Montageanleitung Head Reconfiguration Kits SIPLACE D1 / D2
Ausgabe 02/2007
46
Assembly instructions Head Reconfiguration SIPLACE D1 / D2
Edition 03/2007
47
2 Assembly instructions - SIPLACE
D1/D2 Head Reconfiguration Kits
Described in this document are the head configurations that are possible in a SIPLACE D1 and
D2. 2
Only the procedure for assembly is described. Disassembly take
s place in reverse order.
Calibration and mapping are unnecessary for disassembly. 2
2.1 Head modularity
There are two head configuration options: 2
2.1.1 D1 Head modularity
D1
*For further information, see Chapter 2.1.2 ”D2 Head modularity” 2
2
Gantry 1
Configuration
Initially
configurable* from
SW Version 604
and SW 603 SP1
Placement head 1 Placement head 2
Placement
head
- P&P Modul 1 x
C&P6 P&P Modul 2
C&P12 P&P Modul 3
C&P6 - 4 x
C&P12 - 5 x
Assembly instructions Head Reconfiguration SIPLACE D1 / D2
Edition 03/2007
48
2.1.2 D2 Head modularity
D2
2
2.1.3 Assembling the reconfiguration kits
Refitting from one configuration to another there is one of the following extension sets required:2
From configuration 1 to 2, 4: "Extension set for D1 sing
le C+P 6" (00119863-)
From configuration 1 to 3, 5: "Extension set for D1 sing
le C+P 12" (00119864-)
From configuration 4, 5 to 1, 2, 3: "Extension kit P+P for D1 single" (00119862
-) 2
Refitting from one type of C&P head to another there is one
of the following reconfiguration kits
required: 2
From configuration 2, 4, 6, 7, 9 to 3, 5, 7, 8, 9: "Recon
fig.Kit
C&P12 SIPLACE D1/2" (00119860-)
F
rom configuration 3, 5, 7, 8, 9 to 2, 4, 6, 7, 9: "Recon
fig.Kit
C&P6 SIPLACE D1/2" (00119861-) 2
2.1.4 Prerequisites and restrictions
Required for a D1 single head configuration is SW 603 SP1.
This configuration is already an integral part of the software from SW 604. 2
2.1.5 Refitting times
The following refitting times can be expected for each head: 2
Gantry 1 Gantry 2
Configuration
Placement head 1 Placement head 2
Placement
head
C&P6 C&P6 6
C&P6 C&P12 7
C&P12 C&P12 8
C&P12 C&P6 9
2
Placement head
Single / double
transport Activity
Disassembly C&P 6/12 20 min
No options such as nozzle changer
and no query components reject bin.
