PREVENTIVE MAINTENANCE CLEANING, LUBRICATION A ND MAINTENA NCE DIAGRAMS Chapter Issue 5, Aug 14 Technical Reference Manual 28.59 CLEANING , LUBRICA T ION A ND MAINTENANCE DIAGRAMS Figure 28-1 Rising T able A T ooling ( c…
PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
28.58 Technical Reference Manual Chapter Issue 5, Aug 14
SEMI Level TRS Pull Down Reference Fork Grooves Tick
Inspect for wear, clean and apply a small amount of grease around the fork groove of the
brace assembly forks.
SEMI Level Topside Referencing System Tick
Check the action of the stripper springs, replace if motion is slow or damage is evident.
Replace the z-lock return springs. When refitting, ensure they are intact, not damaged and
not stretched.
Replace the TRA cylinder springs. When refitting, ensure they are intact, not damaged and
not stretched.
Check the electrical and pneumatic looms to the Z-lock, Rail Cap, Reference Cylinders,
TRA cylinders and the Pusher Plate are not damaged. Replace as necessary.
Replace the return springs on the active surround. When refitting, ensure they are intact,
not damaged and not stretched.
Ensure that the interlock pins return against spring pressure, do not stick in the slider.
Replace if necessary.
Rail Cap Bearing Retainers for signs of damage, replace as required.
Rail Cap height above the vacuum chamber.
Estimated time required for Monthly tasks 6.0 hours
Summary/Remarks
Signed: Date:
SEMI1
SEMI 2
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 5, Aug 14 Technical Reference Manual 28.59
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Figure 28-1 Rising Table
A
Tooling (clean)
Manual Tooling Plate (clean)
View on Rear of Rising Table
Transport Rail Drive Belt
Rising Table Drive Belt
LED Stencil Backlight Panel (clean)
Rising Table Ballscrew
Transport Rail Ballscrew
(in 2 positions)
Rising Table Motor
Linear Bearing Block
(in 4 positions)
View on Arrow A
Sensor Vane
Vertical Linear Bearing Guide Rails
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
28.60 Technical Reference Manual Chapter Issue 5, Aug 14
Figure 28-2 Paste Dispenser
View on Rear of Print Carriage
Linear Bearing Guides
Paste Drip Tray
Home Sensor
Home Vane
Paste Dispenser Drive Belt
