IFR1 IFR1 IFR2 2060 CASSETTE DETECTION S→M 2130 SC VERSION CHECK 9 S→M 2200 HANDLE ERROR S→M 2061 PARTS DETECTION S→M 2131 SC VERSION CHECK 10 S…
Memory2 Memory2 IFR1
7270 NON USE 7340 NON USE 2010 SERVO FREE SW S→M
7271 NON USE 7341 NON USE 2011 THERMAL TRIP (DUST COLLETTER) S→M
7272 NON USE 7342 NON USE 2012 SAFETY INPUT S→M
7273 NON USE 7343 NON USE 2013 JW SETTING S→M
7274 NON USE 7344 NON USE 2014 SLIDE CHUCK SETTING RETURN S→M
7275 NON USE 7345 NON USE 2015 SLIDE CHUCK SETTING TRAVERSE S→M
7276 NON USE 7346 NON USE 2016 MAINTENANCE SW RELEASE S→M
7277 NON USE 7347 NON USE 2017 BRAKE RELEASE SIGNAL S→M
Memory2 Memory2 IFR1
7300 NON USE 7350 NON USE 2020 M.ORIGIN S→M
7301 NON USE 7351 NON USE 2021 L.ORIGIN S→M
7302 NON USE 7352 NON USE 2022 THERMAL TRIP (VACUUM PUMP) S→M
7303 NON USE 7353 NON USE 2023 T AXIS SENSOR 1 S→M
7304 NON USE 7354 NON USE 2024 T AXIS SENSOR 2 S→M
7305 NON USE 7355 NON USE 2025 T AXIS SENSOR 3 S→M
7306 NON USE 7356 NON USE 2026 DOUBLE PCB TRANSFER INPUT S→M
7307 NON USE 7357 NON USE 2027 BAD MARK DETECTION S→M
Memory2 Memory2 IFR1
7310 NON USE 7360 NON USE 2030 XY TABLE PCB DETECTION 1 S→M
7311 NON USE 7361 NON USE 2031 XY TABLE PCB DETECTION 2 S→M
7312 NON USE 7362 NON USE 2032 LOADER P.C.B. DETECTION S→M
7313 NON USE 7363 NON USE 2033 POSITIONER DETECTION S→M
7314 NON USE 7364 NON USE 2034 LEFT LEAD ANVIL SHORT ERROR S→M
7315 NON USE 7365 NON USE 2035 RIGHT LEAD ANVIL SHORT ERROR S→M
7316 NON USE 7366 NON USE 2036 P.C.B. WAIT MESSAGE (L) S→M
7317 NON USE 7367 NON USE 2037 P.C.B. WAIT MESSAGE (UL) S→M
Memory2 Memory2 IFR1
7320 NON USE 7370 NON USE 2040 ZL AXIS SAFETY DETECTION S→M
7321 NON USE 7371 NON USE 2041 ZR AXIS SAFETY DETECTION S→M
7322 NON USE 7372 NON USE 2042 Z CENTER SAFETY DETECTION S→M
7323 NON USE 7373 NON USE 2043 LEFTSIDE COVER (C) DETECTION S→M
7324 NON USE 7374 NON USE 2044 RIGHTSIDE COVER (C) DETECTION S→M
7325 NON USE 7375 NON USE 2045 ZL AXIS CASSETTE GAP DETECTION S→M
7326 NON USE 7376 NON USE 2046 ZR AXIS CASSETTE GAP DETECTION S→M
7327 NON USE 7377 NON USE 2047 NON USE
Memory2 IFR1 IFR1
7330 NON USE 2000 1 BLOCK STOP ERROR S→M 2050 ZL SHUNTING DETECTION S→M
7331 NON USE 2001 HANDLE STOP S→M 2051 ZR SHUNTING DETECTION S→M
7332 NON USE 2002 HANDLE STOP (S) S→M 2052 ROTARY CHUCK ORG. DETECTIONS→M
7333 NON USE 2003 FRONT COVER STOP S→M 2053 ZL SHUNTING CHECK SW ERRORS→M
7334 NON USE 2004 REAR COVER STOP S→M 2054 ZR SHUNTING CHECK SW ERROR S→M
7335 NON USE 2005 LOADER COVER STOP S→M 2055 NON USE
7336 NON USE 2006 UNLOADER COVER STOP S→M 2056 NON USE
7337 NON USE 2007 AIR DOWN DETECTION S→M 2057 NON USE
IFR1 IFR1 IFR2
2060 CASSETTE DETECTION S→M 2130 SC VERSION CHECK 9 S→M 2200 HANDLE ERROR S→M
2061 PARTS DETECTION S→M 2131 SC VERSION CHECK 10 S→M 2201 ANVIL SHORT ERROR S→M
2062 COVER OPEN/CLOSE DETECTION S→M 2132 SC VERSION CHECK 11 S→M 2202 MAINTENANCE ACTION S→M
2063 TAPE CUTTER DUMPER DETECTION S→M 2133 SC VERSION CHECK 12 S→M 2203 MAINTE.CIRCUIT ABNOMAL ERROR S→M
2064 NON USE 2134 SC VERSION CHECK 13 S→M 2204 D0 S→M
2065 LCD FAN ABNORMAL DET S→M 2135 SC VERSION CHECK 14 S→M 2205 D1 S→M
2066 PARTS DETECTION ABNOMAL S→M 2136 SC VERSION CHECK 15 S→M 2206 D2 S→M
2067 BRAKE SW DETECTION S→M 2137 SC VERSION CHECK 16 S→M 2207 D3 S→M
IFR1 IFR1 IFR2
2070 SC VERSION CHECK 1 S→M 2140 RESET (SUBCON) S→M 2210 THERMAL TRIP ERROR S→M
2071 SC VERSION CHECK 2 S→M 2141 HEAD SERVO OFF (SUBCON) S→M 2211 ZL PARTS EXCHANGE (COVER) S→M
2072 SC VERSION CHECK 3 S→M 2142 INSERT (SUBCON) S→M 2212 ZR PARTS EXCHANGE (COVER) S→M
2073 SC VERSION CHECK 4 S→M 2143 TEACHING (SUBCON) S→M 2213 ZL PARTS EXCHANGE (CASSETTE) S→M
2074 SC VERSION CHECK 5 S→M 2144 NON USE 2214 ZR PARTS EXCHANGE (CASSETTE) S→M
2075 SC VERSION CHECK 6 S→M 2145 NON USE 2215 DVLD (DATA VALID) S→M
2076 SC VERSION CHECK 7 S→M 2146 ZL COVER OPEN/CLOSE DETECTION S→M 2216 X/Y (XY DATA SWITCHING) S→M
2077 SC VERSION CHECK 8 S→M 2147 ZR COVER OPEN/CLOSE DETECTION S→M 2217 OUT OF AREA S→M
IFR1 IFR1 IFR2
2100 X AXIS INTERLOCK S→M 2150 △ (SUBCON) S→M 2220 INSERT CHECK ERROR (L/R) S→M
2101 Y AXIS INTERLOCK S→M 2151 ▽ (SUBCON) S→M 2221 INSERT CHECK ERROR (R) S→M
2102 ZL AXIS INTERLOCK S→M 2152 ZL COVER DETECTION S→M 2222 INSERT CHECK ERROR (L) S→M
2103 H AXIS INTERLOCK S→M 2153 ZL CASSETTE DETECTION S→M 2223 D4 S→M
2104 θH AXIS INTERLOCK S→M 2154 ZR COVER DETECTION S→M 2224 D5 S→M
2105 θA AXIS INTERLOCK S→M 2155 ZR CASSETTE DETECTION S→M 2225 D6 S→M
2106 ZR AXIS INTERLOCK S→M 2156 NON USE 2226 D7 S→M
2107 U AXIS INTERLOCK S→M 2157 NON USE 2227 S→M
IFR1 IFR1 IFR2
2110 WH AXIS INTERLOCK S→M 2160 LOADER STOP S→M 2230 PCB DETECTION ERROR (XY) S→M
2111 WA AXIS INTERLOCK S→M 2161 NON USE 2231 SLIDE CHUCK TRAVERSE ERROR S→M
2112 V AXIS INTERLOCK S→M 2162 DURING SEMI AUTO LOADING S→M 2232 SLIDE CHUCK RETURN ERROR S→M
2113 T AXIS INTERLOCK S→M 2163 NON USE 2233 JW SET TRAVERSE ERROR S→M
2114 WIDTH CLOSING INTERLOCK S→M 2164 L. MAGAZINE EMPTY S→M 2234 JW SET RETURN ERROR S→M
2115 CHUCK SLIDE STOP IL (A) S→M 2165 L. MAGAZINE FULL S→M 2235 θH ROTATE TRAVERSE ERROR S→M
2116 CHUCK SLIDE STOP IL (JW) S→M 2166 L. MAGAZINE SET S→M 2236 θH ROTATE RETURN ERROR S→M
2117 PARTS EXHAUST DETECTION S→M 2167 L. MAGAZINE TAKE OUT S→M 2237 NON USE
IFR1 IFR1 IFR2
2120 P.C.B. STOCK R1PS S→M 2170 TABLE AXIS SLIT SENSOR S→M 2240 PCB DETECTION ERROR (XY) S→M
2121 PCB DISCHARGE FINISH R1UP S→M 2171 PIN AXIS SLIT SENSOR S→M 2241 NON USE
2122 ENABLING SW S→M 2172 NON USE 2242 NON USE
2123 NON USE 2173 NON USE 2243 TRANSFER TRAVERSE ERROR S→M
2124 NON USE 2174 UL. MAGAZINE EMPTY S→M 2244 TRANSFER RETURN ERROR S→M
2125 NON USE 2175 UL. MAGAZINE FULL S→M 2245 CARRY MISS S→M
2126 ZL/ZR/T 2nd TIMING CHECK S→M 2176 UL. MAGAZINE SET S→M 2246 POSITIONER ERROR S→M
2127 T AXIS SENSER CHECK S→M 2177 UL. MAGAZINE TAKE OUT S→M 2247 NON USE
IFR2 IFR2 IFR2
2250 LOADER RAIL TRAVERSE ERROR S→M 2320 SLIDE CHUCK TRAVERSE FINISH S→M 2370 CYCLE TIMER CH9 ON S→M
2251 LOADER RAIL RETURN ERROR S→M 2321 SLIDE CHUCK RETURN FINISH S→M 2371 CYCLE TIMER CH10 ON S→M
2252 UNLOADER RAIL TRAVERSE ERROR S→M 2322 26mmTRANSFER CHUCK TRA. FINISH S→M 2372 CYCLE TIMER CH11 ON S→M
2253 UNLOADER RAIL RETURN ERROR S→M 2323 26mmTRANSFER CHUCK RET. FINISH S→M 2373 CYCLE TIMER CH28 ON S→M
2254 POSITIONER LEVER TRAVERSE ERR S→M 2324 HEAD ROTATE TRAVERSE LIMIT ERROR S→M 2374 CYCLE TIMER CH13 ON S→M
2255 POSITIONER LEVER RETURN ERROR S→M 2325 HEAD ROTATE RETURN LIMIT ERROR S→M 2375 CYCLE TIMER CH14 ON S→M
2256 NON USE 2326 ANVIL ROTATE TRAV. LIMIT ERROR S→M 2376 CYCLE TIMER CH15 ON S→M
2257 NON USE 2327 ANVIL ROTATE RETURN LIMIT ERRO S→M 2377 CYCLE TIMER CH16 ON S→M
IFR2 IFR2
2260 LOADER RAIL LOAD MISS S→M 2330 ZL STANDBY POSITION DEMAND S→M
2261 UNLOADER RAIL LOAD MISS S→M 2331 ZR STANDBY POSITION DEMAND S→M
2262 PCB WAIT ERROR (LOADER) S→M 2332 ZL PARTS CHANGE FINISH S→M
2263 PCB WAIT ERROR (UNLOADER) S→M 2333 ZR PARTS CHANGE FINISH S→M
2264 TABLE CP TRAVERSE FINISH S→M 2334 ZL PARTS CHANGE DEMAND S→M
2265 TABLE CP RETURN FINISH S→M 2335 ZR PARTS CHANGE DEMAND S→M
2266 PIN CP TRAVERSE FINISH S→M 2336 SWITCH ON ERROR FOR MANUAL S→M
2267 PIN CP RETURN FINISH S→M 2337 JUMPER SUPPLY STOP DETECT ERROR S→M
IFR2 IFR2
2270 P.SEP TRAVERSE ERROR S→M 2340 CYCLE TIMER CH1 ON S→M
2271 P.SEP RETURN ERROR S→M 2341 CYCLE TIMER CH2 ON S→M
2272 PUSH ARM/PUSH UP TRAVERSE ERR. S→M 2342 CYCLE TIMER CH3 ON S→M
2273 PUSH ARM/PUSH UP RETURN ERROR S→M 2343 CYCLE TIMER CH4 ON S→M
2274 TABLE CP TRAVERSE ERROR S→M 2344 CYCLE TIMER CH5 ON S→M
2275 TABLE CP RETURN ERROR S→M 2345 CYCLE TIMER CH6 ON S→M
2276 PIN CP TRAVERSE ERROR S→M 2346 CYCLE TIMER CH7 ON S→M
2277 PIN CP RETURN ERROR S→M 2347 CYCLE TIMER CH8 ON S→M
IFR2 IFR2
2300 EMERGENCY STOP SW INPUT S→M 2350 CYCLE TIMER CH9 ON S→M
2301 SAFETY STOP INPUT S→M 2351 CYCLE TIMER CH10 ON S→M
2302 INTERLOCK INPUT S→M 2352 CYCLE TIMER CH11 ON S→M
2303 SERVO LOCK FREE S→M 2353 CYCLE TIMER CH12 ON S→M
2304 HEAD ROTATE END S→M 2354 CYCLE TIMER CH13 ON S→M
2305 H BRAKE RELEASE DISABLE S→M 2355 CYCLE TIMER CH14 ON S→M
2306 INCORRECT HEAD BRAKE RELEASE SEQ S→M 2356 CYCLE TIMER CH15 ON S→M
2307 JW UNIT NOT MOVING S→M 2357 CYCLE TIMER CH16 ON S→M
IFR2 IFR2
2310 LOADER END S→M 2360 CYCLE TIMER CH1 ON S→M
2311 JW UNIT SET FINISH (TRAVERSE) S→M 2361 CYCLE TIMER CH2 ON S→M
2312 JW UNIT SET FINISH (RETURN) S→M 2362 CYCLE TIMER CH3 ON S→M
2313 COMPLETED REMOVING A PART S→M 2363 CYCLE TIMER CH4 ON S→M
2314 JW UNIT TRAVERSE (SUBCON) S→M 2364 CYCLE TIMER CH5 ON S→M
2315 JW UNIT RETURN (SUBCON) S→M 2365 CYCLE TIMER CH6 ON S→M
2316 SL.CHUCK STOP TRAVERSE(SUBCON) S→M 2366 CYCLE TIMER CH7 ON S→M
2317 SL.CHUCK STOP RETURN(SUBCON) S→M 2367 CYCLE TIMER CH8 ON S→M
