Balloon Quntity Part Number REV DESCRIPTION UM 38 1.00 6039601 BRKT AUTOLUBE MTG EA 39 1.00 6041201 BRKT AUTOLUBE PUMP MTG EA 40 2.00 1171512 SCR 10-32 X 1.50 BTNH SKT SST EA 41 2.00 1171504 SCR 10-32 X .500 BTNH SKT SST…
Balloon Quntity Part Number REV DESCRIPTION UM
1.00 1477101 TUBE COIL 1/8X1.25X(REF) NYLON EA
1.00 3111601 D ASSY AUTOLUBE WIRING EA
2 1.00 1457201 RESERVOIR OIL 1QT SQ EA
4 2.00 1354601 FTG HEX NIPPLE 1/8MPT X 1/8MPT EA
5 1.00 1358102 PUMP METERING 2 FEEDS EA
6 2.00 1429703 FTG CONN 1/8X1/8 MPT COMP BRS EA
11 2.00 0958906 FTG 10-32X1/4 ALUBE X 1/2 LG EA
12 0.00 1037000 ADHESIVE THREAD LOCKING 242 EA
13 8.00 1296001 RIVET MONO 3/16DX.44GP MAX STL EA
15 2.00 1412301 BRUSH 1/4 ID X 1 OD SST WIRE EA
16 2.00 1429702 FTG CONN 1/8 X 10-32 COMP BRS EA
17 2.00 1429801 FTG UNION 1/8T COMP BRS EA
19 4.00 1012500 WSHR 1/4 FL STL EA
21 17.00 1020202 CABLE TIE 8 IN L EA
22 4.00 1012300 WSHR 1/4 SPLT LK STL EA
23 8.00 1133700 CBL TIE ANCHOR CLIP ON EA
24 5.00 1457404 CLAMP CABLE 5/16 BLACK NYLON EA
25 1.00 1463401 FTG NIPPLE 1/8NPTx1-1/2 BRS EA
26 2.00 1227204 OIL SYN CHAIN LUBE 1 PINT EA
27 4.00 1011900 NUT 1/4-20 HEX STL FIN EA
31 20.00 1406401 TUBE 1/8 X .058 NYLON FT
32 2.00 1399901 RING GRIP EXT 1/4 EA
33 4.00 1268701 WSHR WAVE SPRING 1/4 SCR EA
34 1.00 1241105 FTG TEE 1/8 FPT BRASS EA
35 1.00 1204500 FTG EL90 1/8FPT BRS EA
36 1.00 1243803 FTG PLUG 1/8 MPT C'SINK HX BRS EA
BOM NUMBER
3124401
ASSY ALUBE PLUMB 2 PORT
DESCRIPTION
DATE
SHEET
1
REV
E
/ 2
03-Oct-2002
Sort Column = POS
RETURN TO INDEX
3124401
E
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
38 1.00 6039601 BRKT AUTOLUBE MTG EA
39 1.00 6041201 BRKT AUTOLUBE PUMP MTG EA
40 2.00 1171512 SCR 10-32 X 1.50 BTNH SKT SST EA
41 2.00 1171504 SCR 10-32 X .500 BTNH SKT SST EA
42 7.00 1171503 SCR 10-32 X .375 BTNH SKT SST EA
43 7.00 1103000 WASHER #10 18-8 SPLIT LOCK SST EA
44 7.00 1103200 WSHR 10 FL SST EA
45 5.00 1103600 NUT 10-32 HEX SST EA
46 4.00 1011506 SCR 1/4-20X3/4 SOCBHD STL EA
47 1.00 1217410 SCR 10-32X1-1/4 SOCCAP SST EA
BOM NUMBER
3124401
ASSY ALUBE PLUMB 2 PORT
DESCRIPTION
DATE
SHEET
2
REV
E
/ 2
03-Oct-2002
Sort Column = POS
3124401
E
DRAWING NUMBER
REV
BCR TYPE
CUR
Balloon Quntity Part Number REV DESCRIPTION UM
2 1.00 0881101 SHFT DRIVE SPRKT BELT WIDE EA
3 2.00 1346301 BEARING FLG 1/2ID LT DUTY EA
5 10.00 1012300 WSHR 1/4 SPLT LK STL EA
6 10.00 1011900 NUT 1/4-20 HEX STL FIN EA
7 2.00 0877001 PLT SPRT MOUNT BELT L-R EA
9 6.00 1013505 SCR 1/4-20X5/8 HHD STL EA
10 10.00 1124500 WSHR 1/4 FL SST EA
11 4.00 1013508 SCR 1/4-20X1 HHD STL EA
12 8.00 1055700 BLANK OFFLOAD EA
13 2.00 0856401 SPRKT WIRE BELT 17 TOOTH MBS EA
BOM NUMBER
3126201
ASSY BELT ONLOAD 20INX1/2P
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
31-Jan-2000
Sort Column = POS
RETURN TO INDEX
3126201
A
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
