LOOP2 ADD-6 Memory Memory 0360 PART SUPPLY MOTOR OUT(OP) 1030 P.C.B. SUPPLY LOADING MEMORY 1100 MODE SWITCHING MEMORY 0361 NON USE 1031 LOADING R…
LOOP2 ADD-F LOOP1 ADD-4 LOOP2 ADD-1
0170 PCB POSITIONING DETCTION 1 IN(OP) 0240 NON USE 0310 HOUR METER RUNNING SIGNAL OUT
0171 PCB POSITIONING DETCTION 2 IN(OP) 0241 NON USE 0311 LOADER STOCKER ROTATION SIGNAL OUT
0172 PCB POSITIONING DETCTION 3 IN(OP) 0242 NON USE 0312 P.C.B. SUPPLY CYL SIGNAL OUT
0173 PCB POSITIONING DETCTION 4 IN(OP) 0243 NON USE 0313 UNLOADER STOCKER ROTATION SIG. OUT
0174 STOP CYCLE SIGNAL RIGHT IN(OP) 0244 NON USE 0314 PUSH ARM CYL SIGNAL OUT
0175 IN(OP) 0245 NON USE 0315 SAFETY RELEASE BUZZER OUT
0176 STOP CYCLE SIGNAL LEFT IN(OP) 0246 NON USE 0316 P.C.B. SUPPLY VALVE OUT
0177 NON USE 0247 NON USE 0317 POSITIONER PIN COUPLING VALVE OUT(OP)
LOOP1 ADD-0 LOOP1 ADD-5 LOOP2 ADD-2
0200 WARNING LAMP (RED/YELLOW) OUT 0250 NON USE 0320 ZL PARTS CHANGING SIGNAL OUT
0201 WARNING LAMP (YELLOW/WHITE) OUT 0251 NON USE 0321 ZR PARTS CHANGING SIGNAL OUT
0202 WARNING LAMP (GREEN) OUT 0252 NON USE 0322 P.END (POSITIONING END) OUT
0203 CT.IL OUTPUT OUT 0253 NON USE 0323 READ COMPLETE OUT
0204 DISPLAY CHANGE OUT 0254 NON USE 0324 SAFETY VALVE OUT
0205 BACKLIGHT ON/OFF OUT 0255 NON USE 0325 T AXIS START OUTPUT OUT
0206 BUZZER OUTPUT OUT(OP) 0256 NON USE 0326 CT OUTPUT (CH17) OUT
0207 AIR BLOW VALVE OUT 0257 NON USE 0327 EVALUATION OUTPUT OUT
LOOP1 ADD-1 LOOP1 ADD-6 LOOP2 ADD-3
0210 ROTARY CHUCK 1 VALVE OUT 0260 NON USE 0330 GROUP EMPTY SIGNAL (SC→LM) OUT(OP)
0211 ROTARY CHUCK 2 VALVE OUT 0261 NON USE 0331 LD PART EMPTY SIGNAL (SC→LM) OUT(OP)
0212 ROTARY CHUCK 3 VALVE OUT 0262 NON USE 0332 COUNT UP SIGNAL (SC→LM) OUT(OP)
0213 ROTARY CHUCK 4 VALVE OUT 0263 NON USE 0333 MAIN BODY EMPTY SIGNAL(SC→LM) OUT(OP)
0214 26 SLIDE CHUCK VALVE OUT 0264 NON USE 0334 CYCLE TIME OUTPUT (SC→LM) OUT(OP)
0215 52 SLIDE CHUCK VALVE OUT 0265 NON USE 0335 ERROR OUTPUT (SC→LM) OUT(OP)
0216 SLIDE CHUCK PITCH SWIT. VALVE OUT 0266 NON USE 0336 SPARE (SC→LM) OUT(OP)
0217 H AXIS BRAKE RELEASE 1 (OUTPUT) OUT 0267 NON USE 0337 NON USE
LOOP1 ADD-2 LOOP1 ADD-7 LOOP2 ADD-4
0220 JW SET VALVE (TRAVERSE) OUT 0270 NON USE 0340 STOP COMPLETION SIGNAL (R) OUT(OP)
0221 JW SET VALVE (RETURN) OUT 0271 NON USE 0341 SPARE (RIGHT SIDE) OUT(OP)
0222 CHUCK SLIDE VALVE (TRAVERSE) OUT 0272 NON USE 0342 STOP COMPLETION SIGNAL (L) OUT(OP)
0223 CHUCK SLIDE VALVE (RETURN) OUT 0273 NON USE 0343 SPARE (LEFT SIDE) OUT(OP)
0224 H AXIS BRAKE RELEASE OUT 0274 NON USE 0344 AUTO WIDTH ACTION START OUT(OP)
0225 T AXIS NORMAL POSITION OUT 0275 NON USE 0345 SPARE OUT(OP)
0226 TAPE CUTTER DUMPER VALVE OUT 0276 NON USE 0346 NON USE
0227 T AXIS ORIGIN SIGNAL OUT 0277 NON USE 0347 NON USE
LOOP1 ADD-3 LOOP2 ADD-0 LOOP2 ADD-5
0230 SPARE OUT 0300 INSERTION VOLTAGE CHECK 1 OUT 0350 P.END (POSITIONING END) OUT
0231 BUZZER OUTPUT 2 OUT(OP) 0301 INSERTION VOLTAGE CHECK 2 OUT 0351 READ COMPLETE OUT
0232 NON USE 0302 PARTS WASTE BLOW VALVE OUT(OP) 0352 HEAD ROTATE CYL (TRAVERSE) OUT
0233 NON USE 0303 X/Y AXIS START OUTPUT OUT 0353 HEAD ROTATE CYL (RETURN) OUT
0234 NON USE 0304 H AXIS INTERLOCK OUTPUT OUT 0354 NON USE
0235 NON USE 0305 ZL AXIS PARTS CHANGING OUT 0355 NON USE
0236 NON USE 0306 ZR AXIS PARTS CHANGING OUT 0356 ANVIL ROTATE CYL (TRAVERSE) OUT
0237 NON USE 0307 VACUUM PUMP ACTION SIGNAL OUT 0357 ANVIL ROTATE CYL (RETURN) OUT
LOOP2 ADD-6 Memory Memory
0360 PART SUPPLY MOTOR OUT(OP) 1030 P.C.B. SUPPLY LOADING MEMORY 1100 MODE SWITCHING MEMORY
0361 NON USE 1031 LOADING RESET ACTION 2 MEMORY 1101 INITIAL START MEMORY
0362 NON USE 1032 MAINTENANCE MEMORY 1102 MEMORY CLEAR MEMORY
0363 NON USE 1033 MANUAL (FOR MAINTENANCE) MEMORY 1103 MANUAL MODE MEMORY
0364 NON USE 1034 ROTARY CHUCK VALVE1 ACTION MEMORY 1104 FULL AUTO MEMORY
0365 WARNING LAMP OUTPUT (GREEN) OUT(OP) 1035 ROTARY CHUCK VALVE2 ACTION MEMORY 1105 SEMI AUTO MEMORY
0366 WARNING LAMP OUTPUT (WHITE) OUT(OP) 1036 ROTARY CHUCK VALVE3 ACTION MEMORY 1106 MANUAL MEMORY
0367 WARNING LAMP OUTPUT (YELLOW) OUT(OP) 1037 ROTARY CHUCK VALVE4 ACTION MEMORY 1107 SWITCHING MEMORY
LOOP2 ADD-7 Memory Memory
0370 NON USE 1040 ZL AXIS SAFETY STOP MEMORY 1110 X/Y AXIS INTERLOCK MEMORY
0371 NON USE 1041 ZR AXIS SAFETY STOP MEMORY 1111 ZL AXIS INTERLOCK MEMORY
0372 NON USE 1042 Z CENTER SAFETY DETECTION MEMORY 1112 H AXIS INTERLOCK MEMORY
0373 NON USE 1043 CONVEYER BELT MOTOR ACTION MEMORY 1113 U AXIS INTERLOCK MEMORY
0374 NON USE 1044 P.PUSH ACTION (TRAVERSE) MEMORY 1114 ZR AXIS INTERLOCK MEMORY
0375 NON USE 1045 P.PUSH ACTION (RETURN) MEMORY 1115 WIDTH CLOSING INTERLOCK MEMORY
0376 NON USE 1046 JW SET ACTION (TRAVERSE) MEMORY 1116 T AXIS INTERLOCK MEMORY
0377 NON USE 1047 JW SET ACTION (RETURN) MEMORY 1117 CENTERING CHUCK CHANGE MEMORY
Memory Memory Memory
1000 1 BLOCK STOP MEMORY 1050 LOADER RAIL ACTION MEMORY 1120 LOADER SIDE TRANSFER MEMORY
1001 HANDLE STOP MEMORY 1051 UNLOADER RAIL ACTION MEMORY 1121 P.C.B. DISCHARGE FINISH MEMORY
1002 HANDLE STOP (S) MEMORY 1052 PCB TRANSFER ACTION (TRAVERSE) MEMORY 1122 LD BELT MOTOR REVERSE TURN MEMORY
1003 FRONT COVER STOP MEMORY 1053 PCB TRANSFER ACTION (RETURN) MEMORY 1123 VACUUM OPERATION 1 MEMORY
1004 REAR COVER STOP MEMORY 1054 LOADER BELT MOTOR ACTION MEMORY 1124 VACUUM OPERATION 2 MEMORY
1005 LOADER COVER STOP MEMORY 1055 UNLOADER BELT MOTOR ACTION MEMORY 1125 P.C.B. EXHAUST MEMORY
1006 UNLOADER COVER STOP MEMORY 1056 P.PUSH ACTION MEMORY 1126 VACUUM OPERATION 3 MEMORY
1007 AIR DOWN STOP MEMORY 1057 P.PULL ACTION MEMORY 1127 SAFETY INPUT ON MEMORY
Memory Memory Memory
1010 WARNING LAMP COMBINE MEMORY 1060 P.PUSH RESET MEMORY 1130 FRONT COVER SAFETY STOP MEMORY
1011 SAFETY STOP MEMORY 1061 PARTS DETECTION MEMORY 1131 WIDTH CLOSING SELECT (SW2) MEMORY
1012 SAFETY STOP RESET 1 MEMORY 1062 PRODUCTION COMPLETION MEMORY 1132 UL SIDE CONNECTION SELECT(SW3) MEMORY
1013 MAINTENANCE SW MEMORY 1063 P.PULL EFFECTIVE MEMORY 1133 TRANSFER FLOW SELECT (SW4) MEMORY
1014 BRAKE SW DETECTION MEMORY 1064 P.PUSH EFFECTIVE MEMORY 1134 TRANSFER POSITION SELECT (SW5) MEMORY
1015 SAFETY DETECTION EFFECTIVE MEMORY 1065 P.C.B. DETECTION 4 MEMORY 1135 L SIDE CONNECTION SELECT1(SW6) MEMORY
1016 WARNING LAMP YELLOW ON MEMORY 1066 PARTS DETECTION ACTION MEMORY 1136 L SIDE CONNECTION SELECT2(SW7) MEMORY
1017 H BRAKE RELEASE MEMORY 1067 PARTS DETECTION ABNOMAL MEMORY 1137 L SIDE CONNECTION SELECT3(SW8) MEMORY
Memory Memory Memory
1020 SEMI AUTO LOAD START MEMORY 1070 LEFTSIDE COVER STOP (C) MEMORY 1140 SEMI AUTO RESET MEMORY
1021 L.ORIGIN MEMORY 1071 RIGHTSIDE COVER STOP (C) MEMORY 1141 MAINTENANCE ACTION 1 MEMORY
1022 SEMI AUTO LOAD ACTION MEMORY 1072 RIGHT OF FRONTSIDE COVER STOP MEMORY 1142 INSERT ACTION MEMORY
1023 LOADING ACTION START MEMORY 1073 SAFETY STOP RESET 3 MEMORY 1143 HEAD TEACHING ACTION MEMORY
1024 P.C.B. DISCARGE ACTION MEMORY 1074 SAFETY STOP RESET 4 MEMORY 1144 SPECIAL SPEC. SELECT 1 MEMORY
1025 LOADING ACTION 1 MEMORY 1075 JW SET VALVE RESET MEMORY 1145 SPECIAL SPEC. SELECT 2 MEMORY
1026 LOADING ACTION 2 MEMORY 1076 UL BELT MOTOR RETURN ACTION MEMORY 1146 SPECIAL SPEC. SELECT 3 MEMORY
1027 LOADING RESET ACTION 1 MEMORY 1077 LOADING RESET MEMORY 1147 SPECIAL SPEC. SELECT 4 MEMORY
Memory Memory Memory
1150 △ SWITCH ACTION MEMORY 1220 INSERT CHECK ERROR (L.R) MEMORY 1270 P.SEP TRAVERSE LIMIT ERROR MEMORY
1151 ▽ SWITCH ACTION MEMORY 1221 INSERT CHECK ERROR (R) MEMORY 1271 P.SEP RETURN LIMIT ERROR MEMORY
1152 W. LAMP STANDARD SPEC. MEMORY 1222 INSERT CHECK ERROR (L) MEMORY 1272 P.ARM/P.UP TRAVERSE LIMIT ERR. MEMORY
1153 W. LAMP SPECIAL SPEC. 1 MEMORY 1223 ANVIL SHORT ERROR MEMORY 1273 P.ARM/P.UP RETURN LIMIT ERROR MEMORY
1154 W. LAMP SPECIAL SPEC. 2 MEMORY 1224 INSERTION ACTION MEMORY 1274 ROTARY CHUCK No.3 MEMORY
1155 W. LAMP SPECIAL SPEC. 3 MEMORY 1225 INSERT CHECK ACTION MEMORY 1275 ROTARY CHUCK No.4 MEMORY
1156 W. LAMP SPECIAL SPEC. 4 MEMORY 1226 INSERT CHECK (RIGHT SIDE) MEMORY 1276 INTERLOCK OUTPUT 2 MEMORY
1157 W. LAMP SPECIAL SPEC. 5 MEMORY 1227 INSERT CHECK (LEFT SIDE) MEMORY 1277 LOADING ERROR MEMORY
Memory Memory Memory
1160 LOADER STOP MEMORY 1230 P.C.B. DETECTION EXIST (H) MEMORY 1300 EMERGENCY STOP SIGNAL MEMORY
1161 MAINTENANCE ACTION 2 MEMORY 1231 SLIDE CHUCK TRAVERSE ERROR MEMORY 1301 XY AXIS INTERLOCK SQUEEZE MEMORY
1162 VACUUM SUCTION DOWN ACTION MEMORY 1232 SLIDE CHUCK RETURN ERROR MEMORY 1302 INTERLOCK SQUEEZE MEMORY
1163 VACUUM SUCTION UP ACTION MEMORY 1233 JW SET TRAVERSE ERROR MEMORY 1303 ZL AXIS PARTS EXCHANGEING MEMORY
1164 P.C.B. CONVERY FORWERD MEMORY 1234 JW SET RETURN ERROR MEMORY 1304 ZR AXIS PARTS EXCHANGEING MEMORY
1165 P.C.B. CONVERY REVERSE MEMORY 1235 NON USE 1305 JVK3/AVK2 SELECTION MEMORY
1166 RESET 1 MEMORY 1236 1 BLOCK CHECK PICK UP MEMORY 1306 JW READ ERROR SIGNAL MEMORY
1167 RESET 2 MEMORY 1237 1 BLOCK CHECK PICK DOWN MEMORY 1307 POSITIONER PIN ENABLE MEMORY
Memory Memory Memory
1170 P.C.B. SUPPLY SIGNAL MEMORY 1240 P.C.B. DETECTION EXIST (L) MEMORY 1310 LOADER END MEMORY
1171 P.C.B. TAKE OUT MEMORY 1241 P.C.B. TRANSFER ACTION MEMORY 1311 JW UNIT TRAVERSE FINISH MEMORY
1172 W. LAMP SPECIAL SPEC. 6 MEMORY 1242 P.C.B. DETECTION 3 MEMORY 1312 JW UNIT RETURN FINISH MEMORY
1173 W. LAMP SPECIAL SPEC. 7 MEMORY 1243 TRANSFER TRAVERSE ERROR MEMORY 1313 INTERLOCK OUTPUT 1 MEMORY
1174 ZL CASSETTE GAP STOP MEMORY 1244 TRANSFER RETURN ERROR MEMORY 1314 ZL AXIS EXCHANGE WORK MEMORY
1175 ZR CASSETTE GAP STOP MEMORY 1245 CARRY MISS MEMORY 1315 ZL AXIS EXCHANGE WORK MEMORY
1176 ZL AXIS SAFETY STOP 2 MEMORY 1246 POSITIONER ERROR MEMORY 1316 ZL PARTS EXHAUST FINISH MEMORY
1177 ZR AXIS SAFETY STOP 2 MEMORY 1247 WARNING LAMP SPECIAL SPEC. C MEMORY 1317 ZR PARTS EXHAUST FINISH MEMORY
Memory Memory Memory
1200 HANDLE ERROR MEMORY 1250 LOADER RAIL TRAVERSE ERROR MEMORY 1320 SLIDE CHUCK STOP(T) FINISH MEMORY
1201 SLIDE CHUCK TRAVERSE ACTION MEMORY 1251 LOADER RAIL RETURN ERROR MEMORY 1321 SLIDE CHUCK STOP(R) FINISH MEMORY
1202 SLIDE CHUCK IL1 MEMORY 1252 UNLOADER RAIL TRAVERSE ERROR MEMORY 1322 T CHUCK SHUNTING(T) FINISH MEMORY
1203 TRANSFER START CHECK MOMORY 1253 UNLOADER RAIL RETURN ERROR MEMORY 1323 T CHUCK SHUNTING(R) FINISH MEMORY
1204 COUPLING TRAVERSE ERROR 1 MEMORY 1254 POSITIONER TRAVERSE ERROR MEMORY 1324 CYCLE STOP SIGNAL OFF MEMORY
1205 COUPLING RETURN ERROR 1 MEMORY 1255 POSITIONER RETURN ERROR MEMORY 1325 RESET OFF MEMORY
1206 COUPLING TRAVERSE ERROR 2 MEMORY 1256 ROTARY CHUCK No.1 MEMORY 1326 ZL AXIS EXCHANGE LAMP MEMORY
1207 COUPLING RETURN ERROR 2 MEMORY 1257 ROTARY CHUCK No.2 MEMORY 1327 ZR AXIS EXCHANGE LAMP MEMORY
Memory Memory Memory
1210 THERMAL TRIP ERROR MEMORY 1260 LOADER RAIL LOAD MISS MEMORY 1330 ZL STANDBY POSITION MOVEMENT MEMORY
1211 SLIDE CHUCK RETURN ACTION MEMORY 1261 UNLOADER RAIL LOAD MISS MEMORY 1331 ZR STANDBY POSITION MOVEMENT MEMORY
1212 SLIDE CHUCK IL2 MEMORY 1262 LOADER P.C.B. WAIT ERROR MEMORY 1332 ZL PARTS CHANGE FINISH MEMORY
1213 NON USE 1263 UNLOADER P.C.B. WAIT ERROR MEMORY 1333 ZR PARTS CHANGE FINISH MEMORY
1214 COUPLING TRAVERSE ACTION 1 MEMORY 1264 P.C.B. WAIT MEMORY 1334 ZL PARTS CHANGE DEMAND MEMORY
1215 COUPLING RETURN ACTION1 MEMORY 1265 TRANSFER TRAVERSE ACTION MEMORY 1335 ZR PARTS CHANGE DEMAND MEMORY
1216 COUPLING TRAVERSE ACTION 2 MEMORY 1266 TRANSFER RETURN ACTION MEMORY 1336 ZL AXIS SAFETY STOP MEMORY
1217 COUPLING RETURN ACTION 2 MEMORY 1267 WH AXIS ORIGIN MEMORY 1337 ZR AXIS SAFETY STOP MEMORY
