL SUB CONTOROL PANEL
2360 H MOVEMENT PATTERN 1 +180° M→S 3030 OPTION 9 SW SUBCON 3100 OPTION 1 LED SUBCON
2361 H MOVEMENT PATTERN 2 +180° M→S 3031 LOADER RAIL SW SUBCON 3101 ROTARY CHUCK 1 LED SUBCON
2362 H MOVEMENT PATTERN 3 +180° M→S 3032 POSITIONER LEVER SW SUBCON 3102 26 TRANSFER CHUCK LED SUBCON
2363 H MOVEMENT PATTERN 4 +180° M→S 3033 OPTION 18 SW SUBCON 3103 HEAD SERVO OFF LED SUBCON
2364 H MOVEMENT PATTERN 5 +180° M→S 3034 NON USE 3104 OPTION 7 LED SUBCON
2365 H MOVEMENT PATTERN 6 +180° M→S 3035 NON USE 3105 UNLOADER RAIL LED SUBCON
2366 H MOVEMENT PATTERN 7 +180° M→S 3036 HEAD TEACHING SW SUBCON 3106 P.C.B. PUSH IN LED SUBCON
2367 H MOVEMENT PATTERN 8 +180° M→S 3037 ROTARY CHUCK 4 SW SUBCON 3107 OPTION 16 LED SUBCON
