13- F シングルコン ベア:NPM Si ngle Conve yor:NP M パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1007 018 3AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O71 ( KN610070183AA-11-6 )
Ref
No.
Remarks
R
1
Q'ty
13-E
シングルコンベア:NPM
Single Conveyor:NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610070183AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210122658AB
BRACKET
1
2 N210118961AB
BRACKET
1
3 N210113251AC
PIN
4
4 KXFB0210A00
BLOCK
1
5 N210105101AC
BRACKET
1
6 N210092051AA
BRACKET
1
7 N210092070AC
BRACKET
1
8 N210092071AE
BRACKET
1
9 N210092074AA
BEARING
2
11 N510024787AA 6000ZZ
COUPLING
1
12 N510034822AA Special MSF-20-D8XD8(2-M5)
BOLT
2
13 N510020808AA
Hexagon head bolt Best class M6x25-6g A2-70 no mark
BOLT
2
14 N510038131AA
Hexagon head bolt Best class M6x80-6g A2-70 Full thread no mark
SPACER
4
15 N510015195AA ASF-452E
BOLT
1
16 N510039161AA
Hexagon socket head cap screw M3X40-10.9 A2J (Trivalent) Full thread
JOINT
1
17 KXF0DYM2A00 KQ2L06-M5
SILENCER
2
18 KXF00WCAA00 AN120-M5
VALVE
1
19 N510052032AA 4GA140-C6-A2N-FL424713-3
BLOCK
1
20 N510024582AA VQ1000-FPG-C6M5
RING
2
21 KXF089MAA00 R4X0.5
JOINT
2
22 KXF0DZJ5A00 KQ2L06-99
JOINT
2
23 KXF0E48YA00 KQ2Y04-M5
BOLT
1
24 N510017681AA
Hexagon head bolt Best class M10X50-6g 4T A2J (Trivalent)
SENSOR
1
25 N510049698AA EE-SX910-C2J-R 0.2M
O70
--
( KN610070183AA-11-5 )
13-F
シングルコンベア:NPM
Single Conveyor:NPM
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610070183AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O71
( KN610070183AA-11-6 )
Ref
No.
Remarks
R
1
Q'ty
13-F
シングルコンベア:NPM
Single Conveyor:NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610070183AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210117583AA
BRACKET
1
2 N210092049AA
BRACKET
1
3 N210109334AB
RAIL
1
4 N210105345AA
COVER
1
5 N210119056AA
MANIFOLD
1
6 N510052033AA M4GA110-C4-A2N-4-FL424709-3
JOINT
4
7 KXF0DZKJA00 KQ2L04-99
SPACER
2
8 N510029522AA CF-320E
BOLT
2
9 N510017329AA
Hexagon socket head cap screw M3X40-10.9 A2J (Trivalent)
AMP
12
10 N510035086AA FX-101-PFS
SPACER
2
11 N510029536AA CF-414E
CABLE-BEAR
1
12 N510044610AA TKP0250W20R50X16LINK
SPACER
3
13 N510029495AA ASF-458E
JOINT
4
14 KXF0DZQCA00 KQ2W04-99
VALVE
4
15 N510047869AA 4GA119-C4-E2-3
MANIFOLD
1
16 N510047868AA M4GA1-00-4
JOINT
1
17 N510045001AA GWS6-6
SILENCER
2
18 N418SLW6S SLW-6S
PLUG
3
19 KXF057WAA00 Plug 1/8
