Balloon Quntity Part Number REV DESCRIPTION UM 16.00 1277603 TC PROBE TYPE K 18 IN EA 2.00 1442505 CONN STRN RLF 3/4 @ .200/.472 EA 1.00 3039901 D ASSY I.A.S. EA BOM NUMBER 3107304 ASSY REDUNDANT OVERTEMP 820 DESCRIPTION…
Balloon Quntity Part Number REV DESCRIPTION UM
1 1.00 0685001 F MTR ASSY 3PH 220V AC W/TACH MT EA
2 1.00 0563601 BLO WL 7.00OD X 1.31W BCK CV EA
3 6.00 0809701 WASHER VIB DAMP EA
4 3.00 1171506 SCR 10-32 X .750 BTNH SKT SST EA
5 3.00 0809601 TUBE ISOLATION EA
6 2.00 1278906 SCR 1/4-28 X 3/4 SOCSET KCUP PT EA
7 1.00 1247703 SEAL SHAFT .88ID 1.28 FACE EA
8 3.00 1103200 WSHR 10 FL SST EA
BOM NUMBER
3100301
ASSY MOTOR/FAN 208-240V
DESCRIPTION
DATE
SHEET
1
REV
B
/ 1
03-Mar-1999
Sort Column = POS
RETURN TO INDEX
3100301
B
NONE
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
16.00 1277603 TC PROBE TYPE K 18 IN EA
2.00 1442505 CONN STRN RLF 3/4 @ .200/.472 EA
1.00 3039901 D ASSY I.A.S. EA
BOM NUMBER
3107304
ASSY REDUNDANT OVERTEMP 820
DESCRIPTION
DATE
SHEET
1
REV
B
/ 1
02-Apr-2001
Sort Column = POS
RETURN TO INDEX
3107304
B
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quantity Part Number REV DESCRIPTION UM
0.00 1153704 SLEEVE TEF CLR 18AWG 250C FT
0.25 1154603 SHRINK TUBE 3/8 WHT FT
1.00 1297501 B MOTOR DC 1/12HP 312:4-1 GEARHD EA
18.00 1454803 CBL 3 COND 18 AWG W/DRN 600V 90C FT
1.00 1489603 CONN MALE 5MM 3P NON-MISMATING EA
1.00 1489703 CONN FEMALE 5MM 3P NON-MISMATING EA
6.00 1469223 Ferrule Wire 20 AWG two Conductor EA
0.25 1396301 SHRINK, TUBE GRN/YEL 1/8 FT
2 1.00 1367001 SURGE SUPPRESSOR 150V DISK MOV EA
BOM NUMBER
3816701
A
SSY ELEC CONVEYOR MOTO
R
DESCRIPTION
DATE
SHEET
1
REV
E
/ 1
03-Nov-2004
Sort Column = POS
RETURN TO INDEX
3816701
E
DRAWING NUMBER
REV
BCR TYPE
CUR
