PREVENTIVE MAINTENANCE CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS 28.66 Technical Reference Manual Chapter Issue 5, Aug 14 Figure 28-8 Chase Rail Assembly Cable Retainer Bracket View o n C hase R ai lA ssemb ly
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 5, Aug 14 Technical Reference Manual 28.65
Figure 28-7 Adjustable Screen Mount (ASM)
Stencil Guide Strips
Pulleys
(in 3 positions)
View on FlapAssembly (cover removed)
Screen At Centre Sensor
Stencil Guide Strip
(in 13 positions)
Stencil Location Leaf Spring
(in 3 positions)
Flap Assembly
(in 8 positions)
ASM (isometric view)
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
28.66 Technical Reference Manual Chapter Issue 5, Aug 14
Figure 28-8 Chase Rail Assembly
Cable Retainer Bracket
View on Chase RailAssembly
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 5, Aug 14 Technical Reference Manual 28.67
Figure 28-9 Screen Actuators
Y Actuator
X Rear Actuator
X Front Actuator
Plan View on Machine
Fixed Ball Striker Plate
