Balloon Quntity Part Number REV DESCRIPTION UM 1.00 1232001 TBG 3/8OD .032WALL SOFT COPPER FT 75.00 1232901 TBG 3/8OD NYL BLK LEGRIS FT 4.00 1237501 FTG EL90 3/8T X 1/4MPT LEG PLAS EA 4.00 1241901 FTG BLKHD 3/8T X 1/4FTP…
Balloon Quntity Part Number REV DESCRIPTION UM
12.50 1232001 TBG 3/8OD .032WALL SOFT COPPER FT
1.00 1241901 FTG BLKHD 3/8T X 1/4FTP SWG BRS EA
1.00 1243401 FTG TEE 3/8T SWG BRS EA
1.00 1243801 FTG PLUG 1/4MPT CSNK HX BRS EA
4.00 1244105 PLUG HOLE SNAP BTN 5/8 NKL/PLT EA
BOM NUMBER
3169301
ASSY PURGE TUBES XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
26-Jun-2003
Sort Column = POS
RETURN TO INDEX
3169301
A
4169301
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
1.00 1232001 TBG 3/8OD .032WALL SOFT COPPER FT
75.00 1232901 TBG 3/8OD NYL BLK LEGRIS FT
4.00 1237501 FTG EL90 3/8T X 1/4MPT LEG PLAS EA
4.00 1241901 FTG BLKHD 3/8T X 1/4FTP SWG BRS EA
4.00 3169601 A ASSY N2 INLET FITTING XPM2 EA
BOM NUMBER
3169501
ASSY PIPING N2 CELLS AND BAFFLES
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
27-Jun-2003
Sort Column = POS
RETURN TO INDEX
3169501
A
4169501
DRAWING NUMBER
REV
A
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
1.00 1376301 SENSOR SPEED UNDER 100RPM EA
1.75 1454803 CBL 3 COND 18 AWG W/DRN 600V 90C FT
1.00 3152701 A ASSY CELL INTERFACE PCB XPM2 EA
0.00 1480001 TOOL OPERATING 3.5MM SIDE-ENTRY WIRING EA
P1 1.00 1479502 CONN PLUG 3.5MM 2 POLE PLUG-IN EA
P2 1.00 1479503 CONN PLUG 3.5MM 3 POLE PLUG-IN EA
P3 1.00 1479508 CONN PLUG 3.5MM 8 POLE PLUG-IN EA
BOM NUMBER
3170101
ASSY CELL SENSING FAN & HTR XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
03-Jul-2003
Sort Column = POS
RETURN TO INDEX
3170101
A
DRAWING NUMBER
REV
BCR TYPE
CUR
